部分平均Navier-Stokes方法模拟超声速斜面空腔流动

罗大海; 阎超; 王小永

doi:10.13224/j.cnki.jasp.2015.09.015

部分平均Navier-Stokes方法模拟超声速斜面空腔流动

doi: 10.13224/j.cnki.jasp.2015.09.015

北京航空航天大学航空科学与工程学院, 北京 100191

详细信息

作者简介:
罗大海(1986-),男,湖南邵阳人,博士生,主要从事湍流数值模拟研究.

中图分类号: V211
计量
- 文章访问数: 1156
- HTML浏览量: 138
- PDF量: 547
- 被引次数: 0
出版历程
- 收稿日期: 2014-03-17
- 刊出日期: 2015-09-28

Partially averaged Navier-Stokes method for simulation of supersonic flow over a ramped-cavity

School of Aeronautic Science and Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 采用部分平均Navier-Stokes (PANS)方法对超声速斜面空腔流动进行了数值模拟研究,评估其对于超声速非定常湍流模拟的性能,并与雷诺平均N-S(RANS),脱体涡模拟(DES)的计算结果及实验数据进行对比.研究表明:模化湍动能比例全场可变的PANS方法预测的速度、壁面压力和摩擦力系数分布与DES的结果非常接近,都与实验值吻合得较好,优于RANS的计算结果;非定常雷诺平均N-S(URANS)计算的自由剪切层近乎为二维稳态的,而DES和PANS方法可以求解出更为丰富的流动结构;模化湍动能比例全场统一的PANS方法虽然可以求解出相比RANS更多尺度的流动结构,但在近壁区不能回归到RANS模型,预测的湍流边界层的速度型偏离对数律,后续的流动计算也偏离实验数据.
- 超声速流动 /
- 斜面空腔 /
- 模化湍动能比例 /
- 脱体涡模拟 /
- 部分平均Navier-Stokes方法
Abstract: Partially averaged Navier-Stokes (PANS) model was adopted to numerically investigate the supersonic ramped-cavity flow. The objective of current study is to assess the capability of PANS method in the prediction of unsteady supersonic turbulent flow. Comparison of PANS, Reynolds averaged Navier-Stokes (RANS) and detached eddy simulation (DES) results with the available experimental data shows that: (1) velocity profiles, wall-pressure and skin-friction coefficient distributions predicted by PANS model with variable unresolved-to-total ratio of kinetic energy are consistent with DES results; and (2) both of PANS results with variable unresolved-to-total ratio of kinetic energy and DES results are in good agreement with the experimental data and superior to those predicted by RANS; and (3) unsteady Raynolds averaged Navier-Stokes (URANS) model predicts two dimensional steady geometries of free shear layer, while DES and PANS resolve more abundant flow structures; and (4) PANS model with constant unresolved-to-total ratio of kinetic energy cannot return to RANS model in the near-wall region despite it can resolve more scales of motion compared with RANS; and the predicted velocity profiles of upstream turbulent boundary layer mismatch the log law, thus downstream flow simulation deviates a lot from the experiment.
- supersonic flow /
- ramped-cavity /
- unresolved-to-total ratio of kinetic energy /
- detached eddy simulation /
- partially averaged Navier-Stokes method

HTML

参考文献(23)

[1]	Fan T C,Tian M,Edwards J R.Validation of a hybrid Reynolds-averaged large-eddy simulation method for simulating cavity flameholder configurations[R].AIAA 2001-2929,2001.
[2]	Pope S B.Turbulent flows[M].Cambridge:Cambridge University Press,2000.
[3]	Kravchenko A G,Moin P,Moser R.Zonal embedded grids for numerical simulations of wall-bounded turbulent flows[J].Journal of Computational Physics,1996,127(2):412-423.
[4]	高瑞泽,阎超.LES/RANS混合方法对超声速底部流动的应用[J].北京航空航天大学学报,2011,37(9):1095-1099. GAO Ruize,YAN Chao.LES/RANS hybrid method for supersonic axisymmetric base flow[J].Journal of Beijing University of Aeronautics and Astronautics,2011,37(9):1095-1099.(in Chinese)
[5]	Forsythe J R,Squires K D,Wurtzler K E,et al.Detached-eddy simulation of the F-15E at high alpha[J].Journal of Aircraft,2004,41(2):193-200.
[6]	Spalart P R,Jou W-H,Strelets M,Allmaras S R,et al.Comments on the feasibility of LES for wings and on a hybrid RANS/LES approach[R].Ruston,Louisiana,U.S.A:Advances in DNS/LES,Proceedings of the First AFOSR International Conference on DNS/LES,1997.
[7]	Menter F R,Kuntz M,Bender R.A scale-adaptive simulation model for turbulent flow predictions[R].AIAA 2003-0767,2003.
[8]	Girimaji S S,Srinivasan R,Jeong E.PANS turbulence model for seamless transition between RNAS and LES:fixed point analysis and preliminary results[R].Honolulu,Hawaii,U.S.A:4th ASME/JSME Joint Fluid Engineering Conference,2003.
[9]	Schiestel R,Dejoan A.Towards a new partially integrated transport model for coarse grid and unsteady turbulent flow simulations[J].Theoretical and Computational Fluid Dynamics,2005,18(6):443-468.
[10]	Horstman C C,Settles G S,Williams D R,et al.A reattaching free shear layer in compressible turbulent flow[J].AIAA Journal,1982,20(1):79-85.
[11]	Girimaji S S,Abdol-Hamid K S.Partially-averaged Navier Stokes model for turbulence:implementation and validation[R].AIAA 2005-502,2005.
[12]	Girimaji S S.Partially-averaged Navier-Stokes model for turbulence:a Reynolds-averaged Navier-Stokes to direct numerical simulation bridging method[J].Journal of Applied Mechanics,2006,73(3):413-421.
[13]	Lakshmipathy S,Girimaji S S.Partially averaged Navier-Stokes (PANS) method for turbulence simulations:flow past a circular cylinder[J].Journal of Fluids Engineering,2010,132:121202.1-121202.9.
[14]	Lakshmipathy S,Reyes D A,Girimaji S S.Partially averaged Navier-Stokes method:modeling and simulation of low Reynolds number effects in flow past a circular cylinder[R].AIAA 2011-3107,2011.
[15]	Basu D,Hamed A,Das K.Assessment of partially averaged Navier-Stokes (PANS) multiscale model in transonic turbulent separated flows[C]//Proceedings of 5th Joint ASME/JSME Fluids Engineering Conference.San Diego,California:ASME,2007:1451-1459.
[16]	Krajnovi Dć S,Lárusson R,Basara B.Superiority of PANS compared to LES in predicting a rudimentary landing gear flow with affordable meshes[J].International Journal of Heat and Fluid Flow,2012,37:109-122.
[17]	Lakshmipathy S,Togiti V.Assessment of alternative formulations for the specific-dissipation rate in RANS and variable-resolution turbulence models[R].AIAA 2011-3978,2011.
[18]	Menter F R.Two-equation eddy-viscosity turbulence models for engineering applications[J].AIAA Journal,1994,32(8):1598-1605.
[19]	Menter F R,Kuntz M,Langtry R.Ten years of industrial experience with the SST turbulence model[M]//Hanjalic' K,Nagano Y,Tummers M.Turbulence,heat and mass transfer 4.New York:Begell House,Incorporation,2003.
[20]	Strelets M.Detached eddy simulation of massively separated flows[R].AIAA 2001-0879,2001.
[21]	Baurle R A,Tam C J,Edwards J R,et al.Hybrid simulation approach for cavity flows:blending,algorithm,and boundary treatment issues[J].AIAA Journal,2003,41(8):1463-1489.
[22]	Fan C,Xiao X,Edwards J R,et al.Hybrid large-eddy/Reynolds-averaged Navier-Stokes simulations of shock-separated flows[J].Journal of Spacecraft and Rockets,2004,41(6):897-906.
[23]	Frendi A,Tosh A,Girimaji S.Flow past a backward-facing step:comparison of PANS,DES and URANS results with experiments[J].International Journal for Computational Methods in Engineering Science and Mechanics,2007,8(1):23-38.
