弯曲静子叶片对叶尖射流扩稳效果的影响

王前; 胡骏; 李亮; 屠宝锋; 李璧宇

doi:10.13224/j.cnki.jasp.2015.12.021

弯曲静子叶片对叶尖射流扩稳效果的影响

doi: 10.13224/j.cnki.jasp.2015.12.021

1. 南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室, 南京 210016;
2. 中国航空工业集团公司商用航空发动机有限责任公司, 上海 201108

基金项目:

南京航空航天大学青年科技创新基金(NS2014021)

详细信息

作者简介:
王前(1991-),女,安徽宿州人,硕士生,主要从事叶轮机械气动力学研究.

中图分类号: V231.3
计量
- 文章访问数: 932
- HTML浏览量: 64
- PDF量: 476
- 被引次数: 0
出版历程
- 收稿日期: 2014-09-29
- 刊出日期: 2015-12-28

Effect of bowed stator blade on stability enhancement by tip injection

1. Jiangsu Province Key Laboratory of Aerospace Power System, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. Commercial Aircraft Engine Company Limited, Aviation Industry Corporation of China, Shanghai 201108, China

摘要

摘要: 为了研究压气机弯曲静子叶片对叶尖射流扩稳效果的影响,在一台低速轴流压气机上,采用实验方法,对比分析了第1级静子叶片分别为弯曲叶片和直叶片时叶尖射流的扩稳效果以及压气机内部流场信息.结果表明:第1级静子叶片由直叶片改为弯曲叶片后,在压气机失速过程中,模态波主要集中在叶尖区域,而叶尖射流恰好是通过改善叶尖区域的流场来拓宽压气机的稳定工作范围的,所以第1级弯曲静子叶片使得叶尖射流的扩稳效果更加显著.
- 压气机 /
- 叶尖射流 /
- 静子叶片 /
- 弯曲叶片 /
- 稳定裕度
Abstract: In order to study the effect of bowed stator blade on stability enhancement by tip injection, the experimental research on a low-speed axial flow compressor was carried out. The effect of stability enhancement by tip injection and the compressor internal flow field information were comparative analyzed when the first stage stator blades were bowed and straight stator blades. Results show that,the first stage straight stator blades replaced by bowed blades, the effect of stability enhancement by tip injection is more significant, this is because in the process of compressor stall, the modal wave mainly concentrates in the tip region, and the tip injection can broaden stable working range of the compressor by improving the flow field in the tip region.
- compressor /
- tip injection /
- stator blade /
- bowed blade /
- stability margin

HTML

参考文献(18)

[1]	屠宝锋.风扇/压气机动态失速过程和多尺度非定常气动稳定性研究[D].南京:南京航空大学,2009. TU Baofeng.Dynamic stall inception and multi-scale unsteady aerodynamic stability investigation of fan/compressor[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2009.(in Chinese)
[2]	胡骏,吴铁鹰,曹人靖.航空叶片机原理[M].北京:国防工业出版社,2006.
[3]	Roy B,Chouhan M,Kaudinya K V.Experimental study of boundary layer control through tip injection on straight and swept compressor blades[R].ASME Paper GT2005-68304,2005.
[4]	Roy B,Veraarapu S.Stability enhancement and hysteresis improvement of axial flow fan by discrete and distributed tip injection schemes[R].ASME Paper GT2008-50075,2008.
[5]	Sasaki T,Breugelmans F.Comparison of sweep and dihedral effects on compressor cascade performance[J].Journal of Turbomachinery,1998,120(3):454-463.
[6]	邹正平,赵令德,陈懋章,等.叶轮机叶片的三维造型及其对叶片气动负荷的影响[J].航空动力学报,1998,13(3):235-240. ZOU Zhengping,ZHAO Lingde,CHEN Maozhang,et al.Three-dimensional blading and its influence on blade aerodynamic loading[J].Journal of Aerospace Power,1998,13(3):235-240.(in Chinese)
[7]	Fischer A,Riess W,Seume J R.Performance of strongly bowed stators in a 4-stage high speed compressor[R].ASME Paper GT-2003-38392,2003.
[8]	Weingold H D,Neubert R J,Behlke R F,et al.Bowed stators:an example of CFD applied to improve multistage compressor efficiency[J].Journal of Turbomachinery,1997,119(2):161-168.
[9]	Gummer V,Wenger U,Kau H P.Using sweep and dihedral to control three-dimensional flow in transonic stators of axial compressors[J].Journal of Turbomachinery,2001,123(1):40-48.
[10]	Gallimore S J,Bolger J J,Cumpsty N A,et al.The use of sweep and dihedral in multistage axial flow compressor blading:Part Ⅱ low and high speed designs and test verification[J].Journal of Turbomachinery,2002,124(4):533-541.
[11]	Suder K L,Hathaway M D,Thorp S A,et al.Compressor stability enhancement using discrete tip injection[J].Journal of Turbomachinery,2001,123(1):14-23.
[12]	Weigl H J,Paduano J D,Frechette L G,et al.Active stabilization of rotating stall and surge in a transonic single stage axial compressor[D].Cambridge,Massachusetts Massachusetts Institute of Technology,1997.
[13]	Khaleghi H,Teixeira J A.Numerical study of discrete tip injection in a transonic axial compressor[R].ASME Paper BT2010-23608,2010.
[14]	Hathaway M D,Strazisar A J.Impact of discrete tip injection on stabilization of a transonic compressor rotor[R].Norfolk,VA:21st Army Science Conference,1998.
[15]	Nie C,Xu G,Cheng X,et al.Micro air injection and its unsteady response in a low-speed axial compressor[R].ASME Paper GT2002-30361,2002.
[16]	李亮.叶尖射流对压气机稳定性影响研究[D].南京:南京航空大学,2013. LI Liang.The effect of tip injection on the compressor stability[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2013.(in Chinese)
[17]	罗钜.高性能风扇/压气机三维叶片气动设计与实验研究[D].南京:南京航空大学,2013. LUO Ju.Aerodynamic design of three-dimensional blades and experimental investigation for advanced fan/compressor[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2013.(in Chinese)
[18]	罗钜,胡骏,李亮,等.弯曲叶片对压气机轮毂-角区失速的影响[J].南京航空航天大学学报,2012,44(2):139-145. LUO Ju,HU Jun,LI Liang,et al.Bowed blade effect on hub-corner stall[J].Journal of Nanjing University of Aeronautics and Astronautics,2012,44(2):139-145.(in Chinese)
