Pumping speed of cryopump for xenon

LING Gui-long; WEI Li-jun; CAI Guo-biao

doi:10.13224/j.cnki.jasp.2015.07.026

Pumping speed of cryopump for xenon

doi: 10.13224/j.cnki.jasp.2015.07.026

1. School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
2. Unit 93469, the Chinese People's Liberation Army, Shijiazhuang 050000, China

基金项目:

National Defense Science and Industry Bureau the Sino Russian in Cooperation of Spaceflight

详细信息

中图分类号: V238;TB771
计量
- 文章访问数: 1142
- HTML浏览量: 82
- PDF量: 580
- 被引次数: 0
出版历程
- 收稿日期: 2014-01-21
- 刊出日期: 2015-07-28

Pumping speed of cryopump for xenon

1. School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
2. Unit 93469, the Chinese People's Liberation Army, Shijiazhuang 050000, China

Funds:

National Defense Science and Industry Bureau the Sino Russian in Cooperation of Spaceflight

摘要

摘要: The xenon pumping speed testing system of the large-diameter external cryopump was designed to meet the plume test requirements for prototype electric propulsion. The flowmeter method was utilized to measure the xenon pumping speed. The test results show that the averaged effective pumping speed of double-cryopumps is 52200L/s, and that of single-cryopump is 27100L/s. The pumping speed ratio of two configurations is 1.93. It can be concluded that the pumping speed has in linear relationship with the number of cryopump, and the coefficient is irrelevant with the gas type. The averaged effective pumping speed of xenon is less than its nominal pumping speed, and the averaged pumping efficiency is 0.83. Under the identical inflow conditions, the averaged effective pumping speed ratio of nitrogen is 0.53, slightly less than the theoretical pumping speed ratio of 0.55. Consequently, it can be concluded that results assessment of large-diameter external cryopump design index can guide the engineering application, showing certain reference significance.
- vacuum /
- plume /
- large-diameter external cryopump /
- xenon /
- pumping speed test
Abstract: The xenon pumping speed testing system of the large-diameter external cryopump was designed to meet the plume test requirements for prototype electric propulsion. The flowmeter method was utilized to measure the xenon pumping speed. The test results show that the averaged effective pumping speed of double-cryopumps is 52200L/s, and that of single-cryopump is 27100L/s. The pumping speed ratio of two configurations is 1.93. It can be concluded that the pumping speed has in linear relationship with the number of cryopump, and the coefficient is irrelevant with the gas type. The averaged effective pumping speed of xenon is less than its nominal pumping speed, and the averaged pumping efficiency is 0.83. Under the identical inflow conditions, the averaged effective pumping speed ratio of nitrogen is 0.53, slightly less than the theoretical pumping speed ratio of 0.55. Consequently, it can be concluded that results assessment of large-diameter external cryopump design index can guide the engineering application, showing certain reference significance.
- vacuum /
- plume /
- large-diameter external cryopump /
- xenon /
- pumping speed test
