Structure of non-contact shape control based on hierarchical genetic algorithms
-
摘要: 以PLZT光致伸缩层合梁非接触形状控制问题为研究对象,提出了一种结合结构拓扑优化与递阶遗传算法的控制方法.该方法以PLZT光致伸缩驱动器的拓扑分布和照射的光强值为设计变量,以PLZT光致伸缩层合梁的期望形状与控制形状的差值函数为适应度函数,应用结构拓扑优化、递阶遗传算法和有限元法,优化了PLZT光致伸缩驱动器的分布和所照射的光强值.与基于传统遗传算法的形状控制方法的计算结果进行了对比分析,该方法的进化速度提高了91%以上,所控制的结构形状与期望形状的误差较传统遗传算法降低了76%以上.
-
关键词:
- 非接触形状控制 /
- 结构拓扑优化 /
- 递阶遗传算法 /
- 有限元法 /
- PLZT光致伸缩驱动器
Abstract: Taking the non-contact shape control of a beam bonded with PLZT photostrictive actuators on its surface as an object, a control method was proposed by combining the structural topology optimization and hierarchical genetic algorithms. In this method, the topological distribution of photostrictive actuators and the light intensity were chosen as design variables, and the shape errors between the desired shape and the achieved shape of beam bonded with PLZT photostrictive actuators were taken as the fitness function. The distribution of PLZT photostrictive actuators and the light intensity were optimized by using structural topology optimization, hierarchical genetic algorithms and finite element method. The performance of the presented method for shape control was assessed in comparison with that of the conventional genetic algorithm. The results demonstrate that the speed of the evolution of the presented method has been improved by more than 91% and the errors between the desired shape and the achieved shape have been reduced by over 76% compared with the conventional genetic algorithm. -
[1] Agawal B N,Treanor K E.Shape control of a beam using piezoelectric actuators[J].Smart Materials and Struetures,1999,8(6):729-739. [2] Agrawal S K,Tong D,Nagaraja K.Modeling and shape control of piezoeleetric actuator embedded elastic plates[J].Journal of Intelligent Materia1 Systems and Struetures,1994,5(4):514-521. [3] Lin J C,Nien M H.Adaptive modeling and shape control of laminated plates using piezoelectric actuators[J].Journal of Materials Processing Technology,2007,189(1/2/3):231-236. [4] Dawood M S,Greenhalgh E S,Iannucci L.Three-dimensional static shape control analysis of composite plates using distributed piezoelectric actuators[J].Smart Materials and Structures,2008,17(2):507-514. [5] Luo Q T,Tong L Y.High precision shape control of plates using orthotropic piezoelectric actuators[J].Finite Elements in Analysis and Design,2006,42(11):1009-1020. [6] Kang Z,Tong L.Topology optimization-based distribution design of actuation voltage in static shape control of plates[J].Computers and Structures,2008,86(19):1885-1893. [7] Liu S,Lin Z.Integrated design optimization of voltage channel distribution and control voltages for tracking the dynamic shapes of smart plates[J].Smart Materials and Structures,2010,19(12):125013.1-125013.8. [8] Kang Z,Wang X.Topology optimization of bending actuators with multilayer piezoelectric material[J].Smart Materials and Structures,2010,19(7):075018.1-075018.11. [9] Wang X J,Yue H H,Jiang J.Wireless active vibration control of thin cylindrical shells laminated with photostrictive actuators[J].Journal of Intelligent Material Systems and Structures,2011,22(4):337-351. [10] Liu S T,Tong L Y,Lin Z.Simultaneous optimization of control parameters and configurations of PZT actuators for morphing structural shapes[J].Finite Elements in Analysis and Design,2008,44(6/7):417-424. [11] Shih H R,Watkins J,Tzou H S.Displacement control of a beam using photostrictive optical actuators[J].Journal of Intelligent Material Systems and Structures,2005,16(4):355-363. [12] Rahman M,Nawaz M.Finite element modeling analysis of photostrictively driven optical actuators for excitation of microdevices[J].Smart Materials and Structures,2011,20(11):115013.1-115013.12. [13] Sun D,Tong L.Modeling of wireless remote shape control for beams using nonlinear photostrictive actuators[J].International Journal of Solids and Structures,2007,44(2):672-684. [14] Luo Z,Luo Q T,Tong L Y,et al.Shape morphing of laminated composite structures with photostrictive actuators via topology optimization[J].Composite Structures,2011,93(2):406-418. [15] 李书阳,郑世杰,王宏涛.PLZT光致伸缩层合梁的非接触形状控制[J].宇航学报,2012,33(4):514-519. LI Shuyang,ZHENG Shijie,WANG Hongtao.Non-contact shape control of the laminated beam based on PLZT photostrictive actuator[J].Journal of Astronautics,2012,33(4):514-519.(in Chinese) [16] Zheng S.Finite element simulation of wireless structural vibration control with photostrictive actuators[J].Science China:Technological Sciences,2011,55(3):709-716. [17] Shih H R,Tzou H S,Saypuri M.Structural vibration control using spatially configured opto-electromechanical actuators[J].Journal of Sound and Vibration,2005,284(1/2):361-378. [18] 范德礼,郑世杰,王宏涛.基于递阶遗传算法的结构多损伤监测[J].航空动力学报,2013,28(9):2050-2054. FAN Deli,ZHENG Shijie,WANG Hongtao.Multiple damages detection of structure based on hierarchical genetic algorithm[J].Journal of Aerospace Power,2013,28(9):2050-2054.(in Chinese)
