正庚烷液滴在微细直管中的燃烧特性实验

姚荣; 李军伟; 邱佐祯; 黄景怀; 王宁飞

doi:10.13224/j.cnki.jasp.2015.09.011

正庚烷液滴在微细直管中的燃烧特性实验

doi: 10.13224/j.cnki.jasp.2015.09.011

北京理工大学宇航学院, 北京 100081

基金项目:

国家自然科学基金(50906004)

详细信息

作者简介:
姚荣(1989-),男,甘肃张掖人,硕士生,主要从事发动机燃料燃烧研究.

中图分类号: V219
计量
- 文章访问数: 1122
- HTML浏览量: 121
- PDF量: 670
- 被引次数: 0
出版历程
- 收稿日期: 2014-03-10
- 刊出日期: 2015-09-28

Experiment on combustion characteristics of n-heptane droplets in micro-tube

School of Aerospace Engineering, Beijing Institute of Technology, Beijing 100081, China

摘要

摘要: 为了解微细直管对液滴形成和燃烧稳定性的影响,采用正庚烷作为燃料在内径为4mm的石英直管中的进行了实验研究.其结果显示:首先在不加热时,容易形成液滴,正庚烷体积流量小于40μL/min 时,火焰稳定性受液滴滴落的影响较大,液滴的蒸发主要受到空气体积流量影响下的火焰位置的影响;大于40μL/min时,液膜形成,火焰受液滴滴落影响不大.其次,管壁加热温度为180℃时,正庚烷体积流量低于60μL/min时难以形成液滴,大于60μL/min时液滴滴落后不形成液膜,液滴的蒸发受空气流速的影响较大,在液滴滴落以及空气流速的影响下,微燃烧器温度的变化对燃料的蒸发产生更大的影响,富燃较贫燃更易形成连续的火焰.空气流速大小对管壁温度影响明显,空气流速越小,管壁温度越高,液滴蒸发速率越大.
- 微尺度燃烧 /
- 稳定性 /
- 蒸发 /
- 正庚烷液滴 /
- 外部加热
Abstract: To understand the effect of micro-tube on the droplet formation and combustion stability, the following researches were performed by using the n-heptane as fuel in 4mm internal diameter quartz tube. Firstly, without heating, the stability of the flame and quartz tube drips was studied. The results showed that without heating, quartz tube was easy to form droplets, and when the n-heptane volume flow rate was lower than 40μL /min, the flame stability was influenced by dripping easily, the evaporation rate of the droplets was mainly affected by the flame position under the influence of the effect of air volume flow rate; when the fuel volume flow rate was larger than 40μL/min, the flame stability was not affected easily by the dripping of droplet due to the formation of liquid film. Secondly, the influences of heating on the droplet formation and the combustion characteristic were studied. It was found difficult to form droplets when the n-heptane volume flow rate was lower than 60μL/min, and when the n-heptane volume flow rate was greater than 60μL/min, the droplet could drip, and film didn't appear when the wall temperature was 180℃. Droplet evaporation was greatly influenced by air velocity; under the influence of air velocity and the droplet dripping, the temperature of micro burner had a greater impact on evaporation rate of droplet. The flame was more easily formed under fuel-rich condition than fuel-lean condition. Hence, air velocity has strong impact on the tube wall temperature, the lower air velocity means the higher wall temperature, the higher evaporating rate of fuel droplet and lower droplets dripping frequency.
- micro-scale combustion /
- stability /
- evaporation /
- n-heptane droplets /
- external heating

HTML

参考文献(24)

[1]	JU Yiguang,Maruta K.Microscale combustion:technology development and fundamental research[J].Progress in Energy and Combustion Science,2011,37(6):669-715.
[2]	Maruta K.Micro and mesoscale combustion[J].Proceedings of the Combustion Institute,2011,33(1):125-150.
[3]	万建龙,范爱武,刘毅,等.固体材料对微型钝体燃烧器吹熄极限的影响[J].化工学报,2014,65(3):1012-1017. WAN Jianlong,FAN Aiwu,LIU Yi,et al.Effects of solid material on blow-off limit in micro bluff body combustor[J].CIESC Journal,2014,65(3):1012-1017.(in Chinese)
[4]	London A P,Ayon A A,Epstein A H,et al.Microfabrication of a high pressure bipropellant rocket engine[J].Sensors and Actuators A:Physical,2001,92(1/2/3):351-357.
[5]	Kim N I,Kato S,Kataoka T,et al.Flame stabilization and emission of small Swiss-roll combustors as heaters[J].Combustion and Flame,2005,141(3):229-240.
[6]	Maruta K,Kataoka T,Kim N I,et al.Characteristics of combustion in a narrow channel with a temperature gradient[J].Proceedings of the Combustion Institute,2005,30(2):2429-2436.
[7]	LI Junwei,ZHONG Beijing.Experimental investigation on heat loss and combustion in methane/oxygen micro-tube combustor[J].Applied Thermal Engineering,2008,28(7):707-716.
[8]	王国锋,钟北京,唐皇哉.微细通道中甲烷与氧气的预混燃烧[J].燃烧科学与技术,2006,12(2):97-100. WANG Guofeng,ZHONG Beijing,TANG Huangzai.Micro methane-oxygen premixed combustion in micro-scale tube[J].Journal of Combustion Science and Technology,2006,12(2):97-100.(in Chinese)
[9]	Sirignano W A,Pham T K,Dunn-Rankin D.Miniature-scale liquid-fuel-film combustor[J].Proceedings of the Combustion Institute,2002,29(1):925-931.
[10]	Mikami M,Maeda Y,Matsui K,et al.Combustion of gaseous and liquid fuels in meso-scale tubes with wire mesh[J].Proceedings of the Combustion Institute,2013,34(2):3387-3394.
[11]	Abramzon B,Sirignano W A.Droplet vaporization model for spray combustion calculations[J].International Journal of Heat and Mass Transfer,1989,32(9):1605-1618.
[12]	Burger M,Schmehl R,Prommersberger K,et al.Droplet evaporation modeling by the distillation curve model:accounting for kerosene fuel and elevated pressures[J].International Journal of Heat and Mass Transfer,2003,46(23):4403-4412.
[13]	Hallett W L H,Clark N A.A model for the evaporation of biomass pyrolysis oil droplets[J].Fuel,2006,85(4):532-544.
[14]	Abou Al-Sood M M,Birouk M.A numerical study of the effect of turbulence on mass transfer from a single fuel droplet evaporating in a hot convective flow[J].International Journal of Thermal Sciences,2007,46(8):779-789.
[15]	Kitano T,Nishio J,Kurose R,et al.Effects of ambient pressure,gas temperature and combustion reaction on droplet evaporation[J].Combustion and Flame,2014,161(2):551-564.
[16]	ZHOU Zhifu,WANG Guoxiang,CHEN Bin,et al.Evaluation of evaporation models for single moving droplet with a high evaporation rate[J].Powder Technology,2013,240:95-102.
[17]	黄勇,林宇震.燃烧与燃烧室[M].北京:北京航空航天大学出版社,2006.
[18]	孙慧娟,张海滨,白博峰.高温燃气中单个液滴的蒸发特性[J].西安交通大学学报,2008,42(7):833-837. SUN Huijuan,ZHANG Haibin,BAI Bofeng.Evaporation investigation of single droplet in high temperature fuel gas[J].Journal of Xi'an Jiaotong University,2008,42(7):833-837.(in Chinese)
[19]	Lefebvre A.Atomization and sprays[M].New York:CRC Press,1988.
[20]	Sazhin S S,Abdelghaffar W A,Sazhina E M,et al.Models for droplet transient heating:effects on droplet evaporation,ignition,and break-up[J].International Journal of Thermal Sciences,2005,44(7):610-622.
[21]	Chin J,Lefebvre A.The role of the heat-up period in fuel drop evaporation[R].AIAA 83-0068,1983.
[22]	Poling B E,Praustiz J M,O'connel J P.The properties of gases and liquids[M].New York:McGraw-Hil,2000.
[23]	Ludwig E E.Applied process design for chemical and petrochemical plants:Volume 2[M].Houston:Gulf Professional Publishing,1997.
[24]	Incropera F P,Lavine A S,DeWitt D P.Fundamentals of heat and mass transfer[M].New York:John Wiley and Sons,2011.
