基于滑窗包络线法辨识复合圆柱壳结构的模态阻尼

李晖; 薛鹏程; 许卓; 申鹏飞; 闻邦椿

doi:10.13224/j.cnki.jasp.2015.12.003

基于滑窗包络线法辨识复合圆柱壳结构的模态阻尼

doi: 10.13224/j.cnki.jasp.2015.12.003

东北大学机械工程与自动化学院, 沈阳 110819

基金项目:

国家自然科学基金(51505070,51375079)

国家重大科学仪器设备开发专项(2013YQ470765)

详细信息

作者简介:
李晖(1982-),男,内蒙古丰镇人,讲师,博士后,主要从事阻尼减振技术研究.

中图分类号: V231;TB535
计量
- 文章访问数: 1113
- HTML浏览量: 5
- PDF量: 518
- 被引次数: 0
出版历程
- 收稿日期: 2014-11-12
- 刊出日期: 2015-12-28

Identification of modal damping of composite cylindrical shell based on sliding-envelop method

School of Mechanical Engineering and Automation, Northeastern University, Shenyang 110819, China

摘要

摘要: 由于复合圆柱壳阻尼机理的复杂性,目前还没有通用而有效的方法辨识该类结构的模态阻尼,因此提出一种基于滑窗包络线法的模态阻尼测试方法.首先,详细说明了滑窗包络线法测试复合圆柱壳阻尼的原理和总体思路;然后,提出了具体的测试复合圆柱壳结构模态阻尼的流程;最后,以局部涂敷约束层阻尼材料的复合圆柱壳为研究对象,对其阻尼特性进行了测试,并讨论了激励幅度对模态阻尼的影响.测试结果表明,所提出的方法获得的前5阶阻尼结果对应的方差最大不超过0.02%,具有较好的可重复性,从而确保具有较高的测试精度.
- 滑窗包络线法 /
- 复合圆柱壳 /
- 模态阻尼 /
- 阻尼测试 /
- 阻尼特性
Abstract: Due to the complexity of the damping mechanism of composite cylindrical shell, there is no practical and effective method to identify such structural damping.A modal damping test method based on sliding-envelop method was proposed.First, damping test principle and overall plan of sliding-envelop method for modal damping of composite cylindrical shell were clarified in details.Then, its test procedures in the actual test of modal damping of composite cylindrical shell were summarized.At last, a composite cylindrical shell coated with constrained layer damping materials was used as a study object, and its modal damping were well identified and the relation between external excitation level and modal damping was discussed.Test results showed that the maximum variance obtained by the proposed method corresponding to the first five orders damping result was less than 0.02%, and the damping results had good repeatability, thus ensuring high testing precision.
- sliding-envelop method /
- composite cylindrical shell /
- modal damping /
- damping test /
- damping characteristics

HTML

参考文献(18)

[1]	Sainsbury M G,Masti R S.Vibration damping of cylindrical shells using strain-energy-based distribution of an add-on viscoelastic treatment[J].Finite Element in Analysis and Design,2007,43(3):175-192.
[2]	Ramesh T C,Ganesan N.Vibration and damping analysis of cylindrical shells with constrained damping treatment:a comparison of three theories[J].Journal of Vibration and Acoustics,1995,117(2):213-219.
[3]	Ramesh T C,Ganesan N.Orthotropic cylindrical shells with a viscoelastic core:a vibration and damping analysis[J].Journal of Sound and Vibration,1994,175(4):535-555.
[4]	洪杰,郭宝亭,朱梓根.高速转动壳体行波振动实验研究[J].航空动力学报,1998,13(4):390-394. HONG Jie,GUO Baoting,ZHU Zigen.Experimental investigation on travelling wave vibration of high-speed rotation shell[J].Journal of Aerospace Power,1998,13(4):390-394.(in Chinese)
[5]	曾亮,李琳.用于篦齿封严装置的阻尼套筒减振性能研究[J].航空动力学报,2009,24(3):670-676. ZENG Liang,LI Lin.Performance of damping-sleeve for vibration control in labyrinth air seals[J].Journal of Aerospace Power,2009,24(3):670-676.(in Chinese)
[6]	Vinson J R,Sierakowski R L.The behavior of structures composed of composite materials[M].Dordrecht,Netherlands:Springer Science and Business Media,2006.
[7]	汤彬,孙志刚,高希光,等.单向陶瓷基复合材料阻尼计算方法[J].航空动力学报,2010,25(10):2217-2222. TANG Bin,SUN Zhigang,GAO Xiguang,et al.Analytical method for estimating the damping in unidirectional ceramic matrix composites[J].Journal of Aerospace Power,2010,25(10):2217-2222.(in Chinese)
[8]	张大义,洪杰,任德新.碳陶双基体复合材料壳结构的振动分析[J].航空动力学报,2011,26(5):1142-1147. ZHANG Dayi,HONG Jie,REN Dexin.Dynamical analysis on shell structure made of C/C-SiC composite materials[J].Journal of Aerospace Power,2011,26(5):1142-1147.(in Chinese)
[9]	Assarar M,Zouari W,Sabhi H,et al.Evaluation of the damping of hybrid carbon-flax reinforced composites[J].Composite Structures,2015,132:148-154.
[10]	Magalhães F,Cunha Á,Caetano E,et al.Damping estimation using free decays and ambient vibration tests[J].Mechanical Systems and Signal Processing,2010,24(5):1274-1290.
[11]	翁震平,席亦农.相关分析在结构阻尼比时域衰减法测量中的应用[J].船舶力学,2009,13(4):657-661. WENG Zhenping,XI Yinong.Correlation analysis in the application of structural damping ratio time-domain attenuation measurement[J].Ship Mechanics,2009,13(4):657-661.(in Chinese)
[12]	陈奎孚,焦群英.半功率点法估计阻尼比的误差分析[J].机械强度,2002,24(4):510-514. CHEN Kuifu,JIAO Qunying.Half power point method to estimate error analysis of damping ratio[J].Mechanical Strength,2002,24(4):510-514.(in Chinese)
[13]	Jafari A A,Khalili S M R,Tavakolian M.Nonlinear vibration of functionally graded cylindrical shells embedded with a piezoelectric layer[J].Thin-Walled Structures,2014,79(3):8-15.
[14]	Qatu M S,Sullivan R W,Wang W.Recent research advances on the dynamic analysis of composite shells:2000-2009[J].Composite Structures,2010,93(1):14-31.
[15]	Wang X D,Li N,Wang T,et al. Dynamic characteristic testing for MEMS micro-devices with base excitation[J].Measurement Science and Technology,2007,18(6):1740-1746.
[16]	吴家驹,苏华昌,王晓晖.基础激励结构的试验模态分析[J].强度与环境,2010,37(4):28-35. WU Jiaju,SU Huachang,WANG Xiaohui.Based on experimental modal analysis of incentive structure[J].Strength and Environment,2010,37(4):28-35.(in Chinese)
[17]	Madhan M G,Rani G A,Sridhar K,et al.Design and fabrication of transmission line based wideband band pass filter[J].Procedia Engineering,2012,30:646-653.
[18]	Duan J,Oweis I S.Dyadic wavelet analysis of PDA signals[J].Soil Dynamics and Earthquake Engineering,2005,25(7):661-677.
