考虑应变依赖性的硬涂层复合结构有限元分析

孙伟; 刘营; 李晖

doi:10.13224/j.cnki.jasp.2015.09.021

考虑应变依赖性的硬涂层复合结构有限元分析

doi: 10.13224/j.cnki.jasp.2015.09.021

东北大学机械工程与自动化学院, 沈阳 110819

基金项目:

中央高校基本科研业务费专项资金(N140301001)

国家自然科学基金(51375079)

详细信息

作者简介:
孙伟(1975-),男,辽宁营口人,副教授,博士,主要从事机械系统动力学及振动控制研究.

中图分类号: V231.92;TH113.1
计量
- 文章访问数: 1012
- HTML浏览量: 95
- PDF量: 635
- 被引次数: 0
出版历程
- 收稿日期: 2014-03-18
- 刊出日期: 2015-09-28

Finite element analysis of hard-coating composite structure considering strain-dependent characteristic

School of Mechanical Engineering and Automation, Northeastern University, Shenyang 110819, China

摘要

摘要: 在简要介绍硬涂层材料应变依赖性的基础上,推导了用迭代有限元法求解硬涂层复合结构动力学特性的原理,进一步提出了求解硬涂层复合结构固有频率和振动响应的计算流程,即由振动响应值来修正硬涂层材料参数,进而迭代求解硬涂层复合结构的动力学参数.最后以一个涂敷MgO+Al₂O₃硬涂层的悬臂梁为例进行了实例研究,在考虑MgO+Al₂O₃硬涂层材料应变依赖性的基础上,获得了不同激励幅度下悬臂梁的固有频率和振动响应,并与线性计算结果进行了比对.结果表明;该硬涂层复合结构悬臂梁具有软式非线性,同时,对应于不同的激励幅度,迭代计算获得的共振响应相对于线性计算值减少了29%~48%,说明硬涂层材料的应变依赖性会进一步增强硬涂层的减振效果.
- 应变依赖性 /
- 硬涂层 /
- 复合结构 /
- 有限元分析 /
- 迭代计算
Abstract: On the basis of introducing the strain-dependent characteristic of hard-coating material, the dynamic characteristic solution theory of iterative finite element method was derived. Moreover, the processes of calculating natural frequency and vibration response were presented, which can be summarized as: the hard coating material parameters were corrected by the vibration response, and then the dynamic parameters were solved by the iterative solution program. At last, a cantilever beam coated with MgO+Al₂O₃ hard coating was chosen to display the effectiveness of the proposed method. Considering the strain-dependent characteristic of MgO+Al₂O₃ hard coating, the natural frequency and vibration response were obtained under different exciting levels and also compared with the relative values obtained by linear calculation. Results show that the hard-coating composite structure cantilever beam displays the soft nonlinear phenomenon, and the resonance responses reduce by 29%-48% compared with linear calculation correspondingly to different exciting levels. This shows that the strain-dependent characteristic of hard-coating material can promote the effect of vibration reduction.
- strain-dependent characteristic /
- hard-coating /
- composite structure /
- finite element analysis /
- iterative calculation

HTML

参考文献(15)

[1]	Limarga A M,Duong T L,Gregori G,et al.High-temperature vibration damping of thermal barrier coating materials[J].Surface and Coatings Technology,2007,202(4):693-697.
[2]	胡浩炬,张建宇,杨晓光,等.等离子热障涂层失效机理的数值分析研究[J].航空动力学报,2010,25(5):1085-1091. HU Haoju,ZHANG Jianyu,YANG Xiaoguang,et al.Numerical study of failure mechanisms on plasma sprayed thermal barrier coatings[J].Journal of Aerospace Power,2010,25(5):1085-1091.(in Chinese)
[3]	Grzesik W,Zalisz Z,Nieslony P.Friction and wear testing of multilayer coatings on carbide substrates for dry machining applications[J].Surface and Coatings Technology,2002,155(1):37-45.
[4]	Hassani S,Bielawski M,Beres W,et al.Predictive tools for the design of erosion resistant coatings[J].Surface and Coatings Technology,2008,203(3):204-210.
[5]	Blackwell C,Palazotto A,George T J,et al.The evaluation of the damping characteristics of a hard coating on titanium[J].Shock and Vibration,2007,14(1):37-51.
[6]	Ivancic F,Palazotto A.Experimental considerations for determining the damping coefficients of hard coatings[J].Journal of Aerospace Engineering,2005,18(1):8-17.
[7]	Torvik P J.A slip damping model for plasma sprayed ceramics[J].Journal of Applied Mechanics,2009,76(6):061018.1-061018.8.
[8]	Lauwagie T,Lambrinou K,Patsias S,et al.Resonant-based identification of the elastic properties of layered materials:application to air-plasma sprayed thermal barrier coatings[J].NDT&E international,2008,41(2):88-97.
[9]	Patsias S,Saxton C,Shipton M.Hard damping coatings:an experimental procedure for extraction of damping characteristics and modulus of elasticity[J].Materials Science and Engineering:A,2004,370(1):412-416.
[10]	Reed S A,Palazotto A N,Baker W.Determining material properties of nonlinear materials from transient response[R].ASME Paper IMECE2007-43518,2007.
[11]	Sun W,Li H,Han Q.Identification of mechanical parameters of hard-coating materials with strain-dependence[J].Journal of Mechanical Science and Technology,2014,28(1):81-92.
[12]	Tassini N,Patsias S,Lambrinou K.Ceramic coatings:a phenomenological modeling for damping behavior related to microstructural features[J].Materials Science and Engineering:A,2006,442(1):509-513.
[13]	Abu Al-Rub R K,Palazotto A N.Micromechanical theoretical and computational modeling of energy dissipation due to nonlinear vibration of hard ceramic coatings with microstructural recursive faults[J].International Journal of Solids and Structures,2010,47(16):2131-2142.
[14]	Torvik P J.Determination of mechanical properties of non-linear coatings from measurements with coated beams[J].International Journal of Solids and Structures,2009,46(5):1066-1077.
[15]	Reed S A,Palazotto A N,Baker W P.An experimental technique for the evaluation of strain dependent material properties of hard coatings[J].Shock and Vibration,2008,15(6):697-712.
