固体火箭发动机缺陷的ICT局部检测

陈庆贵; 卢洪义; 周源; 李慎; 李朋; 于光辉

doi:10.13224/j.cnki.jasp.2015.09.031

固体火箭发动机缺陷的ICT局部检测

doi: 10.13224/j.cnki.jasp.2015.09.031

1. 海军航空工程学院飞行器工程系, 山东烟台 264001;
2. 海军航空工程学院七系, 山东烟台264001;
3. 中国人民解放军 91206部队, 山东青岛 266108;
4. 海军航空工程学院青岛校区, 山东青岛 266041

基金项目:

国家自然科学基金(51005242)

详细信息

作者简介:
陈庆贵(1987-),男,山东莒南人,博士生,主要从事发动机测试理论与技术研究.

中图分类号: V435
计量
- 文章访问数: 1059
- HTML浏览量: 92
- PDF量: 532
- 被引次数: 0
出版历程
- 收稿日期: 2014-07-20
- 刊出日期: 2015-09-28

ICT local inspection of solid rocket motor's defects

1. Department of Airborne Vehicle Engineering, Naval Aeronautical and Astronautical University, Yantai Shandong 264001, China;
2. No.7 Department, Naval Aeronautical and Astronautical University, Yantai Shandong 264001, China;
3. Unit 91206, the Chinese People's Liberation Army, Qingdao Shandong 266108, China;
4. Qingdao Branch, Naval Aeronautical and Astronautical University, Qingdao Shandong 266041, China

摘要

摘要: 为了实现对固体火箭发动机缺陷的局部检测,提出了窄角扇束工业计算机断层扫描成像(ICT)检测固体火箭发动机缺陷的局部检测方案.采用平移/旋转扫描方式和只旋转扫描方式对固体火箭发动机缺陷进行局部检测.为了验证局部检测方案的有效性,利用窄角扇束ICT对某型固体火箭发动机进行局部检测,并利用卷积反投影算法和小波变换算法进行局部重建.结果表明:平移/旋转扫描方式适合窄角扇束ICT对固体火箭发动机缺陷进行局部检测,只旋转扫描方式不适合局部检测.由于利用局部缺陷区域外的投影数据,卷积反投影算法较小波变换算法的局部重建质量高.这对于提高固体火箭发动机缺陷的检测效率,降低检测成本具有重要意义.
- 固体火箭发动机 /
- 缺陷 /
- 窄角扇束ICT /
- 局部检测 /
- 卷积反投影 /
- 小波变换
Abstract: To inspect solid rocket motor's defects locally, local inspection scheme of solid rocket motor's defects was proposed for narrow fan-beam industrial computed tomography(ICT). Translation/rotation scan mode and rotation only scan mode were used to inspect solid rocket motor's defects locally. To demonstrate the effectiveness of local inspection scheme, narrow fan-beam ICT was used to inspect one solid rocket motor locally. Convolution backprojection algorithm and wavelet transform algorithm were applied to reconstruct ICT images locally. Results show that translation/rotation scan mode is effective for narrow fan-beam ICT to inspect solid rocket motor's defects locally, rotation only scan mode is not effective. For using projections outside the local defect area, the reconstructed image quality of convolution backprojection algorithm is better than that of wavelet transform algorithm. It is of great significance for improving the inspection efficiency of solid rocket motor's defects and for reducing the inspection cost.
- solid rocket motor /
- defect /
- narrow fan-beam ICT /
- local inspection /
- convolution backprojection /
- wavelet transform

HTML

参考文献(18)

[1]	卢洪义,杨兴根,孙有田.固体火箭发动机内部缺陷高分辨率检测[J].推进技术,2003,24(1):90-92. LU Hongyi,YANG Xinggen,SUN Youtian.High resolution inspecting investigation for inner defect of SRM[J].Journal of Propulsion Technology,2003,24(1):90-92.(in Chinese)
[2]	朱敏,于光辉,卢洪义,等.固体火箭发动机体空间缺陷精确定位方法[J].航空动力学报,2013,28(10):2364-2369. ZHU Min,YU Guanghui,LU Hongyi,et al.Defect accurate positioning method of solid rocket motor in volume space[J].Journal of Aerospace Power,2013,28(10):2364-2369.(in Chinese)
[3]	朱敏,卢洪义,从培胜,等.固体发动机CT检测中的一种缺陷识别方法[J].航空动力学报,2009,24(1):230-234. ZHU Min,LU Hongyi,CONG Peisheng,et al.A method of defect recognition in solid motor CT testing[J].Journal of Aerospace Power,2009,24(1):230-234.(in Chinese)
[4]	李涛,张乐,赵锴,等.固体火箭发动机缺陷分析及其无损检测技术[J].无损检测,2006,28(10):541-544. LI Tao,ZHANG Le,ZHAO Kai,et al.Analysis and nondestructive testing of defects for solid rocket motor[J].Nondestructive Testing,2006,28(10):541-544.(in Chinese)
[5]	艾春安,桑元,徐志高,等.基于X射线胶片的固体火箭发动机断面图像重建[J].无损检测,2011,33(3):1-4. AI Chun'an,SANG Yuan,XU Zhigao,et al.Solid rocket motor sectional view reconstruction from X-ray films[J].Nondestructive Testing,2011,33(3):1-4.(in Chinese)
[6]	唐庆明,张明.固体火箭发动机的装药缺陷及检测方法[J].飞航导弹,2006(7):52-54.
[7]	卢洪义,杨兴根,程卫平.小张角扇形射线束CT检测固体发动机局部缺陷[J].推进技术,2003,24(3):251-253. LU Hongyi,YANG Xinggen,CHENG Weiping.Local tomography inspecting investigation for inner crack of SRM[J].Journal of Propulsion Technology,2003,24(3):251-253.(in Chinese)
[8]	王飞.基于ICT的固体火箭发动机无损检测及成像技术研究[D].西安:西北工业大学,2005.
[9]	张卫贞.固体火箭发动机ICT局部重建算法研究[D].太原:中北大学,2009. ZHANG Weizhen.Research on local tomography algorithm of solid rocket engine based on ICT[D].Taiyuan:North University of China,2009.(in Chinese)
[10]	马有为.基于小波的图像重建扇束卷积反投影算法[D].北京:北京交通大学,2007.
[11]	叶海霞,王珏,瞿中.工业CT窄角扇束卷积反投影图像重建[J].微机发展,2003,13(9):11-12. YE Haixia,WANG Jue,QU Zhong.Image reconstruction of ICT in convolution backprojection algorithm with narrow fan-beam scan mode[J].Microcomputer Development,2003,13(9):11-12.(in Chinese)
[12]	Besson G.CT image reconstruction from fan-parallel data[J].Medical Physics,1999,26(3):415-426.
[13]	Dennerlein F,Noo F,Hornegger J,et al.Fan-beam filtered-backprojection reconstruction without backprojection weight[J].Physics in Medicine and Biology,2007,52(11):3227-3240.
[14]	薛少峰.基于小波变换的CT局部重建算法研究[D].沈阳:东北大学,2004. XUE Shaofeng.The research of wavelet-based local reconstruction algorithm[D].Shenyang:Northeastern University,2004.(in Chinese)
[15]	刘杰,李政,康克军,等.小波变换用于CT图像重建及处理研究[J].系统工程与电子技术,2002,24(2):80-83. LIU Jie,LI Zheng,KANG Kejun,et al.Study on CT image reconstruction and processing using wavelets[J].Systems Engineering and Electronics,2002,24(2):80-83.(in Chinese)
[16]	Farrokh R F,Ray L,Carlos A B,et al.Wavelet-based multiresolution local tomography[J].IEEE Transactions on Image Processing,1997,6(10):1412-1430.
[17]	陈庆贵,刘赵云,卢洪义,等.基于窄角扇束扫描的固体火箭发动机CT图像重建[J].固体火箭技术,2014,37(6):877-880. CHEN Qinggui,LIU Zhaoyun,LU Hongyi,et al.CT image reconstruction of solid rocket motor based on narrow fan beam san[J].Journal of Solid Rocket Technology,2014,37(6):877-880.(in Chinese)
[18]	杨兴根,陈宇杰.固体火箭发动机专用ICT机械扫描系统[J].推进技术,1999,20(6):106-108. YANG Xinggen,CHEN Yujie.ICT scan system for solid rocket motors[J].Journal of Propulsion Technology,1999,20(6):106-108.(in Chinese)
