汽车发电机冷却风扇旋转噪声预测方法

王媛文; 董大伟; 闫兵

doi:10.13224/j.cnki.jasp.2015.07.024

汽车发电机冷却风扇旋转噪声预测方法

doi: 10.13224/j.cnki.jasp.2015.07.024

西南交通大学机械工程学院, 成都 610031

基金项目:

汽车噪声振动和安全技术国家重点实验室开放基金课题(NVHSKL-201007)

详细信息

作者简介:
王媛文(1984-),男,江苏淮安人,博士生,主要从事流体机械气动噪声研究.

中图分类号: V211.3;TB535;TK83
计量
- 文章访问数: 1088
- HTML浏览量: 135
- PDF量: 642
- 被引次数: 0
出版历程
- 收稿日期: 2014-03-06
- 刊出日期: 2015-07-28

Prediction method of vehicle alternator cooling fan rotation noise

School of Mechanical Engineering, Southwest Jiaotong University, Chengdu 610031, China

摘要

摘要: 以汽车发电机冷却风扇为对象,针对其修改叶片分布角度前后的旋转噪声预测问题,提出一套较精确且节约计算机时的预测方法.该方法结合了声类比法和矢量合成方法,首先,用大涡模拟(LES)和Ffowcs-Williams和Hawkings(FW-H)方程相结合的声类比方法对原风扇总噪声和主要阶次旋转噪声幅值进行预测;然后,针对只改变叶片分布角度情况下,提出一种矢量合成方法,用于对修改叶片分布前后主要阶次旋转噪声变化量的预测;最后,得到修改后主要阶次旋转噪声的幅值.计算和实验结果表明,原风扇总噪声最大预测误差4.3dB,第12阶和第18阶主要阶次旋转噪声幅值预测误差为1.24dB和4.26dB;修改后风扇第12阶和第18阶主要阶次旋转噪声分别变小了9.3dB和10.5dB,其变化量预测误差分别为0.36dB和0.43dB.结果表明,这一整套对修改前后风扇旋转噪声进行预测的方法是可行的,且大大节省计算时间,为风扇叶片周向分布角度设计提供了很好的依据.
- 风扇 /
- 旋转噪声预测 /
- 声类比方法 /
- 矢量合成方法 /
- 大涡模拟
Abstract: A set of accurate and time-saving methods were proposed to predict the rotation noise of vehicle alternator cooling fan. First, to predict the overall noise and main order noise magnitudes of the original fan, an acoustic analogy method combined with large eddy simulation (LES) and Ffows-Williams and Hawkings (FW-H) equations was applied. Second, to predict the change of rotation noise caused by blade angle modification, a vector composition method was proposed in case only the blade distribution angle was changed. The main order noise magnitudes of the modified fan were eventually calculated. Calculations and experimental results indicate that the maximum prediction error of the overall noise of the original fan is 4.3dB, and the prediction errors of main rotation noise magnitudes in orders 12 and 18 are 1.24dB and 4.26dB, respectively. The rotation noises of the modified fan in orders 12 and 18 are decreased by 9.3dB and 10.5dB, while the prediction errors of their sound pressure level (SPL) variations are 0.36dB and 0.43dB, respectively. The results show that this set of methods can effectively predict the rotation noise of fan, providing a significant guide to the design of blade distribution angles.
- fan /
- rotation noise prediction /
- acoustic analogy method /
- vector composition method /
- large eddy simulation(LES)

HTML

参考文献(20)

[1]	Schmitz S.Reducing pump noise in cooling tower applications[J].World Pumps,2004,456:24-29.
[2]	毛义军,祁大同,刘晓良,等.离心风机气动噪声的数值预测[J].西安交通大学学报,2009,43(3):65-69. MAO Yijun,QI Datong,LIU Xiaoliang,et al.Numerical prediction of aerodynamic noise for centrifugal fan[J].Journal of Xi'an Jiaotong University,2009,43(3):65-69.(in Chinese)
[3]	康强,左曙光,韩惠君.汽车空调系统离心风机气动噪声数值计算[J].江苏大学学报:自然科学版,2013,34(1):1-6. KANG Qiang,ZUO Shuguang,HAN Huijun.Simulation of aerodynamic noise from centrifugal fan of HVAC in automobile[J].Journal of Jiangsu University:Natural Science Edition,2013,34(1):1-6.(in Chinese)
[4]	Velarde-Suárez S,Hurtado-Cruz J P,Santolaria-Morros C.Numerical calculation of pressure fluctuations in the volute of a centrifugal fan[J].Journal of Fluids Engineering,2006,128:359-369.
[5]	Liu Q,Qi D,Mao Y.Numerical calculation of centrifugal fan noise[J].Journal of Mechanical Engineering Science,2006,220(8):1167-1177.
[6]	Goldstein M E.Aeroacoustics[M].New York:McGraw-Hill,1976.
[7]	Liu Q,Qi D,Tang H.Computation of aerodynamic noise of centrifugal fan using large eddy simulation approach,acoustic analogy,and vortex sound theory[J].Journal of Mechanical Engineering Science,2007,221(11):1321-1332.
[8]	Lowson M V.Reduction of compressor noise radiation[J].Journal of the Acoustical Society of America,1968,43(1):37-50.
[9]	Mellin R C,Sovran G.Controlling the tonal characteristics of the aerodynamic noise generated by fan rotors[J].Journal of Basic Engineering,1970,92(1):143-154.
[10]	Ewald D,Pavlovic A,Bollinger J G.Noise reduction by applying modulation principles[J].The Journal of the Acoustical Society of America,1971,49(5):1381-1385.
[11]	Duncan P E,Dawson B.Reduction of interactiontones from axial flow fans by suitable design of rotor configuration[J]. Journal of Sound and Vibration,1974,33(2):143-154.
[12]	黄俊雄,耿少娟,吴瑞,等.不同叶轮形式下离心泵噪声特性对比研究[J].声学学报,2010,35(2):113-118. HUANG Junxiong,GENG Shaojuan,WU Rui,et al.Comparison of noise characteristics in centrifugal pumps with different types of impellers[J].Acta Acustica,2010,35(2):113-118.(in Chinese)
[13]	孙晓峰.不等节距叶片风机气动声学特性的研究[J].北京航空学院学报,1986(4):137-145. SUN Xiaofeng.The aeroacoustic nature of unequally spaced fan[J].Journal of Beijing Institute of Aeronautics and Astronautics[J].1986(4):137-145.(in Chinese)
[14]	伍先俊,朱石坚,李志明.低A声级贯流风机叶片周向角不等距优化设计[J].应用声学,2004,23(6):40-44. WU Xianjun,ZHU Shijian,LI Zhiming.An optimization model by using unequal spacing blades for turbine noise reduction[J].Journal of Applied Acoustics,2004,23(6):40-44.(in Chinese)
[15]	毛义军,祁大同.叶轮机械气动噪声的研究进展[J].力学进展,2009,39(2):189-202. MAO Yijun,QI Datong.Review of aerodynamic noise in turbomachinery[J].Advances in Mechanics,2004,23(6):40-44.(in Chinese)
[16]	Kim W,Jeon W,Hur N,et al.Development of a low-noise cooling fan for an alternator using numerical and doe methods[J].International Journal of Automotive Technology,2011,12(2):307-314.
[17]	Neise W.Review of fan noise generation mechanisms and control methods[R].Seulis,France:International Symposium on Fan Noise,1992.
[18]	Lowson M V.The sound field for singularities in motion[J].Proceedings of the Royal Society of London:Series A Mathematical and Physical Sciences,1965,286(1407):559-572.
[19]	惠颖男.车用交流发电机噪声测试及降噪方法研究[D].成都:西南交通大学,2011. HUI Yingnan.Study on vehicle altornater noise testing and noise reduction method[D].Chengdu:Southwest Jiaotong University,2011.(in Chinese)
[20]	Tyler J M,Sofrin T G.Axial flow compressor noisestudies[R].SAE Technical Paper 620532,1962.
