偏心对双级旋流器出口流场影响数值模拟

蒋尧; 胡建; 胡好生

doi:10.13224/j.cnki.jasp.2015.12.015

偏心对双级旋流器出口流场影响数值模拟

doi: 10.13224/j.cnki.jasp.2015.12.015

中国航空工业集团公司中国航空动力机械研究所, 湖南株洲 412002

详细信息

作者简介:
蒋尧(1988-),男,江苏镇江人,工程师,硕士,主要从事燃烧室气动设计工作.

中图分类号: V231.3
计量
- 文章访问数: 976
- HTML浏览量: 52
- PDF量: 454
- 被引次数: 0
出版历程
- 收稿日期: 2014-04-28
- 刊出日期: 2015-12-28

Numerical simulation on the effect of misalignment on outlet flow field of double-swirler

China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 412002, China

摘要

摘要: 采用Fluent软件,数值模拟了一级旋流器和二级旋流器偏心情况下,双级旋流器出口流场变化,湍流模型采用标准k-ε模型,计算了3种不同偏心量(0,0.5,1.7mm)下的双级旋流器出口流场,并将计算结果与试验结果进行了对比.研究表明:偏心对双级旋流器出口流场影响较大,0.5mm偏心下双级旋流器出口的回流区发生畸变,径向速度峰值区域位于X/D=0.5~1.0范围内;轴向速度和径向速度的计算结果与试验结果吻合良好.
- 双级旋流器 /
- 偏心 /
- 标准k-ε模型 /
- 冷态流场 /
- 回流区
Abstract: Numerical simulation on outlet flow field of a double-swirler with misalignment of the first and second stages was performed by Fluent software, and standard k-ε model was chosen for the turbulence model.The numerical simulation was conducted on three configurations with different misaligned dimensions (0, 0.5, 1.7mm) and validated against the test data. The results show that misalignment has significant influence on the outlet flow field of a double-swirler, and distortion on the recirculation zone has already appeared since 0.5mm misalignment. Meanwhile, the zone with peak radial velocity is located at the region of X/D=0.5~1.0. Numerical simulations agree well with the test results for both axial and radial velocities.
- double-swirler /
- misalignment /
- standard k-ε model /
- non-reacting flow field /
- recirculation zone

HTML

参考文献(18)

[1]	McDonell V G,Arellao L,Lee S W,et al.Effect of hardware alignment of fuel distribution and combustion performance for a production engine fuel injection assembly[R].Irvine,California:26th Symposium on Combustion,1996.
[2]	Nikjooy M,Mongia H C,Samuelsen G S,et al.A numerical and experimental study of confined swirling jets[R].AIAA 89-2898,1989.
[3]	Ateshkadi A,Mcdonell V,Samuelsen G S.Effect of hardware geometry on gas and drop behavior in a radial mixer spray[R].AIAA 98-0247,1998.
[4]	Hsiao G,Mongia H C.Swirl cup modeling:Part Ⅲ grid independent solution with different turbulence models[R].AIAA-2003-1349,2003.
[5]	Hsiao G,Mongia H C,Vij A.Swirl cup modeling:Part Ⅱ inlet boundary conditions[J].AIAA-2003-1350,2003.
[6]	Grinstein F F,Young T R,LI Guoqiang,et al.Computational and experimental analysis of the flow dynamics in a multi-swirler combustor[R].AIAA-2002-1006,2002.
[7]	Mongia H C,AI-Roub M,Danis A,et al.Swirl cup modeling:Part Ⅰ[R].AIAA-2001-3576,2001.
[8]	FU Yongqiang,CAI Jun,Jeng S M,et al.Confinement effects on the swirling flow of a counter-rotating swirl cup[J].ASME Paper GT2005-68622,2005.
[9]	CAI Jun,FU Yongqiang,Flohre N.Experimental study on coherent structures of a counter-rotating multi-swirler cup[J].AIAA-2007-5674,2007.
[10]	Reddy A P,Sujith R I,Chakravarthy S R.Swirler flow field characteristic in a sudden expansion combustor geometry[J].Journal of Propulsion and Power,2006,22(4):800-808.
[11]	Syred N,Beer J M.Combustion in swirling flows:a review[J].Combustion and Flame,1974,23(2):143-201.
[12]	Adrian S,Hollis D,Carrote J.PIV measurements of combustor turbulence fields[J].ASME Paper GT2007-28050,2007.
[13]	Ramos J I,Somert H T.Swirling flow in a research combustor[J].AIAA Journal,1985,23(2):241-248.
[14]	Rizk N K,Mongia H C.Three-dimensional analysis of gas turbine combustors[J].Journal of Propulsion and Power,1991,7(3):445-451.
[15]	Rosfjord T J,Russell S.Nozzle design and manufacturing influences on fuel spray circumferential uniformity[J].Journal of Propulsion and Power,1989,5(2):144-150.
[16]	Rosfjord T J,Eckerle W A.Aerating fuel nozzle design influence on airflow features[J].Journal of Propulsion and Power,1991,7(6):849-856.
[17]	Cohen J M,Rosfjord T J.Influences on the sprays formed by high-shear fuel nozzle/swirler assemblies[R].Journal of Propulsion and Power,1993,9(1):16-27.
[18]	蒋尧.双级旋流器偏心对旋流器出口流场影响研究[D].湖南株洲:中国航空动力机械研究所,2013. JIANG Yao.Research on the outlet flow field of double-swirler'smisalignment[D].Zhuzhou Hunan:China Aviation Powerplant Research Institute,2013.(in Chinese)
