RP-3航空煤油层流燃烧特性的实验

曾文; 陈欣; 马洪安; 刘宇; 陈潇潇; 胡二江

doi:10.13224/j.cnki.jasp.2015.12.011

RP-3航空煤油层流燃烧特性的实验

doi: 10.13224/j.cnki.jasp.2015.12.011

1. 沈阳航空航天大学航空航天工程学部(院), 沈阳 110136;
2. 西安交通大学能源与动力工程学院动力工程多相流国家重点实验室, 西安 710049

基金项目:

辽宁省自然科学基金(2013024009)

沈阳市科技攻关项目(F13024200)

国家自然科学基金(51376133)

详细信息

作者简介:
曾文(1977-),男,湖南沅江人,教授,博士后,主要从事航空发动机燃烧过程与排放物生成的数值研究.

中图分类号: V231;TK401
计量
- 文章访问数: 959
- HTML浏览量: 5
- PDF量: 563
- 被引次数: 0
出版历程
- 收稿日期: 2014-10-11
- 刊出日期: 2015-12-28

Experiment on laminar combustion characteristics of RP-3 kerosene

1. College of Aerospace Engineering, Shenyang Aerospace University, Shenyang 110136, China;
2. State Key Laboratory of Multiphase Flow in Power Engineering, School of Energy and Power Engineering, Xi'an Jiaotong University, Xi'an 710049, China

摘要

摘要: 为了阐明RP-3航空煤油的燃烧特性,在定容燃烧反应器中实验测量了初始压力分别为0.1,0.3,0.5,0.7MPa、初始温度分别为390,420,450K、当量比范围为0.6~1.6时,RP-3航空煤油的层流燃烧速度与马克斯坦长度,分析了初始温度、压力以及当量比对火焰发展结构、层流燃烧速度及马克斯坦长度的影响.结果表明:随着初始温度的升高或初始压力的降低,RP-3航空煤油的层流燃烧速度逐渐升高;随着当量比由0.6升高至1.6,层流燃烧速度呈现先增加后降低的趋势,当当量比为1.2时,层流燃烧速度最大.随着初始压力或当量比的降低,马克斯坦长度逐渐增大,火焰稳定性增强;初始温度对马克斯坦长度的影响不明显,当当量比为0.9~1.1时,随着初始温度的升高,马克斯坦长度逐渐减小,但当当量比为1.2~1.5时,马克斯坦长度则有所增大.
- RP-3航空煤油 /
- 燃烧稳定性 /
- 层流燃烧速度 /
- 马克斯坦长度 /
- 影响因素
Abstract: In order to illustrate the combustion characteristics of RP-3 kerosene, the laminar combustion velocity and Markstein length of RP-3 kerosene were investigated experimentally in a constant volume combustion bomb.The experiments were performed at four different pressures:0.1, 0.3, 0.5 and 0.7MPa, three different temperatures:390, 420 and 450K, and over the equivalence ratio range of 0.6-1.6.The influences of three crucial parameters:initial temperature, initial pressure and equivalence ratio on the flame structure, laminar combustion velocity and Markstein length were investigated.The results showed that increasing the initial temperature or decreasing the initial pressure could lead to an increase in the laminar combustion velocity of RP-3 kerosene.With the equivalence ratio increasing from 0.6 to 1.6, the laminar combustion velocity increased initially and then decreased gradually.The highest laminar combustion velocity was measured at fuel rich condition (equivalence ratio of 1.2).Furthermore, decreasing the initial pressure or equivalence ratio could increase the stability of the flame front, which is established by increased Markstein length.The effect of the initial temperature on the Markstein length is not clear; with the increase of the initial temperature, the Markstein length has a decreasing trend at some conditions for the equivalence ratios of 0.9-1.1, and an increasing trend over the equivalence ratios range of 1.2-1.5.
- RP-3 kerosene /
- combustion stability /
- laminar combustion velocity /
- Markstein length /
- influence factor

HTML

参考文献(19)

[1]	Edwards T,Maurice L Q.Surrogate mixtures to represent complex aviation and rocket fuels[J].Journal of Propulsion and Power,2001,17(2):461-466.
[2]	Riesmeir E,Honnet S,Peters N.Flamelet modeling of pollutant formation in a gas turbine combustion chamber using detailed chemistry for a kerosene model fuel[J].Journal of Engineering for Gas Turbines and Power,2004,126(4):899-905.
[3]	Kumar K,Sung C J,Hui X.Laminar flame speeds and extinction limits of conventional and alternative jet fuels[J].Fuel,2011,90(3):1004-1011.
[4]	Bosschaart K J,Lph D G.The laminar burning velocity of flames propagating in mixtures of hydrocarbons and air measured with the heat flux method[J].Combustion and Flame,2004,136(3):261-269.
[5]	Weiss M,Zarzalis N,Suntz R.Experimental study of Markstein number effects on laminar flamelet velocity in turbulent premixed flames[J].Combustion and Flame,2008,154(4):671-691.
[6]	Gu X J,Haq M Z,Lawes M,et al.Laminar burning velocity and Markstein numbers of methane-air mixtures[J].Combustion and Flame,2000,121(1/2):41-58.
[7]	Far E K,Parsinejad F,Metghalchi H.Flame structure and laminar burning speeds of JP-8/air premixed mixtures at high temperatures and pressures[J].Fuel,2010,89(5):1041-1049.
[8]	Far E K,Moghaddas A,Metghalchi H,et al.The effect of diluent on flame structure and laminar burning speeds of JP-8/oxidizer/diluent premixed flames[J].Fuel,2011,90(4):1476-1486.
[9]	Singh D,Nishiie T I,Qiao L.Laminar burning speeds and Markstein numbers of n-decane/air,n-decane/O₂/He,Jet-A/air and S-8/air flames[R].AIAA 2010-951,2010.
[10]	Vukadinovic V,Habisreuther P,Zarzalis N.Influence of pressure and temperature on laminar burning velocity and Markstein number of kerosene Jet A-1:experimental and numerical study[J].Fuel,2013,111(9):401-410.
[11]	Hu E J,Huang Z H,He J J,et al.Experimental and numerical study on laminar burning characteristics of premixed methane-hydrogen-air flames[J].International Journal of Hydrogen and Energy,2009,34(11):4876-4888.
[12]	Bradley D,Hicks R A,Lawes M,et al.The measurement of laminar burning velocities and Markstein numbers for iso-octane-air and iso-octane-n-heptane-air mixtures at elevated temperatures and pressures in an explosion bomb[J].Combustion and Flame,1998,115(1):126-144.
[13]	范学军,俞刚.大庆RP-3航空煤油热物性分析[J].推进技术,2006,27(2):187-192. FAN Xuejun,YU Gang.Analysis of thermophysical properties of daqing RP-3 aviation kerosene[J].Journal of Propulsion Technology,2006,27(2):187-192.(in Chinese)
[14]	ZENG Wen,LI Haixia,CHEN Baodong,et al.Experimental and kinetic modeling study of ignition characteristics of Chinese RP-3 kerosene[J].Combustion Science and Technology,2015,187(3):396-409.
[15]	Bradley D,Gaskell P H,Gu X J.Burning velocities,Markstein numbers,and flame quenching for spherical methane-air flames:a computational study[J].Combustion and Flame,1996,104(3):176-198.
[16]	Huang Z H,Wang Q,Yu J R,et al.Measurement of laminar burning velocity of dimethyl ether-air premixed mixtures[J].Fuel,2007,86(15):2360-2366.
[17]	Burke M P,Chen Z,Ju Y,et al.Effect of cylindrical confinement on the determination of laminar flame speeds using outwardly propagating flames[J].Combustion and Flame,2009,156(4):771-779.
[18]	Kwon O C,Rozenchan G,Law C K.Cellular instabilities and self-acceleration of outwardly propagating spherical flames[J].Proceedings of the Combustion Institute,2002,29(2):1775-1783.
[19]	Bechtold J K,Matalon M.The dependence of the Markstein length on stoichiometry[J].Combustion and Flame,2001,127(1):1906-1913.
