斜齿行星齿轮传动系统振动模式与动载特性

林何; 王三民; 董金城

doi:10.13224/j.cnki.jasp.2015.09.032

斜齿行星齿轮传动系统振动模式与动载特性

doi: 10.13224/j.cnki.jasp.2015.09.032

西北工业大学机电学院, 西安 710072

基金项目:

国家高技术研究发展计划(2009AA04Z404)

详细信息

作者简介:
林何(1985-),男,湖北襄阳人,博士生,主要从事齿轮系统动力学研究.

中图分类号: V233.1;TH113.1
计量
- 文章访问数: 1315
- HTML浏览量: 86
- PDF量: 665
- 被引次数: 0
出版历程
- 收稿日期: 2014-02-27
- 刊出日期: 2015-09-28

Vibration mode and dynamical characteristics of helical planetary gear train

School of Mechanical Engineering, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 斜齿行星传动在高速重载场合中应用越来越广泛,其振动模式和动载特性研究对减振降噪设计具有重要意义.针对斜齿行星齿轮传动系统,建立了随动坐标系,推导了含陀螺效应的多自由度间隙非线性动力学方程,求解了系统的固有特性.结果表明:斜齿行星齿轮系统存在3种典型振动模式,即轴向平移-扭转耦合振动模式(重根数r=1),径向平移振动模式(重根数r=2)和行星轮振动模式(重根数r=N－3,N>3);综合考虑啮合刚度、齿侧间隙、综合误差和外载荷等激励作用,研究了啮合相位差和激励方式对动载系数的影响规律,结果表明计入啮合相位差时动载系数有所增大,当刚度波动系数ζ=1.723时,系统分岔为2周期次谐响应,随着激励参数的变化,内啮合较外啮合更快的进入混沌状态.
- 随动坐标系 /
- 陀螺效应 /
- 动载系数 /
- 啮合相位差 /
- 外激励
Abstract: Helical planetary gear transmission was applied more extensively in high-speed and heavy load situations, as the vibration mode and dynamic characteristic had significant influence on vibration and noise reduction. Targeting the helical planetary gear transmission system, co-moving coordinate system was conducted, the multi-degree of freedom nonlinear dynamical equations including gyroscopic effect and backlash was derived, and the natural characteristic of the system was solved. The results show that helical planetary gear train has three typical vibration modes: axial translational-rotational coupled vibration mode (multiplicity r=1), translational vibration mode (multiplicity r=2) and planet vibration mode(multiplicity r=N－3,N>3); in consideration of mesh stiffness, backlash, general errors and external load, influence laws of mesh phase difference and excitation ways to dynamical coefficient have been studied, showing that mesh phase difference makes the dynamical coefficient increase; when stiffness fluctuation coefficient ζ=1.723, the system is bifurcated into 2-period sub-harmonic response, with the changes of excitation parameters, internal engagement turning into the chaotic state is earlier than external engagement.
- co-moving coordinate system /
- gyroscopic effect /
- dynamical coefficient /
- mesh phase difference /
- external excitations

HTML

参考文献(18)

[1]	屈文涛.直升机动力旋翼系统及航空齿轮系统的振动研究[D].西安:西北工业大学,1995. QU Wentao.Study on helicopter rotor dynamic system and the vibration of the gear system[D].Xi'an:Northwestern Polytechnical University,1995.(in Chinese)
[2]	杨通强,宋轶民,张策,等.斜齿行星齿轮系统自由振动特性分析[J].机械工程学报,2005,41(7):50-55. YANG Tongqiang,SONG Yimin,ZHANG Ce,et al.Property analysis of free vibration of helical planetary gear trains[J].Journal of Mechanical Engineering,2005,41(7):50-55.(in Chinese)
[3]	Parker R G,Lin J.Mesh phasing relationships in planetary and epicyclic gears[J].Journal of Mechanical Design,2004,126(2):365-370.
[4]	Eritenel T,Parker R G.Modal properties of three-dimensional helical planetary gears[J].Journal of Sound and Vibration,2009,325(1):397-420.
[5]	Ambarisha V K,Parker R G.Suppression of planet mode response in planetary gear dynamics through mesh phasing[J].Journal of Vibration and Acoustics,2006,128(2):133-142.
[6]	Mark V D,Hines J A.Stationary transducer response to planetary-gear vibration excitation with non-uniform planet loading[J].Mechanical Systems and Signal Processing,2009,23(4):1366-1381.
[7]	孙智明,沈允文,李素有.封闭行星齿轮传动系统的扭振特性研究[J].航空动力学报,2001,16(2):163-166. SUN Zhimin,SHEN Yunwen,LI Suyou.A study on torsional vibration in an encased differential gear train[J].Journal of Aerospace Power,2001,16(2):163-166.(in Chinese)
[8]	李润方,王建军.齿轮系统动力学:振动、冲击、噪声[M].北京:科学出版社,1997.
[9]	Sondkar P,Kahraman A.A dynamic model of a double-helical planetary gear set[J].Mechanism and Machine Theory,2013,70(7):157-174.
[10]	郭家舜,王三民,刘海霞.某新型直升机传动系统弯-扭耦合振动特性研究[J].振动与冲击,2009,28(10):132-140. GUO Jiashun,WANG Sanmin,LIU Haixia.Lateral-torsional coupled vibration characteristics of transmission of a new type helicopter[J].Journal of Vibration and Shock,2009,28(10):132-140.(in Chinese)
[11]	秦大同,肖正明,王建宏.基于啮合相位分析的盾构机减速器多级行星齿轮传动动力学特性[J].机械工程学报,2011,47(23):20-29. QIN Datong,XIAO Zhengming,WANG Jianhong.Dynamic characteristics of multi-stage planetary gears of shield tunneling machine based on planet mesh phasing analysis[J].Journal of Mechanical Engineering,2011,47(23):20-29.(in Chinese)
[12]	史志伟.行星传动啮合相位计算方法研究[J].科学计算与工程,2011,11(22):5286-5289. SHI Zhiwei.A method to determine the mesh phasing in planetary gear train[J].Science Technology and Engineering,2011,11(22):5286-52894.(in Chinese)
[13]	Tamminana V K,Kahraman A,Vijayakar S.A study of the relationship between the dynamic factors and the dynamic transmission error of spur gear pairs[J].Journal of Mechanical Design,2007,129(1):75-84.
[14]	Sweeney P J,Randall R B.Gear transmission error measurement using phase demodulation[J].Journal of Mechanical Engineering Science,1996,210(3):201-213.
[15]	Velex P,Ajmi M.Dynamic tooth loads and quasi-static transmission errors in helical gears:approximate dynamic factor formulae[J].Mechanism and Machine Theory,2007,42(11):1512-1526.
[16]	张锁怀,沈允文,董海军,等.转速和不平衡质量对齿轮拍击振动的影响[J].航空动力学报,2003,18(1):197-203. ZHANG Suohuai,SHEN Yunwen,DONG Haijun,et al.The influence of speed and mass unbalance on dynamic characteristics of a gear-rattling system[J].Journal of Aerospace Power,2003,18(1):197-203.(in Chinese)
[17]	朱自冰,朱如鹏,鲍和云.两级星型齿轮传动系统非线性动力学研究[J].航空动力学报,2007,22(11):1963-1970. ZHU Zibing,ZHU Rupeng,BAO Heyun.Non-linear dynamic study of 2-stage gear train[J].Journal of Aerospace Power,2007,22(11):1963-1970.(in Chinese)
[18]	崔亚辉,刘占生,叶建槐,等.内外激励作用下含侧隙的齿轮传动系统的分岔和混沌[J].机械工程学报,2010,46(11):129-136. CUI Yahui,LIU Zhansheng,YE Jianhuai,et al.Bifurcation and chaos of gear transmission system with clearance subjected to internal and external excitation[J].Journal of Mechanical Engineering,2010,46(11):129-136.(in Chinese)
