夹气喷嘴瞬态喷雾的CFD仿真及试验

杨海青; 陈茂杰; 黄丽萍; 胡春明

doi:10.13224/j.cnki.jasp.2015.12.012

夹气喷嘴瞬态喷雾的CFD仿真及试验

doi: 10.13224/j.cnki.jasp.2015.12.012

1. 南京航空航天大学能源与动力学院, 南京 210016;
2. 天津大学内燃机研究所, 天津 300072

详细信息

作者简介:
杨海青(1963-),男,江苏南京人,副教授,硕士,主要从事内燃机性能仿真与控制研究.

中图分类号: V234.2
计量
- 文章访问数: 1516
- HTML浏览量: 167
- PDF量: 580
- 被引次数: 0
出版历程
- 收稿日期: 2014-03-05
- 刊出日期: 2015-12-28

CFD simulation and experiment of transient spray for an air-assisted injector

1. College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. Tianjin Internal Combustion Engine Research Institute, Tianjin University, Tianjin 300072, China

摘要

摘要: 通过CFD仿真和试验的方法研究了夹气喷嘴的瞬态喷雾特性并验证了喷雾仿真模型的准确性.利用Fluent软件在不同环境背压和不同喷气压力的条件下进行了瞬态喷雾的CFD仿真计算,同时利用高速摄影机拍摄定容弹内部的喷雾形态,以及通过激光粒径测试仪对大气环境下的喷雾进行燃油液滴SMD的测量.结果表明:喷嘴出口处高速流出的压缩气体与燃油发生强烈的耦合,并于下游处产生强烈的涡环结构;试验中环境背压减少0.2MPa时所增加的平均贯穿速率是喷气压力增加0.2MPa时的3.62倍;喷雾平均贯穿速率的试验结果与仿真结果的平均误差为9.94%;试验得到的喷嘴外围的喷雾平均索特直径与仿真平均索特直径的平均误差为4.33%.
- 夹气喷嘴 /
- 瞬态喷雾 /
- 计算流体动力学(CFD) /
- CFD仿真 /
- 索太尔平均直径(SMD)
Abstract: In order to research the transient spray characteristics of the air-assisted injector and verify the accuracy of the simulation model, the spray characteristics of the air-assisted injector were investigated by CFD simulation and experiment. The CFD simulation had been carried out that the transient injection with different back pressure and inject pressure was simulated. The spray development in the constant volume bomb had visualized by the high speed camera. The SMD of the fuel droplets in the atmospheric environmenthad measured by the laser particles test device. The results show that the high speed compressed air from the injector and the fuel are strongly coupled, and the vortex ring structures come out in the downstream; the increased average rate in experiment by reducing 0.2MPa of back pressure is 3.62 times than increasing 0.2MPa of inject pressure; the average error of average rate between experiment and simulation is 9.94%; the SMD average error of the outlying of injector between experiment and simulation is 4.33%.
- air-assisted injector /
- transient spray /
- computational fluid dynamics (CFD) /
- CFD simulation /
- Sauter mean diameter (SMD)

HTML

参考文献(15)

[1]	Cathcart G,Dickson G,Tubb J,et al.Development of lightweight 2-stroke & 4-stroke heavy fuel UAV engines[C]//Proceedings of Unmanned Systems North America Conference.Orlando,Florida:Association for Unmanned Vehicle Systems International (AUVAI),2006:1235-1249.
[2]	莫胜钧.小型航空点燃式重油活塞发动机点火及火焰传播特性的模拟研究[D].北京:北京交通大学,2012. MO Shengjun.Study of the ignition and flame propagation property of light-weight spark ignition,heavy oil aeroengine[D].Beijing:Beijing Jiaotong University,2012.(in Chinese)
[3]	甘晓华.航空燃气轮机燃油喷嘴技术[M].北京:国防工业出版社,2006.
[4]	杨嘉林.车用汽油发动机燃烧系统的开发[M].北京:机械工业出版社,2009.
[5]	巴斯怀森.汽油机直喷技术[M].宋进桂,李栋,于京诺,等译.北京:机械工业出版社,2011.
[6]	Yang J,Yi J,Anderson R,et al.Study of a stratified-charge DISI engine with an air-forced fuel injection system[J].SAE TP 2000-01-0901,2000.
[7]	Cathcart G,Zavier C.Fundamental characteristics of an air-assisted direct injection combustion system as applied to 4-stroke automotive gasoline engines[R].SAE TP 2000-01-0256,2000.
[8]	Hatakeyama S,Kondo M,Sekiya Y.An attempt at lean burn of a 4 stroke gasoline engine by the aid of low pressure air assisted in-cylinder injection[R].SAE TP 982698,1998.
[9]	Boretti A A,Jin S H,Zakis G,et al.Experiment and numerical study of an air assisted fuel injection for a D.I.S.I engine[R].SAE TP 2007-01-1415,2007.
[10]	Jin S H,Brear M,Watson H,et al.An experimental study of the spray from an air-assisted direct fuel injector[J].Proceedings of the Institute of Mechanical Engineers:Part D Journal of Automobile Engineering,2008,222(10):1883-1894.
[11]	王福军.计算流体动力学:CFD软件原理与应用[M].北京:清华大学出版社,2004.
[12]	韩占忠,王敬,兰小平.FLUENT流体工程仿真计算实例与应用[M].北京:北京理工大学出版社,2004.
[13]	吕洪.燃油喷射过程的数值模拟[D].南昌:南昌大学,2006. LV Hong.Numerical simulation of fuel injection process[D].Nachang:Nanchang University,2006.(in Chinese)
[14]	Maclnnes J M,Bracco F V.Computation of the spray from an air-assisted fuel injector[R].SAE TP 902079,1990.
[15]	李波,李云清,王德福.往复式汽油直喷发动机燃油喷雾特性研究[J].航空动力学报,2010,25(8):1723-1727. LI Bo,LI Yunqing,WANG Defu.Study on fuel spray characteristics of gasoline direct injection reciprocating engine[J].Journal of Aerospace Power,2010,25(8):1723-1727.(in Chinese)
