基于AMESim的隔舱式贮箱推进剂管理仿真研究

苏立超; 刘建勇; 章成亮; 石竟成

doi:10.13224/j.cnki.jasp.2015.09.030

基于AMESim的隔舱式贮箱推进剂管理仿真研究

doi: 10.13224/j.cnki.jasp.2015.09.030

中国航天科技集团公司中国运载火箭技术研究院空间物理重点实验室, 北京 100076

详细信息

作者简介:
苏立超(1985-),男,河北衡水人,工程师,硕士,主要研究方向为发动机总体设计、增压输送系统总体设计.

中图分类号: V434.1
计量
- 文章访问数: 1344
- HTML浏览量: 110
- PDF量: 517
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-03
- 刊出日期: 2015-09-28

Simulation research on compartmental tank propellant management based on AMESim

Science and Technology on Space Physics Laboratory, China Academy of Launch Vehicle Technology, China Aerospace Science and Technology Corporation, Beijing 100076, China

摘要

摘要: 通过多学科动力学建模方法研究,利用AMESim建立了隔舱式贮箱推进剂输送系统机械、液流与控制动力学模型,并对不同工况下推进剂输送系统动态特性进行数值仿真,获得了隔舱式贮箱推进剂动态变化、各个隔舱的推进剂消耗率及质心位移等结果.仿真结果显示隔舱总体布局与初始容积分配、隔舱连通结构、飞行轨迹等均对隔舱式贮箱推进剂动态变化产生影响,所建立的模型可应用于隔舱式贮箱总体及结构设计.
- 动态仿真 /
- 隔舱式贮箱 /
- AMESim模型 /
- 推进剂管理 /
- 质心计算
Abstract: According to the research on the method of multi-subjects dynamic modeling, an AMESim mechanical, hydraulic and control dynamic complicated model of propellant feed system based on the compartmental tank was established, and then numerical simulation was made on the dynamic characteristics of the propellant feed system under different working conditions. The results of dynamic change of the propellant, the comsumption rate and the centroid displacement of the propellant were obtained. The simulation results show that the dynamic change of the compartmental tank propellant is influenced by the compartments general layout, initial compartments volume, structure design, flight trajectory and etc, so the simulation model can provide guidance to improve compartmental tank overall and structure design.
- dynamic simulation /
- compartmental tank /
- AMESim model /
- propellant management /
- centroid calculation
