管道网络算法在涡轮内冷叶片换热计算中的应用

史亮; 谢鸣; 韩万金; 颜培刚

doi:10.13224/j.cnki.jasp.2015.09.006

管道网络算法在涡轮内冷叶片换热计算中的应用

doi: 10.13224/j.cnki.jasp.2015.09.006

哈尔滨工业大学能源科学与工程学院, 哈尔滨 150001

详细信息

作者简介:
史亮(1988-),男,宁夏固原人,博士生,主要从事叶轮机械气动热力学研究.

中图分类号: V232.4
计量
- 文章访问数: 1034
- HTML浏览量: 83
- PDF量: 728
- 被引次数: 0
出版历程
- 收稿日期: 2014-03-19
- 刊出日期: 2015-09-28

Application of pipeline network algorithm in turbine inner cooling blade heat transfer calculation

School of Energy Science and Engineering, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 基于管道网络算法的概念,开发了适用于内冷通道换热计算的程序,耦合外流场求解程序HIT3D,以Mark II叶片实验工况5411的结果做验证,传热系数和温度的计算值与实验值有着较好的吻合.在此基础上,对某型高压涡轮动叶内冷通道的复杂流路,建立流体网络计算模型.对原型结构吸力面一侧叶顶新增一排气膜孔,并对前部和后部蛇形通道的两组相邻通道间新增连接起平衡作用的贯通孔各3个.改型设计和原型都用开发的管道网络程序计算流动和换热参数.结果显示:在入口冷气边界条件相同条件下,相对原型,改型设计最高温度和平均温度都有10K以上的降低,叶片吸力面局部高温区集中的状况改有所善.改型设计效果在CFX全三维模拟中亦得到证实.
- 管道网络算法 /
- MarkII叶片实验验证.内冷通道 /
- 贯通孔 /
- 换热计算
Abstract: Based on the concept of pipeline network algorithm, the calculation procedure applicable to inner cooling channel heat exchange has been developed. Coupled with external flow field solver HIT3D, the Mark II blades condition 5411 test results were used to verify the validity of pipeline network procedure, showing that heat transfer coefficient and temperature had good agreement with the test values. On this basis, for the complex inner cooling channel flow paths of a certain type of high-pressure turbine rotor blade, a fluid network computing model was established. An exhaust film hole was added to the suction side of blade tip, and the two groups of adjacent passages of the front and rear serpentine channels were connected with three through tubes separately to balance the pressure. Retrofit design and prototype employed pipeline network procedure to calculate flow and heat transfer parameters. Results show that, under the same inlet boundary conditions of cooling air, the maximum temperature and the average temperature have decreased more than 10K as compared with prototype, and adverse conditions such as concentration of local high temperature on suction side have been improved. The improvement effect has been confirmed through full three-dimensional CFX simulation.
- pipeline network algorithm /
- Mark II blade test verification /
- inner cooling channel /
- perforation hole

HTML

参考文献(18)

[1]	董平,黄洪雁,冯国泰.高压燃气涡轮径向内冷叶片气热耦合的数值分析[J].航空动力学报,2008,23(2):201-207. DONG Ping,HUANG Hongyan,FENG Guotai.Conjugate heat transfer analysis of a high pressure turbine vane with radial internal cooling passages[J].Journal of Aerospace Power,2008,23(2):201-207.(in Chinese)
[2]	Han J C,Dutta S,Ekkad S.Gas turbine heat transfer and cooling technology[M].London,UK:Taylor & Francis,2001.
[3]	Chiyuki N,Kazuyoshi C,Shinsuke M.Research for advanced turbine cooling technology[J].Ishikawajima-Harima Heavy Industries,IHI Engineering Review,2005,38(2):63-69.
[4]	李广超,朱惠人,郭涛.旋转对内冷通道气膜孔流量系数的影响[J].推进技术,2006,27(5):394-398. LI Guangchao,ZHU Huiren,GUO Tao.Effects of rotating on the discharge coefficients of film holes in turbine blade[J].Journal of Propulsion Technology,2006,27(5):394-398.(in Chinese)
[5]	许宏博.某燃气涡轮高压级叶栅冷却结构设计及气热耦合数值模拟[D].哈尔滨:哈尔滨工业大学,2010. XU Hongbo.Cooling structures design and conjugated heat transfer calculation for high stage cascade of a gas turbine[D].Harbin:Harbin Institute of Technology,2010.(in Chinese)
[6]	迟重然.气冷涡轮叶片的传热设计[D].哈尔滨:哈尔滨工业大学, 2011. CHI Zhongran.Heat transfering design for air-cooled turbine blades[D].Harbin:Harbin Institute of Technology,2011.(in Chinese)
[7]	Peschiulli A,Coutandin D,Cioppo M D,et al.Development of a numerical procedure for integrated multidisciplinary thermal-fluid-structural analysis of an aeroengine turbine[R].ASME Paper GT2009-59875,2009.
[8]	陶智,侯升平,韩树军,等.流体网络法在发动机空气冷却系统设计中的应用[J].航空动力学报,2009,24(1):7-12. TAO Zhi,HOU Shengping,HAN Shujun,et,al.Study on application of fluid network into the design of air system in engine[J].Journal of Aerospace Power,2009,24(1):7-12.(in Chinese)
[9]	刘庆唐.高压天然气管网动态模拟与壅塞流动特性研究[D].济南:山东大学,2010. LIU Qingtang.Research on dynamic simulation and chocked flow characteristic of high-pressure natural gas network[D]. Jinan:Shandong University,2010.(in Chinese)
[10]	马壮,程礼.航空发动机滑油系统稳态压力模型研究[J].航空动力学报,2004,19(3):398-401. MA Zhuang,CHENG Li.Steady pressure model of the aeroengine oil system[J].Journal of Aerospace Power,2004,19(3):398-401.(in Chinese)
[11]	Majumdar A,Bailey J,Sarkar B.A generalized fluid system simulation program to model flow distribution in fluid networks[R].AIAA 97-3225,1997.
[12]	Schallhorn P A,Hass N E.Forward looking pressure regulator algorithm for improved modeling performance within the generalized fluid system simulation program[R].AIAA-2004-3667,2004.
[13]	Papalexandris M V.Feedback control of thermal systems modeled via the network approach[J].Journal of Dynamic Systems,Measurement and Control,2004,126(9):509-519.
[14]	侯升平,陶智,韩树军,等.流固网络一体化模拟方法探索及应用[J].航空动力学报,2010,25(3):33-38. HOU Shengping,TAO Zhi,HAN Shujun,et,al.Simulation approach to the fluid-thermal network and the application[J].Journal of Aerospace Power,2010,25(3):33-38.(in Chinese)
[15]	王松,王新军,俞茂铮.燃气轮机空气冷却系统建模及计算分析[J].燃气轮机技术,2010,23(4):33-37. WANG Song,WANG Xinjan,YU Maozheng.Calculations and analysis of a gas turbine air cooling system[J].Gas Turbine Technology,2010,23(4):33-37.(in Chinese)
[16]	Chupp R E,Helms H E.Evaluation of internal heat-transfer coefficients for impingement-cooled turbine airfoils[J].Journal of Aircraft,1969,6(3):203-208.
[17]	Metzger D E,Berry R A,Bronson J P.Developing heat transfer in rectangular duct with staggered array of short pin fins[J]. Journal of Heat Transfer,1982,104(4):700-706.
[18]	迟重然,温风波,王松涛,等.涡轮动叶冷却结构设计方法Ⅱ:管网计算[J].工程热物理学报,2011,32(6):35-38. CHI Zhongran,WEN Fengbo,WANG Songtao,et,al.Cooling structure design for turbine blades Ⅱ:pipe-net calculation[J].Journal of Engineering Thermophysics,2011,32(6):35-38.(in Chinese)
