补燃循环发动机强迫起动过程

陈宏玉; 刘红军; 陈建华

doi:10.13224/j.cnki.jasp.2015.12.026

补燃循环发动机强迫起动过程

doi: 10.13224/j.cnki.jasp.2015.12.026

中国航天科技集团公司西安航天动力研究所液体火箭发动机技术国防科技重点实验室, 西安 710100

详细信息

作者简介:
陈宏玉(1982-),男,陕西横山人,工程师,博士,主要从事液体火箭发动机系统仿真研究.

中图分类号: V421.42
计量
- 文章访问数: 962
- HTML浏览量: 10
- PDF量: 528
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-15
- 刊出日期: 2015-12-28

Forced start-up procedure of a staged combustion cycle engine

National Key Laboratory of Science and Technology on Liquid Rocket Engines, Xi'an Aerospace Propulsion Institute, China Aerospace Science and Technology Corporation, Xi'an 710100, China

摘要

摘要: 以补燃循环液氧煤油发动机系统为研究对象,对其强迫起动特性进行了研究.建立了描述补燃循环发动机瞬变过程的数学模型,提出了求解推进剂供应管路瞬变流控制方程的Chebyshev伪谱方法.采用新的面向对象仿真语言Modelica,建立了可扩展的发动机仿真模型库,在MWorks平台上,利用模型库搭建了补燃循环液氧煤油发动机仿真模型.对发动机强迫起动过程进行了仿真计算,计算结果与试车数据基本相符,其中稳态相对误差小于4%,动态相对误差小于10%,初步验证了模型的正确性.进一步分析了火药起动器工作时间、阀门打开时序等因素对发动机起动过程的影响.结果表明,为保证该发动机可靠起动,发生器点火应在氧化剂头腔充填完成后,火药起动器工作时间应持续到发生器点火.
- 液体火箭发动机 /
- 补燃循环 /
- 起动过程 /
- Chebyshev伪谱方法 /
- 液氧/煤油
Abstract: Using the advanced staged combustion cycle LOX (liquid oxygen)/kerosene engine as an example, the engine start-up characteristics were investigated. The mathematical model of transient process of the engine was developed based on modular modeling means. The nonlinear hyperbolic partial differential equations governing the unsteady flow of propellant pipelines were solved by the Chebyshev pseudo-spectral method. Furthermore, an extensible simulation library for liquid propellant rocket engines has been elaborated by using the new object-oriented simulation language-Modelica. Simultaneously, by using the simulation library, a staged combustion cycle LOX/kerosene engine model is built on the platform MWorks and forced start-up characteristics of the engine calculated. Results from the numerical simulation agree well with the ground-test data, the relative errors of steady-state are less than 4%, and the dynamic simulation errors are less than 10%, which indicates that the model can accurately predict the transient behavior of the engine. Some rules relating to start-up were simulated. The results demonstrate that solid propellant starter working should be lasted up to the gas generator ignition, and gas generator head should be filled with liquid oxygen when gas generator igniting.
- liquid propellant rocket engine /
- staged combustion cycle /
- start-up procedure /
- Chebyshev pseudo-spectral method /
- liquid oxygen (LOX)/kerosene

HTML

参考文献(18)

[1]	格列克曼.液体火箭发动机自动调节[M].顾明初,郁明桂,邱明煜,译.北京:宇航出版社,1995.
[2]	刘红军.补燃循环发动机静态特性与动态响应特性研究[D].西安:航天工业总公司第十一研究所,1998. LIU Hongjun.Investigation on static characteristics and dynamic response characteristics of staged combustion cycle rocket engine[D].Xi'an:The 11th Research Institute of China Aerospace General Corporation,1998.(in Chinese)
[3]	Seymour D C,Martin M A,Nguyen H H,et al.Transient mathematical modeling for liquid rocket engine systems:methods,capabilities,and experience[R].Tennessee,USA:15th International Symposium on Space Propulsion Chattanooga,2003.
[4]	Durteste S.A transient model of the VINCI cryogenic upper stage rocket engine[R].AIAA-2007-5531,2007.
[5]	Ogawara A,Koganezawa T,Watanabe D.Progress in rocket engine simulations in MHI[R].Okinawa,Japan:28th International Symposium on Space Technology and Science,2011.
[6]	Kurosu A,Yamanishi N,Ogawara A,et al.Study of next booster engine LE-X in JAXA[R].AIAA-2006-4700,2006.
[7]	张小平,丁丰年.富氧补燃循环发动机启动过程[J].推进技术,2004,25(1):82-85. ZHANG Xiaoping,DING Fengnian.Starting process of oxidizer-rich staged combustion rocket engine[J].Journal of Propulsion Technology,2004,25(1):82-85.(in Chinese)
[8]	刘红军,张恩昭,董锡鉴.补燃循环发动机启动特性仿真研究[J].推进技术,1999,20(3):5-9. LIU Hongjun,ZHANG Enzhao,DONG Xijian.Start-up simulation of a liquid propellant staged combustion rocket engine[J].Journal of Propulsion Technology,1999,20(3):5-9.(in Chinese)
[9]	尘军,王桁.系统动态仿真技术在高压补燃氢氧发动机研制中的应用[J].导弹与航天运载技术,2002(5):29-35. CHEN Jun,WANG Hang.The application of system dynamic simulation technology to the development of LOX-LH₂ staged combustion rocket engine[J].Missiles and Space Vehicles,2002(5):29-35.(in Chinese)
[10]	刘昆,张育林,程谋森.液体火箭发动机系统瞬变过程模块化建模与仿真[J].推进技术,2003,24(5):401-405. LIU Kun,ZHANG Yulin,CHENG Mousen.Modular ization modeling and simulation for the transients of liquid propellant rocket engines[J].Journal of Propulsion Technology,2003,24(5):401-405.(in Chinese)
[11]	Wylie E B,Streeter V L.Fluid transient in systems[M].Endlewood Cliffs,US:Prentice Hall,1993.
[12]	Guo B Y.Spectral methods and their applications[M].Singapore:World Scientific,1998.
[13]	Huang W Z,Sloan D M.The pseudo-spectral method for solving differential eigenvalue equations[J].Journal of Computational Physics,1994,111(2):399-409.
[14]	Ma H P,Li H Y.Super spectral viscosity method for nonlinear conservation laws[J].Journal of Shanghai University:English Edition,2006,10(1):9-l4.
[15]	Sarra S A.Chebyshev super spectral viscosity method for a two-dimensional fluidized bed model[J].Internation Journal for Numerical Methods in Fluids,2002(4):1-18.
[16]	Beliaev E N,Chevanov V K,Chervakov V V.Mathematical modeling of working processes of liquid propellant rocket engines[M].Moscow,Russia:MAI Publications,1999.
[17]	Tiller M M.Introduction to physical modeling with modelica[M].Holland:Kluwer Academic Publishers,2001.
[18]	ZHOU Fanli,CHEN Liping,WU Yizhong,et al.MWorks:a modern IDE for modeling and simulation of multidomain physical systems based on modelica[R].Vienna,Austria:The 5th International Modelica Conference,2006.
