基于非线性模型预测控制方法的航空发动机约束管理

杜宪; 郭迎清; 陈小磊

doi:10.13224/j.cnki.jasp.2015.07.031

基于非线性模型预测控制方法的航空发动机约束管理

doi: 10.13224/j.cnki.jasp.2015.07.031

西北工业大学动力与能源学院, 西安 710072

详细信息

作者简介:
杜宪(1989-),女,山西运城人,博士生,主要从事航空发动机模型预测控制与仿真研究.

中图分类号: V233.7
计量
- 文章访问数: 2198
- HTML浏览量: 244
- PDF量: 706
- 被引次数: 0
出版历程
- 收稿日期: 2014-03-04
- 刊出日期: 2015-07-28

Limit management of aircraft engine based on nonlinear model predictive control method

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 针对目前航空发动机控制系统普遍采用Min-Max选择逻辑处理输出量约束的方法具有一定保守性的问题,设计了非线性模型预测控制器,提出在非线性序列二次规划(SQP)算法中加入罚函数实现航空发动机输出量约束管理.仿真结果表明:无论是否触及输出量约束限,非线性模型预测控制器都比Min-Max控制逻辑动态响应更快,在达到限制线时更加明显,此时调节时间从1.16s下降到0.82s,且几乎没有超调量.
- 约束管理 /
- 航空发动机 /
- Min-Max选择 /
- 非线性模型预测控制 /
- 罚函数 /
- 序列二次规划
Abstract: In order to solve conservatism problem resulted from Min-Max selection structure currently implemented in aircraft engine control,a nonlinear model predictive controller was designed, by incorporating penalty functions into the nonlinear sequential quadratic programming (SQP) algorithm. Simulation results show that nonlinear predictive controller, whether outputs hit their limits or not, achieved faster response than Min-Max logic, particularly apparent when outputs reached their limits. In this case, the setting time is reduced from 1.16s to 0.82s, and almost no overshoot occurred.
- limit management /
- aircraft engine /
- Min-Max selection /
- nonlinear model predictive control /
- penalty function /
- sequential quadratic programming

HTML

参考文献(19)

[1]	Csank J,May R D,Litt J S,et al.Control design for a generic commercial aircraft engine[R].AIAA-2010-6629,2010.
[2]	May R D,Garg S.Reducing conservatism in aircraft engine response using conditionally active min-max limit regulators[R].NASA/TM-2012-217814,2012.
[3]	Thompson A,Hacker J,Cao C.Adaptive engine control in the presence of output limits[R].AIAA-2010-3492,2010.
[4]	Richter H.Multiple sliding modes with override logic:Limit management in aircraft engine controls[J].Journal of Guidance,Control,and Dynamics,2012,35(4):1132-1142.
[5]	Richter H,Litt J S.A novel controller for gas turbine engines with aggressive limit management[R].AIAA-2011-5857,2011.
[6]	Richter H.Advanced control of turbofan engines[M].New York:Springer,2012.
[7]	Fuller J W,Kumar A,Millar R C.Adaptive model based control of aircraft propulsion systems:status and outlook for naval aviation applications[R].ASME Paper GT2006-90241,2006.
[8]	孙健国,姚文荣.涡轴发动机非线性模型预测控制[J].航空学报,2008,29(4):776-780. SUN Jianguo,YAO Wenrong.Nonlinear model predictive control for turboshaft engine[J].Acta Aeronautica et Astronautica Sinica,2008,29(4):776-780.(in Chinese)
[9]	肖玲斐,黄向华.涡轴发动机自适应非线性预测控制[J].航空动力学报,2012,27(5):1194-1200. XIAO Lingfei,HUANG Xianghua.Adaptive nonlinear predictive control forturboshaft engine[J].Journal of Aerospace Power,2012,27(5):1194-1200.(in Chinese)
[10]	Diwanji V,Godbole A,Waghode N.Nonlinear model predictive control for thrust tracking of a gas turbine[R].Mumbai,India:IEEE International Conference on Industrial Technology,2006.
[11]	Mu J,Rees D,Liu G P.Advanced controller design for aircraft gas turbine engines[J].Control Engineering Practice,2005,13(8):1001-1015.
[12]	May R D,Csank J,Lavelle T M,et al.A high-fidelity simulation of a generic commercial aircraft engine and controller[R].AIAA-2010-6630,2010.
[13]	张书刚,郭迎清,陆军.基于GasTurb/MATLAB的航空发动机部件级模型研究[J].航空动力学报,2012,27(12):2850-2856. ZHANG Shugang,GUO Yingqing,LU Jun.Research on aircraft engine component-level models based on GasTurb/MATLAB[J].Journal of Aerospace Power,2012,27(12):2850-2856.(in Chinese)
[14]	吴君凤,郭迎清.发动机稳态与过渡态控制集成设计仿真验证[J].航空动力学报,2013,28(6):1436-1440. WU Junfeng,GUO Yingqing.Design and simulation of aero-engine steady-state and transient-state control integration[J].Journal of Aerospace Power,2013,28(6):1436-1440.(in Chinese)
[15]	Grüne L,Pannek J.Nonlinear model predictive control[M].London:Springer,2011.
[16]	Akpan V A,Hassapis G D.Nonlinear model identification and adaptive model predictive control using neural networks[J].International Society of Automation Transactions,2011,50(2):177-194.
[17]	陆军,郭迎清,陈小磊.线性拟合法建立航空发动机状态变量模型[J].航空动力学报,2011,26(5):1172-1177. LU Jun,GUO Yingqing,CHEN Xiaolei.Establishment of aero-engine state variable model based on linear fitting method[J].Journal of Aerospace Power,2011,26(5):1172-1177.(in Chinese)
[18]	张光澄.非线性最优化计算方法[M].北京:高等教育出版社,2005.
[19]	Randal T R,Kai F G,Neil H E,et al.Integrated in-flight fault detection and accommodation:a model-based study[R].ASME Paper GT2005-68300,2005.
