跨声压气机内确定应力耦合问题研究

赵军; 刘宝杰

doi:10.13224/j.cnki.jasp.2015.09.024

跨声压气机内确定应力耦合问题研究

doi: 10.13224/j.cnki.jasp.2015.09.024

赵军¹,
刘宝杰²

1. 中国民用航空飞行学院航空工程学院, 四川广汉 618307;
2. 北京航空航天大学能源与动力工程学院, 北京 100191

详细信息

作者简介:
赵军(1980-),男,安徽淮北人,高级工程师,博士,主要从事叶轮机械内复杂流动研究.

中图分类号: V231.3
计量
- 文章访问数: 955
- HTML浏览量: 107
- PDF量: 541
- 被引次数: 0
出版历程
- 收稿日期: 2014-03-19
- 刊出日期: 2015-09-28

Research on problem of deterministic stress coupling in transonic compressor

ZHAO Jun¹,
LIU Bao-jie²

1. Aviation Engineering Institute, Civil Aviation Flight University of China, Sichuan Guanghan 618307, China;
2. School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 基于三维定常Denton程序发展了二维定常、二维非定常、三维非定常计算程序,以二维跨声压气机叶栅、三维跨声单级压气机近失速点为算例,进行确定应力耦合问题的研究.结果表明:在确定应力应用到时均方程的耦合处理中存在一些因素导致时均方程的解和非定常解的时均值有一定偏差,它们分别是空间差分离散引入的误差、黏性相关项引入的误差、掺混面处理引入的误差.在多排耦合问题中掺混面的处理方式至关重要,对耦合计算结果有较大的影响,简单的掺混面处理并不能获得理想的效果.
- 确定应力 /
- 跨声 /
- 压气机 /
- 非定常计算 /
- 时间平均
Abstract: Two-dimensional steady/unsteady, and three-dimensional unsteady calculation programs were developed based on three-dimensional steady Denton program. Researches on deterministic stress coupling were conducted on two cases:two-dimensional transonic compressor cascade and three-dimensional single-stages transonic compressor near stall point. It is found that, there are some deviations from time-averaged value of solution and unsteady solution of time-averaged equations when deterministic stresses are applied to coupling processing. The deviation of the coupling error originated from three sources: spatial difference discrete,viscosity correlation terms,mixing-plane processing. In multi-row coupling cases,the influences of mixing-plane are vital. It has a vital effect on the coupling calculation results. The simple mixing-plane processing can't get an ideal effect.
- deterministic stress /
- transonic /
- compressor /
- unsteady calculation /
- time-averaged

HTML

参考文献(20)

[1]	Adamczyk J J.Model equation for simulation flows in multistage turbomachinery[R].ASME Paper 85-GT-226,1985.
[2]	Adamczyk J J.A model for closing the invisid form of the average passage equation system[J].Journal of Turbinemachinery,1986,108(2):180-186.
[3]	Rhie C M,Gleixner A J,Spear D A,et al.Development and application of a multistage Navier-Stokes solver:Part 1 multistage modeling using body-forces and deterministic stresses[R].ASME Paper 95-GT-342,1995.
[4]	Sondak D L,Dorney D J,Davis R L.Modeling turbomachinery unsteadiness with lumped deterministic stresses[R].AIAA 96-2570,1996.
[5]	Van de Wall A J,Kadambi J R,Adamczyk J J.A transport model for the deterministic stresses associated with turbomachinery blade row interaction[J].Journal of Turbomachinery,2000,122(4):593-603.
[6]	季路成.轴流式叶轮机转子/静子干扰非定常流动探索研究[D].北京,北京航空航天大学,1998. JI Lucheng.Research on rotor/stator interaction in axial turbomachinery[D].Beijing:Beijing University of Aeronautics and Astronautics,1998.(in Chinese)
[7]	高丽敏.离心压缩机级内流动的数值分析与实验研究[D].西安,西安交通大学,2002. GAO Limin.Numerical and experimental research on centrifugal compressor[D].Xi'an:Xi'an Jiaotong University,2002.(in Chinese)
[8]	Giles M.An approach for multistage calculations incorporating unseadiness[R].ASME Paper 92-GT-282,1992.
[9]	He L,Ning W.Efficient approach for analysis of unsteady viscous flows in turbomachines[J].AIAA Journal,1998,36(11):2005-2012.
[10]	Chen T,Vasanthakumar P,He L.Analysis of unsteady blade row interaction using nonlinear harmonic approach[J].Journal of Propulsion and Power,2001,17(3):651-658.
[11]	Pechloff A,Laschka B.Small disturbance Navier-Stokes method:efficient tool for predicting unsteady air loads[J].Journal of Aircraft,2006,43(1):17-29.
[12]	Saiz G,Imregun M,Sayma A I.A multi-blade-row linearised analysis method for flutter and forced response predictions in turbomachinery[R]. ASME Paper GT2006-90789,2006.
[13]	Stridh M,Eriksson L E.Modeling unsteady flow effects in a 3D transonic compressor[R].ASME Paper GT2005-68149,2005.
[14]	Vilmin S,Lorrain E,Hirsch C,et al.Unsteady flow modeling across the rotor/stator interface using the nonlinear harmonic method[R].ASME Paper GT2006-90210,2006.
[15]	柳阳威,黄卫兵,刘宝杰.离心压气机确定应力场分析[J].航空动力学报,2008,23(3):534-540. LIU Yangwei,HUANG Weibing,LIU Baojie.Analysis of deterministic stresses in a centrifugal compressor[J].Journal of Aerospace Power,2008,23(3):534-540.(in Chinese)
[16]	高丽敏,李晓军,高杰,等.确定应力模型在离心压缩机级流场模拟的应用[J].机械工程学报,2011,47(2):166-172. GAO Limin,LI Xiaojun,GAO Jie,et al.Application of deterministic stresses model in simulation of centrifugal compressor stage flow field[J].Journal of Mechanical Engineering,2011,47(2):166-172.
[17]	刘波,王雷,黄建.非线性谐波法在双级对转压气机中的进一步校检[J].航空动力学报,2013,28(6):1333-1341. LIU Bo,WANG Lei,HUANG Jian.Further validation of NHM in two-stage counter-rotating compressor[J].Journal of Aerospace Power,2013,28(6):1333-1341.(in Chinese)
[18]	赵军,柳阳威,刘宝杰.NASA67级非定常流场的频域分析[J].航空动力学报,2007,22(8):1371-1377. ZHAO Jun,LIU Yangwei,LIU Baojie.Frequency-domain analysis of NASA67 unsteady flow field[J].Journal of Aerospace Power,2007,22(8):1371-1377.(in Chinese)
[19]	赵军,刘宝杰.非线性谐波法的进一步校验分析[J].航空动力学报,2008,23(4):680-686. ZHAO Jun,LIU Baojie.Application of nonlinear harmonic method in numerical simulation for turbomachinery[J].Journal of Aerospace Power,2008,23(4):680-686.(in Chinese)
[20]	Denton J D.The calculation of three-dimensional viscous flow through multistage turbomachines[J].Journal of Turbomachinery,1992,114(1):18-26.
