非结构网格限制器研究

李芳; 孙唯哲; 刘鑫; 徐金秀

doi:10.13224/j.cnki.jasp.2015.09.013

非结构网格限制器研究

doi: 10.13224/j.cnki.jasp.2015.09.013

江南计算技术研究所, 江苏无锡 214083

基金项目:

国家重点基础研究发展计划(2014CB744100)

国家高技术研究发展计划(2012AA01A306)

详细信息

作者简介:
李芳 (1980-),女,山西长治人,助理研究员,博士,研究方向为高性能计算技术.

中图分类号: V21;TN401
计量
- 文章访问数: 1551
- HTML浏览量: 74
- PDF量: 635
- 被引次数: 0
出版历程
- 收稿日期: 2014-01-16
- 刊出日期: 2015-09-28

Research on limiters of unstructured grid

Jiangnan Institute of Computing Technology, Wuxi Jiangsu 214083, China

摘要

摘要: 研究了6种限制器形式及其参数计算方法,其中新的自适应VenkatakrishnanM限制器能够根据当地流场特征自动调节参数从而实现不同区域不同特性.数值试验表明:非结构网格限制器对邻居集合选择方法较敏感,其中共面法比共点法精度高约15%;高马赫数时压缩型限制器比耗散型限制器计算精度高约10%~40%;参变量算法中,方向梯度法得到的流场比增量法平滑;自适应VenkatakrishnanM限制器能够模拟复杂超声速流动.
- 限制器 /
- 非结构网格 /
- 自适应 /
- 方向梯度法 /
- 超声速
Abstract: Six limiters and methods of their parameters were researched, of which the adaptive VenkatakrishnanM limiter was able to balance the compression and dissipation of limiter by changing parameters adaptively. Numerical computations show that, limiters of unstructured grid are susceptible to neighbor set methods, and the common-face method has about 15% higher precision than the common-node one; under conditions of high Mach number, the compressive limiters have about 10%-40% higher precision than the dissipative ones; flow fields computed with the direction gradient method are more smooth than the augment method; the adaptive VenkatakrishnanM limiter is able to simulate complex supersonic flows.
- limiters /
- unstructured grid /
- adaptive /
- direction gradient method /
- supersonic

HTML

参考文献(16)

[1]	赵慧勇.超燃冲压整体发动机并行数值模拟[D].四川绵阳:中国空气动力研究与发展中心,2005. ZHAO Huiyong.Parallel numerical simulations of the whole scramjet engine[D].Mianyang Sichuan:China Aerodynamics Research and Development Center,2005.(in Chinese)
[2]	王兰.超燃冲压发动机整机非结构网格并行数值模拟研究[D].四川绵阳:中国空气动力研究与发展中心,2007. WANG Lan.Parallel numerical simulations of the whole scramjet engine flowfields on unstructured grids[D].Mianyang Sichuan:China Aerodynamics Research and Development Center,2007.(in Chinese)
[3]	王保国,李荣先.非结构网格生成方法的改进及气膜冷却三维静子流场的求解[J].航空动力学报,2001,16(3):232-237. WANG Baoguo,LI Rongxian.Improvement for unstructured grid generation and calculations of three-dimensional turbulent flow around turbine stator blade rows with film cooling e[J].Journal of Aerospace Power,2001,16(3):232-237.(in Chinese)
[4]	汪银乐.高精度两步TVD格式的构造及数值检验[J].航空动力学报,2006,21(6):1043-1047. WANG Yinle.Structure and numerical simulation of high order two steps scheme[J].Journal of Aerospace Power,2006,21(6):1043-1047.(in Chinese)
[5]	James D,Kannepalli O C,Brinckman K,et al.Scramjet propulsive flowpath prediction improvements using recent modeling upgrades[R].AIAA-2005-432,2005.
[6]	LIU Zhining,Ramakrishnan S V.Aeroheating prediction using the hybrid flow solver ICAT[R].AIAA-2002-2936,2002.
[7]	Kodera M,Sunami T.Numerical analysis of scramjet combusting flows by unstructured hybrid grid method[R].AIAA-2000-0886,2000.
[8]	Mack A,Steelant J,Karl S,et al.Mixing and combustion enhancement in a generic combustion chamber[R].AIAA-2006-8134,2006.
[9]	Ingenito A,Bruno C,Giacomazzi E,et al.Supersonic combustion:modelling and simulations[R].AIAA-2006-8035,2006.
[10]	Kouchi T,Mitani T,Kodera M,et al.Numerical experiments of scramjet combustion with boundary-layer bleeding[R].AIAA-2003-7038,2003.
[11]	Mark A,Hannemann V.Validation of the unstructured DLR-TAU code for hypersonic flow[R].AIAA-2002-3111,2002.
[12]	Lehr H F.Experiments on shock-induced combustion[J].Aeronautica Acta,1972,17(4):589-597.
[13]	Soetrisno M,Imay S T.Simulation of the flow field of a ram accelerator[R].AIAA 91-1915,1991.
[14]	Imlay S T,Roberts D W,Soetrisno M,et al.Nonequilibrium thermo-chemical calculations using a diagonal implicit scheme[R].AIAA 91-0468,1991.
[15]	Evans J S,Schexnayder C J,Jr.Influence of chemical kinetics and unmixedness on burning in supersonic hydrogen flames[J].AIAA Journal,1980,18(2):130-136.
[16]	Rodriguez C G,White J A,Riggins D W.Three-dimensional effects in modeling of dual-mode scramjets[R].AIAA-2000-3704,2000.
