离心压气机失速模式及自循环机匣处理的作用机制

康剑雄; 黄国平; 朱俊强; 温殿忠

doi:10.13224/j.cnki.jasp.2015.12.020

离心压气机失速模式及自循环机匣处理的作用机制

doi: 10.13224/j.cnki.jasp.2015.12.020

1. 南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室, 南京 210016;
2. 中国科学院工程热物理研究所轻型动力重点实验室, 北京 100190;
3. 中国航空工业集团公司中国航空动力机械研究所, 湖南株洲 412002

基金项目:

基础科研项目(B1320110070)

详细信息

作者简介:
康剑雄(1979-),男,湖南郴州人,博士生,主要从事推进系统内流流动控制研究.

中图分类号: V231.3
计量
- 文章访问数: 858
- HTML浏览量: 3
- PDF量: 529
- 被引次数: 0
出版历程
- 收稿日期: 2014-04-27
- 刊出日期: 2015-12-28

Stall mode of centrifugal compressor and mechanism of self-recirculating casing treatment

1. Jiangsu Province Key Laboratory of Aerospace Power System, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. Key Laboratory of Light-duty Gas-turbine, Institute of Engineering Thermophysics, Chinese Academy of Sciences, Beijing 100190, China;
3. China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 412002, China

摘要

摘要: 通过对离心压气机不同转速下实壁机匣和处理机匣两种状态流场的数值模拟,研究了失速模式随转速的变化及不同失速模式下机匣处理作用机制的转变.结果表明:随转速的降低,失速模式由100%设计转速时的扩压器失速逐步向导风轮失速过渡,导风轮失速也经历了由80%设计转速时的端壁失速和叶片前缘失速向50%设计转速的通道大范围完全失速的发展过程.自循环机匣处理对离心压气机失速裕度和效率的影响都与失速模式紧密相关,其扩稳作用仅对80%设计转速时的叶片前缘失速有效.在80%左右设计转速,机匣处理使主流效率有朝大流量工况点变化的趋势,从而使效率降低.当转速低至50%设计转速时,主流通道形成大范围回流区,机匣处理的二次回流可以减少叶轮对通道回流区气流的做功量,从而提高效率.
- 机匣处理 /
- 失速模式 /
- 失速裕度 /
- 压气机效率 /
- 离心压气机
Abstract: In order to explore the variation of stall mode with changing speed and the mechanism transition of casing treatment under different stall modes, numerical simulation of a centrifugal compressor with solid wall casing and casing treatment under different speeds was performed. The results showed that the stall mode transited from diffuser stall at 100% design speed to inducer stall with the speed decrease. Inducer stall also experienced from end wall stall and blade leading edge stall at 80% design speed to wide-range full stall at 50% design speed. The effect of self-recirculating casing treatment on stall margin and efficiency of centrifugal compressor were closely related to the stall mode, its stability enhancement effect was only valid for the blade leading edge stall at 80% design speed. At about 80% design speed, casing treatment tended to bring about bigger flow rate operating point for the main flow efficiency, thus reducing the efficiency. When the speed was low enough to 50% design speed, with a wide recirculation region in main flow passage, the secondary reverse flow in casing treatment could reduce the load of the impeller to passage recirculation region, so as to improve the efficiency.
- casing treatment /
- stall mode /
- stall margin /
- compressor efficiency /
- centrifugal compressor

HTML

参考文献(20)

[1]	朱俊强,刘志伟.4种不同型式机匣处理的实验研究及机理分析[J].航空学报,1997,18(5):567-570. ZHU Junqiang,LIU Zhiwei.Experimental research of four kinds of treated casings[J].Acta Aeronautica et Astronautica Sinica,1997,18(5):567-570.(in Chinese)
[2]	楚武利,朱俊强,刘志伟.折线斜缝式机匣处理的实验研究及机理分析[J].航空动力学报,1999,14(3):270-274. CHU Wuli,ZHU Junqiang,LIU Zhiwei.Experimental research and analysis of sloped slotted casing treatment[J].Journal of Aerospace Power,1999,14(3):270-274.(in Chinese)
[3]	Takata H,Tsukuda Y.Stall margin improvement by casing treatment:its mechanism and effectiveness[J].Journal for Engineering for Power,1977,99(1):121-133.
[4]	Greitzer E M,Nikkanen J P,Haddad D E,et al.A fundamental criterion for the application of rotor casing treatment[J].Journal of Fluids Engineering,1979,101(2):237-243.
[5]	周亚峰,郭捷.应用机匣处理的工程准则[J].航空发动机,1995(3):15-22. ZHOU Yafeng,GUO Jie.Engineering criteria for the application of casing treatment[J].Aeroengine,1995(3):15-22.(in Chinese)
[6]	蒋世亮.机匣处理若干问题探讨[J].工程热物理学报,2000,21(1):46-49. JIANG Shiliang.A discussion of some questions about casing treatment[J].Journal of Engineering Thermophysics,2000,21(1):46-49.(in Chinese)
[7]	康剑雄.75kW燃气轮机离心叶轮改进设计及试验研究[D].上海:上海交通大学,2008. KANG Jianxiong.Improved design and experimental in-vestigation for the centrifugal impeller of a 75kW gas turbine engine[D].Shanghai:Shanghai Jiaotong University,2008.(in Chinese)
[8]	Ishida M,Surana T,Ueki H,et al.Suppression of un-stable flow at small flow rates in a centrifugal blower by controlling tip leakage flow and reverse flow[C]//Proceedings of ASME Turbo Expo 2004:Power for Land,Sea,and Air.Vienna,Austria:ASME,2004:761-770.
[9]	蒋永松,王咏梅,杜辉,等.驻室式处理机匣:内部流动及扩稳机理的数值研究[J].航空动力学报,2008,23(2):361-366. JIANG Yongsong,WANG Yongmei,DU Hui,et al.Plenum chamber casing treatment:numerical research of internal flow and mechanism of stall margin improvements[J].Journal of Aerospace Power,2008,23(2):361-366.(in Chinese)
[10]	Fujita H.A study on configurations of casing treatment for axial flow compressors[J].Bulletin of Japan Society of Mechanical Engineers,1984,27(230):1675-1681.
[11]	Khalid S.Practical compressor casing treatment[R].ASME Paper 97-GT-375,1997.
[12]	卢新根,楚武利,朱俊强,等.轴流压气机机匣处理研究进展及评述[J].力学进展,2006,36(2):222-232. LU Xingen,CHU Wuli,ZHU Junqiang,et al.A review of studies on casing treatment of axial-flow compressor[J]. Advances in Mechanics,2006,36(2):222-232.(in Chinese)
[13]	樊琳,宁方飞,刘火星.一种槽道式处理机匣的准定常流动模型:Ⅱ 跨声转子处理机匣的优化设计[J].航空动力学报,2012,27(6):1278-1287. FAN Lin,NING Fangfei,LIU Huoxing.Quasi-steady flow model of slot-type casing treatment:Ⅱ design optimization of casing treatment for a transonic rotor[J].Journal of Aerospace Power,2012,27(6):1278-1287.(in Chinese)
[14]	高鹏,楚武利,吴艳辉.带机匣处理的离心压气机顶部流场分析研究[J].机械设计与制造,2008(5):100-102. GAO Peng,CHU Wuli,WU Yanhui.The analysis of tip flow field in a centrifugal compressor with casing treatment[J].Machinery Design and Manufacture,2008(5):100-102.(in Chinese)
[15]	Hazby H R,Xu L.Role of tip leakage in stall of a tran-sonic centrifugal impeller[C]//Proceedings of ASME Turbo Expo 2009:Power for Land,Sea,and Air.Orlando,Florida,USA:ASME,2009:1245-1253.
[16]	陆亚韵.叶轮机非定常流动理论[M].北京:北京航空航天大学出版社,1990.
[17]	Streit J A,Heinichen F,Kau H P.Axial-slot casing treatments improve the efficiency of axial flow compressors:aerodynamic effects of a rotor redesign[R].ASME Paper GT-2013-94975,2013.
[18]	Yang M Y,Ricardo M B,Zhang Y J,et al.Investigation of self-recycling-casing-treatment (SRCT) influence on stability of high pressure ratio centrifugal compressor with a volute[R].ASME Paper GT-2011-45065,2011.
[19]	Stephanie W,Ivor D,Chris F.Self-regulating casing treatment for axial compressor stability enhancement[R].ASME Paper GT-2011-46042,2011.
[20]	卜远远,楚武利,张皓光,等.高压比离心叶轮自循环机匣处理扩稳研究[J].推进技术,2013,34(2):194-201. BU Yuanyuan,CHU Wuli,ZHANG Haoguang,et al.Stability improvement in high pressure ratio centrifugal impeller with self recirculation casing treatment[J].Journal of Propulsion Technology,2013,34(2):194-201.(in Chinese)
