强迫振动下超声速混合层的掺混特性

张冬冬; 谭建国; 吕良; 王前程

doi:10.13224/j.cnki.jasp.2015.09.017

强迫振动下超声速混合层的掺混特性

doi: 10.13224/j.cnki.jasp.2015.09.017

国防科学技术大学航天科学与工程学院高超声速冲压发动机技术重点实验室, 长沙 410073

基金项目:

国家自然科学基金(11272351,91441121)

详细信息

作者简介:
张冬冬(1990-),男,江苏泰州人,硕士生,主要从事高超声速推进技术的研究.zhangdd0902@163.com

中图分类号: V211.7
计量
- 文章访问数: 1382
- HTML浏览量: 140
- PDF量: 541
- 被引次数: 0
出版历程
- 收稿日期: 2015-03-04
- 刊出日期: 2015-09-28

Mixing characteristics of supersonic mixing layer induced by forced vibration

Science and Technology on Scramjet Laboratory, College of Aerospace Science and Engineering, National University of Defense Technology, Changsha 410073, China

摘要

摘要: 利用实验研究与数值仿真相结合的方法,对强迫振动下对流马赫数为0.22的超声速混合层的掺混特性进行了分析,采用动量混合、雷诺应力以及标量混合指标对超声速混合层的掺混效率进行评估.研究结果表明:强迫振动对超声速混合层的掺混特性有重要影响.与无振动下相比,强迫振动使混合层的失稳位置提前,卷起的展向涡尺度变大,加快上下两层流动的混合.同时,强迫振动下,动量混合和标量混合更加充分.振动频率为4500Hz时,雷诺应力峰值提高约48%,薄平板后缘下游160mm处,动量厚度增长120%.
- 超声速混合层 /
- 强迫振动 /
- 掺混特性 /
- 动量混合 /
- 雷诺应力 /
- 标量混合
Abstract: Through combining an experimental study with numerical simulation, an analysis of mixing characteristics of a supersonic mixing layer was carried out, which was influenced by forced vibration under the condition of convective Mach number 0.22. The indexes of momentum mixing, Reynolds stress and scalar mixing were adopted to assess the mixing efficiency of supersonic mixing layer. The results show that forced vibration has an important effect on the mixing efficiency. Compared with no vibration, forced vibration advances the instability position of mixing layer and enlarges the scales of rolled-up spanwise vortices, which can promote the mixing of upper and lower streams. Meanwhile, with forced vibration, both momentum and scalar are more fully mixed. The peak value of Reynolds stress increases by about 48% when the vibration frequency is 4500Hz and the momentum thickness increases by 120% at 160mm position downstream the trailing edge of thin metal plate.
- supersonic mixing layer /
- forced vibration /
- mixing characteristics /
- momentum mixing /
- Reynolds stress /
- scalar mixing

HTML

参考文献(18)

[1]	Ribault C L.Large eddy simulation of passive scalar in compressible mixing layers[J].International Journal of Heat and Mass Transfer,2008,51(13/14):3514-3524.
[2]	Sankaran V,Menon S.LES of scalar mixing in supersonic mixing layers[J].Proceedings of the Combustion Institute,2005,30(2):2835-2842.
[3]	刘世杰,潘余,刘卫东.超燃冲压发动机支板喷射燃料的燃烧过程试验[J].航空动力学报,2009,24(1):55-59. LIU Shijie,PAN Yu,LIU Weidong.Experimental study on the combustion and flow process in a scramjet with strutinjector[J].Journal of Aerospace Power,2009,24(1):55-59.(in Chinese)
[4]	张弯洲,乐嘉陵,田野,等.超燃发动机混合效率评估方法探讨[J].航空动力学报,2012,27(9):1958-1966. ZHANG Wanzhou,LE Jialing,TIAN Ye,et al.Evalution methods of the fuel mixing efficiency for scramjet[J].Journal of Aerospace Power,2012,27(9):1958-1966.(in Chinese)
[5]	Clemens N T,Mungal M G.Two-and three-dimensional effects in the supersonic mixing layer[J].AIAA Journal,1992,30(4):973-981.
[6]	Olsen M G,Dutton J C.Planar velocity measurements in a weakly compressible mixing layer[J].Journal of Fluid Mechanics,2003,486(7):51-77.
[7]	Papamoschou D,Roshko A.The compressible turbulent shear layer:an experimental study[J].Journal of Fluid Mechanics,1988,197(4):453-477.
[8]	Freund J B,Lele S K,Moin P.Compressibility effects in a turbulent annular mixing layer:Part 1 turbulence and growth rate[J].Journal of Fluid Mechanics,2000,421(1):229-267.
[9]	Fernando E M,Menon S.Mixing enhancement in compressible mixing layers:an experimental study[J].AIAA Journal,2012,31(2):278-285.
[10]	程晓军,范育新,蔡迪,等.一种波瓣混合器超级燃烧室的掺混特性[J].航空动力学报,2014,29(7):1606-1614. CHENG Xiaojun,FAN Yuxin,CAI Di,et al.Mixing characteristics of hyperburner with a lobed mixer[J].Journal of Aerospace Power,2014,29(7):1606-1614.(in Chinese)
[11]	曹伟,周恒.二维超音速混合层增强混合的研究[J].中国科学:A辑,2002,32(2):150-157. CAO Wei,ZHOU Heng.The enhancement of the mixing of a 2D supersonic mixing layer[J].Science China:Series A,2002,32(2):150-157.(in Chinese)
[12]	Williams A M,Griffiths D J,Vlachos P P.Laminar mixing using oscillating cantilevered ionic polymer actuators[J].Sensors and Actuators,2009,153(1):105-113.
[13]	Zhao Y X,Yi S H,Tian L F,et al.Supersonic flow imaging via nanoparticles[J].Science China:Series E,2009,52(10):3640-3648.
[14]	Zhao Y X,Yi S H,Tian L F,et al.Density field measurement and approximate reconstruction of supersonic mixing layer[J].Chinese Science Bulletin,2010,55(19):2004-2009.
[15]	Tian L F,Yi S H,Zhao Y X,et al.Study of density field measurement based on NPLS technique in supersonic flow[J].Science China:Series G,2009,52(9):1357-1363.
[16]	Kim Y H,Cierpka C,Wereley S T.Flow field around a vibrating cantilever:coherent structure eduction by continuous wavelet transform and proper orthogonal decomposition[J].Journal of Fluid Mechanics,2011,669(1):584-606.
[17]	Mattner T W.Large-eddy simulations of turbulent mixing layers using the stretched-vortex model[J].Journal of Fluid Mechanics,2011,671(1):507-534.
[18]	Barre S,Quine C,Dussauge J P.Compressibility effects on the structure of supersonic mixing layers experimental results[J].Journal of Fluid Mechanics,1994,259(4):47-78.
