脉冲射流控制弯曲扩压管道流动分离的特点

朱剑锋; 黄国平; 傅鑫; 付勇

doi:10.13224/j.cnki.jasp.2015.12.018

脉冲射流控制弯曲扩压管道流动分离的特点

doi: 10.13224/j.cnki.jasp.2015.12.018

1. 南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室, 南京 210016;
2. 中国航空工业集团公司中国航空动力机械研究所, 湖南株洲 412002

基金项目:

国家自然科学基金(51176072)

江苏省普通高校研究生科研创新基金(CXLX11_0216)

详细信息

作者简介:
朱剑锋(1987-),男,湖南双峰人,工程师,博士,主要从事推进系统内流流动控制研究及发动机总体性能分析.

中图分类号: V211⁺5,V231.1
计量
- 文章访问数: 981
- HTML浏览量: 182
- PDF量: 465
- 被引次数: 0
出版历程
- 收稿日期: 2014-05-28
- 刊出日期: 2015-12-28

Characteristic of controlling flow separation in divergent curved channels by pulsed jet

1. Jiangsu Province Key Laboratory of Aerospace Power System, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 412002, China

摘要

摘要: 结合弯曲扩压通道的脉冲射流总体控制规律,开展了不同射流频率下通道内流场的稳定及动态特性分析.研究结果表明:定常射流控制状态下,流场内沿径向不同位置流动特性的变化幅度基本相同,定常射流通过压制通道内复杂流动现象达到整体线性地改变通道内流场特性的效果;而在合理脉冲射流控制状态下,脉冲射流对流场的影响主要是通过改变分离涡的脉动时空特性,沿径向逐步增强对流场的影响,从而使得主流区内总压损失降低幅度最为明显,此时扩压通道内占主导地位分离涡的周期性特征有了明显的改善,流场拟序结构更为有序.
- 脉冲射流 /
- 非定常 /
- 流动分离 /
- 弯曲扩压管道 /
- 分离涡
Abstract: Combined with the pulsed jet overall control ruler of divergent curved channels, the steady and unsteady characteristics of flow fields in channel under different frequency states were analysed. Results show that the flow characteristics change amplitude is similar along the radial direction under steady control state, and the influence of steady jet suppresses the complex flow phenomenon and linearly changes the flow characteristic of the flow field. Under suitable pulsed jet control state, the influence of pulsed jet on the flow field is presented by changing the fluctuation time-space characteristic of separation vortex, so that the influence amplitude increases along the radial direction, and the decreased magnitude of total pressure loss in the mainstream region is more obvious; meanwhile, the periodic characteristic of the dominant separation vortex is improved significantly, and the flow coherent structure is more orderly.
- pulsed jet /
- unsteadiness /
- flow separation /
- divergent curved channels /
- separation vortex

HTML

参考文献(17)

[1]	Rivir R B,Bons J P,Lake J P.Passive and active control of separation in gas turbines[R].AIAA-2000-2235,2000.
[2]	Hergt A,Meyer R,Engel K.Experimental investigation of flow control in compressor cascades[R].ASME Paper GT2006-90415,2006.
[3]	Gmelin C,Zander V,Huppertz A,et al.Active flow control concepts on a highly loaded subsonic compressor cascade:resume of experimental and numerical results[R].ASME Paper GT2011-46468,2011.
[4]	Hecklau M,Wiederhold O,Zander V,et al.Active separation control with pulsed jets in a critically loaded compressor cascade[R].AIAA-2010-4252,2010.
[5]	ZHENG Xinqian,ZHOU Xiaobo,ZHOU Sheng.Investigation on a type of flow control to weaken unsteady separated flows by unsteady excitation in axial flow compressors[J].Journal of Turbomachinery,2005,127(7):489-496.
[6]	ZHENG Xinqian,ZHOU Sheng,LU Yajun,et al.Flow control of annular compressor cascade by synthetic jets[J].Journal of Turbomachinery,2008,130(2):021018.1-021018.7.
[7]	郭明,郑晓宇,周盛,等.BVF在吹气控制压气机叶栅分离流中的应用[J].航空动力学报,2008,23(8):1498-1503. GUO Ming,ZHANG Xiaoyu,ZHOU Sheng,et al.BVF application on blowing control of flow separation of a compressor cascade[J].Journal of Aerospace Power,2008,23(8):1498-1503.(in Chinese)
[8]	Hoeger M,Baier R D,Fischer S,et al.High turning compressor tandem cascade for high subsonic flows:Part 1 aerodynamic design[R].AIAA-2011-5601,2011.
[9]	Müller L,Kožulovi Dćy D,Wulff D,et al.High turning compressor tandem cascade for high subsonic flows:Part 2 numerical and experimental investigations[R].AIAA-2011-5602,2011.
[10]	Schuler B J,Kerrebrock J L,Merchant A.Experimental investigation of a transonic aspirated compressor[J].Journal of Turbomachinery,2005,127(4):340-348.
[11]	Greenblatt D,Wygnanski I J.The control of flow separation by periodic excitation[J].Progress in Aerospace Sciences,2000,36(7):487-545.
[12]	Culley D E,Bright M M,Prahst P S,et al.Active flow separation control of a stator vane using embedded injection in a multistage compressor experiment[J].Journal of Turbomachinery,2004,126(1):24-34.
[13]	黄国平,陈杰,夏晨,等.抑制压气机叶背分离的无源脉冲射流器:中国,ZL200810195408.3[P].2011-10-30.
[14]	朱剑锋,黄国平,傅鑫,等.一种控制气流分离的无源微脉冲射流技术研究[J].航空学报,2013,34(8):1757-1767. ZHU Jianfeng,HUANG Guoping,FU Xin,et al.Investigation of technology for controlling flow separation by micro-pulsed-jet without external device[J].Acta Aeronautica et Astronautica Sinica,2013,34(8):1757-1767.(in Chinese)
[15]	张攀峰,王晋军,冯立好.零质量射流技术及其应用研究进展[J].中国科学 E辑:技术科学,2008,38(3):321-349. ZHANG Panfeng,WANG Jinjun,FENG Lihao.Review on the zero-net-mass-flux jet and the application in separation flow control[J].Science in China Series E:Technological Sciences,2008,38(3):321-349.(in Chinese)
[16]	朱剑锋,黄国平,傅鑫,等.无源微脉冲射流抑制叶栅气流分离的初步实验研究[J].航空动力学报,2014,29(2):391-397. ZHU Jianfeng,HUANG Guoping,FU Xin,et al.Primary experimental investigation of suppressing flow separation in cascade by pulsed-jet without external device[J].Journal of Aerospace Power,2014,29(2):391-397.(in Chinese)
[17]	ZHU Jianfeng,HUANG Guoping,FU Xin,et al.Use of POD to Elucidate the physics of unsteady micro-pulsed-jet flow for boundary layer flow separation control[R].ASME Paper GT2013-95266,2013.
