叶身融合技术在涡轮中的应用

田勇; 季路成; 邵卫卫; 肖云汉

doi:10.13224/j.cnki.jasp.2015.12.019

叶身融合技术在涡轮中的应用

doi: 10.13224/j.cnki.jasp.2015.12.019

田勇^1,2,4,
季路成^3, ,,
邵卫卫^1,2,
肖云汉^1,2

1. 中国科学院工程热物理研究所先进能源动力重点实验室, 北京 100190;
2. 中国科学院能源动力研究中心, 江苏连云港 222069;
3. 北京理工大学宇航学院, 北京 100081;
4. 中国科学院大学物理科学学院, 北京 100049

基金项目:

国家自然科学基金(51176012,51376023)

详细信息

作者简介:
田勇(1985-),男,湖北崇阳人,博士生,研究方向为叶轮机气动热力学.

通讯作者:
季路成(1970-),男,山东蓬莱人,教授,博士,研究方向为航空发动机能源动力、叶轮机气动热力学和计算流体力学.E-mail:jilc@bit.edu.cn

中图分类号: V231.3
计量
- 文章访问数: 942
- HTML浏览量: 56
- PDF量: 447
- 被引次数: 0
出版历程
- 收稿日期: 2014-05-07
- 刊出日期: 2015-12-28

Application of blended blade/endwall in turbines

TIAN Yong^1,2,4,
JI Lu-cheng^{3
, ,},
SHAO Wei-wei^1,2,
XIAO Yun-han^1,2

1. Key Laboratory of Advanced Energy and Power, Institute of Engineering Thermophysics, Chinese Academy of Science, Beijing 100190, China;
2. Research Center for Clean Energy and Power, Chinese Academy of Sciences, Lianyungang Jiangsu 222069, China;
3. School of Aerospace Engineering, Beijing Institute of Technology, Beijing 100081, China;
4. School of Physical Sciences, University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 将叶身融合技术进一步应用于涡轮,探索其技术应用效果.为此,以TTM-stage为原型,施加7种不同的叶身融合模型,并采用数值模拟方法进行了对比研究.结果表明:前缘融合面可削弱马蹄涡;侧融合面可削弱角区分离;对静叶实施融合使动叶进口总温附面层厚度降低,在通道涡作用下高总温流体被部分推离,明显降低了轮毂壁温.
- 叶身融合 /
- 涡轮 /
- 角区分离 /
- 绝热壁温 /
- 马蹄涡
Abstract: Blended blade/endwall was applied into turbine for finding out its effectiveness of application. Taking the TTM-stage as example, seven kinds of blended blade/endwall models were designed and numerically simulated and compared. The results show that:the leading edge's blending surface can weaken the horseshoe vortex; the side blending surface can weaken the corner separation; the blending surface of the vane reduces the height of the boundary layer of total temperature at the inlet of the blade, and then the passage vortex moves the fluid of high total temperature away from the hub wall, reducing the adiabatic wall temperature of the hub evidently.
- blended blade/endwall /
- turbine /
- corner separation /
- adiabatic temperature /
- horseshoe vortex
