Effect of operating conditions on turbine rotor blade creep life
-
摘要: 基于Larson-Miller蠕变寿命理论,定量地分析了高压涡轮相对转速、飞行高度H、径向温度分布系数(RTDF)偏离设计状态时对涡轮转子叶片蠕变寿命的影响.结果表明:以叶根位置来看,高压涡轮相对转速从参考状态减小2%,导致叶片温度减小6%,叶片应力减小6%,使蠕变寿命因子从1增大到186.H增大导致叶片温度增大、叶片应力减小.从叶根位置来看,在温度和应力的综合作用下,H偏离参考状态时,蠕变寿命因子减小;而远离叶根位置,温度对蠕变寿命因子的影响越来越大,蠕变寿命因子随着H的减小而增大.RTDF减小导致叶片温度减小,使蠕变寿命因子随之增大.Abstract: Based on Larson-Miller parameter, the effects of high pressure turbine relative rotational speed, flight altitude H and radial temperature distribution factor (RTDF) on turbine rotor blade creep life were analyzed quantitatively when these parameters deviated from design condition. The results show that when high pressure turbine relative rotational speed is reduced by 2% from its reference value, both the blade temperature and blade stress decrease by 6%. The creep factor increases substantially from 1 to around 186 in terms of blade root. With the increase of H, blade temperature increases and blade stress decreases. In terms of blade root, when H is deviated from its reference value, the creep factor is reduced under the combined action of temperature and stress. Far away from the blade root, the effect of temperature is more important and creep factor increases with the decrease of H. When RTDF reduces, the blade temperature decreases and creep factor increases.
-
Key words:
- turbine rotor blade /
- blade temperature /
- blade stress /
- creep /
- life estimation
-
[1] Toufexis D.Aircraft maintenance and development of a performance-based creep life estimation for aero engine[D].Cranfield,England:Cranfield University,2012. [2] Eshati S,Laskaridis P.Investigation into the effects of operating conditions and design parameters on the creep life of high pressure turbine blades in a stationary gas turbine engine[J].Mechanics and Mechanical Engineering,2011,15(3):237-247. [3] Ghafir M F A,LI Yinguang,Li Y G,et al.Impact of operating and health conditions on areo gas turbine hot section creep life using a creep factor approach[R].ASME Paper 2010-GT-22332,2010. [4] Ghafir M F A.Performance based creep life estimation for gas turbines application[D].Cranfield,England:Cranfield University,2011. [5] Eshati S,Abu A,Laskaridis P,et al.Influence of water-air ratio on the heat transfer and creep life of a high pressure gas turbine blade[J].Applied Thermal Engineering,2013,60(1/2):334-347. [6] Eshati S,Laskaridis P,Haslam A,et al.The influence of humidity on the creep life of a high pressure gas turbine blade:Part Ⅱ case study[R].ASME Paper 2012-GT-69462,2012. [7] 刘葆华,黄金泉.基于高压涡轮叶片寿命损耗的航空发动机功率控制[J].航空动力学报,2013,28(12):2836-2841. LIU Baohua,HUANG Jinquan.Aero-engine power control based on life consumption of high pressure turbine blade[J].Journal of Aerospace Power,2013,28(12):2836-2841.(in Chinese) [8] Naeem M.Implications of a military turbofan's high-pressure turbine erosion for blade's creep-life consumption[J].Journal of Propulsion and Power,2010,26(1):177-182. [9] Horlock J H,Torbidoni L.Turbine blade cooling:the blade temperature distribution[J].Journal of Power and Energy,2006,22(4):343-353. [10] 斯库巴切夫斯基.航空燃气涡轮发动机零件结构与计算[M].张文杰,译.北京:国防工业出版社,1992. [11] 王健,彭立强.榫头接触应力计算及涡轮叶片强度分析[C]//第五届中国CAE工程分析技术年会论文集.兰州:中国机械工程学会,2009:201-209. [12] 葛玉峰.双工质冷却涡轮叶片温度场计算与强度分析[D].大连:大连理工大学,2009. [13] LU Yi.Preliminary design and life estimation of the first stage high pressure turbine rotor blade of an industrial engine[D].Cranfield,England:Cranfield University,2012. [14] 罗尔斯·罗伊斯公司.EGD-3斯贝MK202发动机应力标准[S].丁爱祥,吴君,译.北京:国际航空编辑部,1979:164-212. [15] 宋兆泓.航空燃气涡轮发动机强度设计[M].北京:北京航空学院出版社,1988. [16] 颜鸣皐,刘伯操,李金桂,等.中国航空材料手册:第2卷 变形高温合金 铸造高温合金[M].北京:中国标准出版社,2002. [17] 廉筱纯,吴虎.航空发动机原理[M].西安:西北工业大学出版社,2008. [18] 彭泽琰,刘刚,桂幸民,等.航空燃气轮机原理[M].北京:国防工业出版社,2008. -
