某涡扇发动机分布式控制系统设计与总线性能

田飞龙; 郭迎清; 李睿超; 姜彩虹

doi:10.13224/j.cnki.jasp.2015.09.029

某涡扇发动机分布式控制系统设计与总线性能

doi: 10.13224/j.cnki.jasp.2015.09.029

1. 西北工业大学动力与能源学院, 西安 71007;
2. 中国航空工业集团公司沈阳发动机设计研究所, 沈阳 110015

基金项目:

国家先进航空发动机技术研究计划

详细信息

作者简介:
田飞龙(1990-),男,陕西咸阳人,硕士生,主要从事航空发动机分布式研究.

中图分类号: V233.7
计量
- 文章访问数: 1657
- HTML浏览量: 153
- PDF量: 623
- 被引次数: 0
出版历程
- 收稿日期: 2014-03-10
- 刊出日期: 2015-09-28

Design of distributed control system and investigation on bus communication performance of a turbofan engine

1. School of Power and Energy, Northwestern Polytechnical University, Xi'an 71007;
2. Shenyang Engine Design and Research Institute, Aviation Industry Corporation of China, Shenyang 110015, China

摘要

摘要: 针对国内某型涡扇发动机,以该机目前采用的集中式FADEC为基础,依据地域分散原则,设计了一种发动机部分分布式控制系统结构,并对发动机控制系统中的传输信号进行了合理划分;对发动机采用分布式控制进行了总线通信需求分析;选择时间触发CAN总线作为发动机分布式控制系统通信总线,并进行了通信方案设计;利用TrueTime构建了分布式控制仿真系统,研究了网络时延、掉包对发动机性能的影响.研究表明:在250kbit/s和1Mbit/s带宽下,总线利用率分别为50%和12.34%,满足通信要求;250kbit/s带宽下所设计时间触发系统的网络诱导时延为12ms,高压转子转速上升时间延迟0.02s,而网络随机掉包使发动机响应明显变慢,设计时需要加以考虑.
- 涡扇发动机 /
- 分布式控制系统 /
- 数据集中器 /
- 总线通信 /
- 时延和掉包
Abstract: A partially distributed engine control system was designed based on the centralized FADEC (full authority digital engine control) of domestic turbofan engine by geographical distribution principle. A reasonable classification of various signals in the control system was presented. According to communication requirement assessment for distributed turbine engine control, Time-triggered CAN (controller area network) bus was determined as the engine area network and the communication strategy was designed. TrueTime was exploited to develop a distributed control system simulation. Impact of network delay and data dropout on the engine performance was studied. The results show that bus utilization is 50% at 250kbit/s and 12.34% at 1Mbit/s, which meets the communication requirement. The network-induced delay of the time-triggered system is 12ms. It prolongs the rise time of high pressure rotor speed for 0.02s. However, the engine response is significantly slower under the random packet dropout, which should be taken into account at the design phase.
- turbofan engine /
- distributed control system /
- data concentrator /
- bus communication /
- delay and packet dropout

HTML

参考文献(19)

[1]	Culley D E,Thomas R,Saus J.Concepts for distributed engine control[R].AIAA-2007-5709,2007.
[2]	孙健国.面向21世纪航空动力控制展望[J].航空动力学报,2001,16(2):98-102. SUN Jianguo.Prospects of the aeroengine control development in the early time of the 21st century[J].Journal of Aerospace Power,2001,16(3):98-102.(in Chinese)
[3]	郭迎清,章泓.航空发动机分布式控制系统综述[J].航空发动机,2003,29(3):52-55. GUO Yingqing,ZHANG Hong.Survey of the distributed control system for an aeroengine[J].Aeroengine,2003,29(3):52-55.(in Chinese)
[4]	Belapurkar R K,Yedavalli R K.Stability analysis of ARINC-825 based partially distributed aircraft engine control with transmission delays and packet dropouts[R].AIAA-2010-6675,2010.
[5]	Belapurkar R K,Yedavalli R K,Paluszewski P J.Design of set-point controller for partially distributed turboshaft engine with network faults[R].AIAA-2011-5858,2011.
[6]	彭靖波,谢寿生,武卫,等.航空发动机分布式控制系统指数稳定性分析[J].航空动力学报,2009,24(10):2362-2367. PENG Jingbo,XIE Shousheng,WU Wei,et al.Stability analyzation of aero-engine distributed control system[J].Journal of Aerospace Power,2009,24(10):2362-2367.(in Chinese)
[7]	Behbahani A,Tulpule B.Perspective for distributed intelligent engine controls of the future[R].AIAA-2010-6631,2010.
[8]	Leen G,Heffernan D.TTCAN:a new time-triggered controller area network[J].Microprocessors and Microsystems,2002,26(2):77-94.
[9]	Knueppel R.Standardization of CAN networks for airborne use through ARINC 825[R].Hambach:13th International CAN Conference,2012.
[10]	Yedavalli R K,Willett M,Behani A.The role of various real-time communication data bus for open system distributed engine control architectures for the future[R].AIAA-2011-6145,2011.
[11]	冯源,豆海利.CAN总线在航空领域应用的探讨[J].航空工程进展,2011(2):231-235. FENG Yuan,DOU Haili.Applicability of CAN bus in the aviation field[J].Advances in Aeronautical Science and Engineering,2011(2):231-235.(in Chinese)
[12]	李光耀,郭迎清,王海泉.基于CAN总线的航空发动机分布式控制系统通信研究[J].测控技术,2009,28(1):62-66,69. LI Guangyao,GUO Yingqing,WANG Haiquan.Communication research on CAN based distributed aero-engine control system[J].Measurement and Control Technology,2009,28(1):62-66,69.(in Chinese)
[13]	Thompson H A,Benitez-Perez H,Lee D,et al.A CAN bus-based safety-critical distributed aeroengine control systems architecture demonstrator[J].Microprocessors and Microsystems,1999,23(6):345-355.
[14]	关越,潘慕绚.基于DSP的航空发动机分布式控制TTCAN总线的节点设计[J].航空发动机,2013,39(4):61-66. GUAN Yue,PAN Muxuan.Design of TTCAN node for aeroengine distributed control system based on DSP[J].Aeroengine,2013,39(4):61-66.(in Chinese)
[15]	Tindell K,Burns A.Guaranteed message latencies for distributed safety-critical hard real-time control net works[R].Department of Computer Science,University of York,Report YCS229,1994.
[16]	曹万科,张天侠,周淑文,等.基于CAN与TTCAN的汽车整车分层控制网络及调度[J].东北大学学报:自然科学版,2007,28(11):1640-1643. CAO Wanke,ZHANG Tianxia,ZHOU Shuwen,et al.Automotive hierarchical control network based on TTCAN and CAN for entire cars and its scheduling strategy[J].Journal of Northeastern University:Natural Science,2007,28(11):1640-1643.(in Chinese)
[17]	Ohlin M,Henriksson D,Cervin A.TrueTime 1.5:reference manual[M].Sweden:Department of Automatic Control,Lund University,2007.
[18]	Schenato L,Sinopoli B,Franceschetti M,et al.Foundations of control and estimation over lossy networks[J].Proceedings of the IEEE,2007,95(1):163-187.
[19]	Henriksson E,Sandberg H,Johansson K H.Predictive compensation for communication outages in networked control systems[R].Cancun,Mexico:47th IEEE Conference on Decision and Control,2008.
