改善压气机端区流动的新方法——前缘边条叶片技术

伊卫林; 唐方明; 陈志民; 季路成

doi:10.13224/j.cnki.jasp.2015.07.022

改善压气机端区流动的新方法——前缘边条叶片技术

doi: 10.13224/j.cnki.jasp.2015.07.022

1. 北京理工大学机械与车辆学院, 北京 100081;
2. 中国航空工业集团公司中国航空动力机械研究所, 湖南株洲 412002;
3. 北京理工大学宇航学院, 北京 100081

基金项目:

国家自然科学基金(51006100,51176012)

详细信息

作者简介:
伊卫林(1978-),男,黑龙江牡丹江人,副教授,博士,主要从事叶轮机械气动热力学研究.

通讯作者:
季路成(1970-),男,山东蓬莱人,教授,博士,主要从事叶轮机械气动热力学研究.Jilc@bit.edu.cn

中图分类号: V231.1
计量
- 文章访问数: 1155
- HTML浏览量: 82
- PDF量: 645
- 被引次数: 0
出版历程
- 收稿日期: 2014-01-22
- 刊出日期: 2015-07-28

New approach to improve the endwall flow of compressor—leading edge strake blade technique

1. School of Mechanical Engineering, Beijing Institute of Technology, Beijing 100081, China;
2. China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 412002, China;
3. School of Aerospace Engineering, Beijing Institute of Technology, Beijing 100081, China;

摘要

摘要: 针对压气机叶片进气存在端区附面层扭曲而造成局部大攻角问题,借鉴飞机边条翼理论,阐释了LESB(前缘边条叶片)概念,开发了对主叶片施加修型形成边条叶片的造型方法,从而形成LESB技术.为验证其技术效果,选取折转角为60°的NACA65扩压叶栅进行了LESB修型,在利用叶栅试验数据确认CFD模拟精度及掌握使用经验后,对主流区0°攻角、5°攻角带端区附面层扭曲来流条件下NACA65原型叶片及LESB流场进行了数值模拟,对其中流场结构、性能参数及作用机理进行了分析.结果表明:LESB技术能有效组织端区流场,改善压气机性能,15%叶高的LESB修型在0°攻角、5°攻角下改善区域分别可至30%和40%叶高.
- 压气机 /
- 叶轮机 /
- 前缘边条叶片 /
- 端区 /
- 分离与损失
Abstract: Targeting the high flow incidence angle induced by inlet endwall boundary layer skew in compressor, the LESB(leading edge strake blade) concept was elucidated with reference to the strake wing theory from aircraft. The modeling method was developed by adding leading edge strake to main blade, and the LESB technique was formed. In order to validate the effect of technique, the LESB modeling was applied to the NACA65 diffuser cascade with turning angle 60° after the numerical method was verified by cascade test data. The performance improvement was compared between original blade and LESB at 0° and 5° incidence angles with endwall boundary layer skew through the flow field structure, performance parameters and action mechanism. The results show that LESB technique can organize effectively the flow field near endwall and improve the compressor performance. The LESB modeling with 15% span can improve the performances of 30% and 40% span at 0° and 5° incidence angles separately.
- compressor /
- turbomachinery /
- leading edge strake blade /
- end wall /
- separation and loss

HTML

参考文献(17)

[1]	Lei V M,Spakovszky Z S,Greitzer E M.A criterion for axial compressor hub-corner stall[R].ASME Paper GT2006-91332,2006.
[2]	Roberts W B,Serovy G K,Sandercock D M.Modeling the 3-D flow effects on deviation angle for axial compressor middle stages[J].Journal of Engineering for Gas Turbines and Power,1986,108(1):131-137.
[3]	Wadia A R,Beacher B F.Three-dimensional relief in turbomachinery blading[J].Journal of Turbomachinery,1990,112(3):587-596.
[4]	Sauer H,Müller R,Vogeler K.Influencing the secondary losses in compressor cascades by a leading edge bulb modification at the endwall[R].ASME Paper 2000-GT-473,2000.
[5]	Hoeger M,Baier R D,Muller R.Impact of a fillet on diffusing vane endwall flow structure[R].The International Symposium on Transport Phenomena and Dynamics of Rotating Machinery,ISROMAC 2006-057,2006.
[6]	JI Lucheng,SHAO Weiwei,YI Weilin,et al.A model for describing the influences of SUC-EW dihedral angle on corner separation[C]//Proceedings of the ASME Turbo Expo 2007.Montreal,Germany:ASME,2007:219-228.
[7]	季路成,伊卫林,田勇,等.一种叶轮机械叶片与端壁融合设计方法:中国,ZL201010623606.2[P].2012-10-24.
[8]	季路成,田勇,李伟伟,等.叶身-端壁融合技术研究[J].航空发动机,2012,39(6):10-17. JI Lucheng,TIAN Yong,LI Weiwei,et al.Study on blended blade and endwall technique[J].Aeroengine,2012,2012,39(6):10-17.(in Chinese)
[9]	田勇,季路成,李伟伟,等.叶身端壁融合技术工况的适用性[J].航空动力学报,2013,28(8):1905-1913. TIAN Yong,JI Lucheng,LI Weiwei,et al.Applicability of blended blade and end wall under different operating conditions[J].Journal of Aerospace Power,2013,28(8):1905-1913.(in Chinese)
[10]	伊卫林,陈志民,季路成,等.离心压气机叶身/端壁融合技术应用初探[J].工程热物理学报,2014,35(2):256-261. YI Weilin,CHEN Zhimin,JI Lucheng,et al.Study on blended blade and end wall technique applied to centrifugal compressor[J].Journal of Engineering Thermophysics,2014,35(2):256-261.(in Chinese)
[11]	彭学敏.高负荷压气机叶栅叶身/端壁融合研究[D].北京:北京理工大学,2012.
[12]	Luckring J M.Aerodynamics of strake-wing interaction[J].Journal of Aircraft,1979,16(11):756-762.
[13]	吕志咏,马树威.利用前缘旋转控制边条翼外翼分离[J].航空学报,1996,17(5):513-517. LV Zhiyong,MA Shuwei.Control of separated a strake wing by moving surface[J].Acta Aeronautica et Astronautica Sinica,1996,17(5):513-517.(in Chinese)
[14]	季路成,伊卫林,唐方明,等.一种叶轮机端区叶片前缘边条修型方法:中国,201310739898.X[P].2013-12-26.
[15]	刘谋佶,吕志咏,丘成昊,等.边条翼及旋涡分离流[M].北京:北京航空学院出版社,1988.
[16]	张华良.采用叶片弯/掠及附面层抽吸控制扩压叶栅内涡结构的研究[D].哈尔滨:哈尔滨工业大学,2006. ZHANG Hualiang.Investigation on application of dihedral/swept blade and boundary layer suction to control vortex configurations in compressor cascades[D].Harbin:Harbin Intitute of Technology,2006.(in Chinese)
[17]	Khalid S A,Khalsa A S,Waitz I A,et al.Endwall blockage in axial compressors[J].Journal of Turbomachinery,1999,121(3):499-509.
