基于局部均值分解和峭度图的滚动轴承包络分析方法

张亢; 程军圣

doi:10.13224/j.cnki.jasp.2015.12.030

基于局部均值分解和峭度图的滚动轴承包络分析方法

doi: 10.13224/j.cnki.jasp.2015.12.030

张亢¹,
程军圣²

1. 长沙理工大学能源与动力工程学院, 长沙 410076;
2. 湖南大学机械与运载工程学院, 长沙 410082

基金项目:

国家自然科学基金(51305046)

能源高效清洁利用湖南省高校重点实验室开放基金(2013NGQ007)

详细信息

作者简介:
张亢(1983-),男,湖南长沙人,讲师,博士,主要从事机械故障诊断研究.

中图分类号: V233.4⁺5;TN911.7;TH165.3
计量
- 文章访问数: 1167
- HTML浏览量: 298
- PDF量: 427
- 被引次数: 0
出版历程
- 收稿日期: 2014-04-28
- 刊出日期: 2015-12-28

Roller bearing envelope analysis method based on local mean decomposition and kurtogram

ZHANG Kang¹,
CHENG Jun-sheng²

1. School of Energy and Power Engineering, Changsha University of Science and Technology, Changsha 410076, China;
2. College of Mechanical and Vehicle Engineering, Hunan University, Changsha 410082, China

摘要

摘要: 提出了基于局部均值分解(local mean decomposition,LMD)和峭度图(kurtogram)的滚动轴承包络分析方法.该方法中,原始滚动轴承故障振动信号通过LMD进行自适应的频率成分分离和初步降噪,包络分析中带通滤波器的参数通过峭度图客观地提供,从而提高滚动轴承包络分析的准确度.通过对滚动轴承仿真信号以及实验信号的分析,结果表明:在低信噪比情况下,LMD可以自适应分离出滚动轴承的固有振动成分,峭度图可以自动确定包络分析中带通滤波器的参数,与传统包络分析比较,所提方法能更加清晰准确地提取滚动轴承的故障特征.
- 故障诊断 /
- 滚动轴承 /
- 局部均值分解 /
- 峭度图 /
- 包络分析 /
- 故障特征
Abstract: Roller bearing envelope analysis method based on local mean decomposition (LMD) and kurtogram was proposed. In this method, the original roller bearing fault vibration signal was decomposed into a set of frequency components and preliminary reduced noises adaptively by LMD, and the parameters of band-pass filter in envelope analysis were provided objectively by kurtogram, thus the envelope analysis accuracy for roller bearing can be enhanced. The analytical results from roller bearing simulation signals and experiment signals indicate that the natural vibration components of roller bearing can be separated by LMD adaptively and the parameters of band-pass filter in envelope analysis can be determined by kurtogram automatically in low signal-to-noise ratio. Compared with traditional envelope analysis, the proposed method can extract the fault features of roller bearing more clearly and accurately.
- fault diagnosis /
- roller bearing /
- local mean decomposition /
- kurtogram /
- envelope analysis /
- fault feature

HTML

参考文献(18)

[1]	梅宏斌.滚动轴承振动监测与诊断[M].北京:机械工业出版社,1996.
[2]	McFadden P D,Smith J D.Vibration monitoring of rolling element bearings by the high frequency resonance technique:a review[J].Tribology International,1984,17(1):3-10.
[3]	Nikolaou N G,Antoniadis I A.Demodulation of vibration signals generated by defects in rolling element bearings using complex shifted Morlet wavelet[J].Mechanical Systems and Signal Processing,2002,16(4):677-694.
[4]	何岭松,李巍华.用Morlet小波进行包络检波分析[J].振动工程学报,2002,15(1):119-121. HE Lingsong,LI Weihua.Morlet wavelet and its application in enveloping[J].Journal of Vibration Engineering,2002,15(1):119-121.(in Chinese)
[5]	程军圣,于德介,杨宇.基于EMD的能量算子解调方法及其在机械故障诊断中的应用[J].机械工程学报,2004,40(8):115-118. CHENG Junsheng,YU Dejie,YANG Yu.Energy operator demodulating approach based on EMD and its application in mechanical fault diagnosis[J].Chinese Journal of Mechanical Engineering,2004,40(8):115-118.(in Chinese)
[6]	Antoni J.The spectral kurtosis:a useful tool for characterising non-stationary signals[J].Mechanical Systems and Signal Processing,2006,20(2):282-307.
[7]	Antoni J,Randall R B.The spectral kurtosis:application to the vibratory surveillance and diagnostics of rotating machines[J].Mechanical Systems and Signal Processing,2006,20(2):308-331.
[8]	Antoni J.Fast computation of the kurtogram for the detection of transient faults[J].Mechanical Systems and Signal Processing,2007,21(1):108-124.
[9]	Sawalhi N,Randall R B.The application of spectral kurtosis to bearing diagnosis[C]//Proceedings of Acoustics.Gold Coast,Australia:Australian Acoustical Society,2004:393-398.
[10]	Sawalhi N,Randall R B,Endo H.The enhancement of fault detection and diagnosis in rolling element bearings using minimum entropy deconvolution combined with spectral kurtosis[J].Mechanical Systems and Signal Processing,2007,21(6):2616-2633.
[11]	Combet F,Gelman L.Optimal filtering of gear signals for early damage detection based on the spectral kurtosis[J].Mechanical Systems and Signal Processing,2009,23(3):652-668.
[12]	Barszcz T,Randall R B.Application of spectral kurtosis for detection of a tooth crack in the planetary gear of a wind turbine[J].Mechanical Systems and Signal Processing,2009,23(4):1352-1365.
[13]	ZHANG Yongxiang,Randall R B.Rolling element bearing fault diagnosis based on the combination of genetic algorithms and fast kurtogram[J].Mechanical Systems and Signal Processing,2009,23(5):1509-1517.
[14]	Smith J S.The local mean decomposition and its application to EEG perception data[J].Journal of the Royal Society Interface,2005,2(5):443-454.
[15]	杨宇,王欢欢,程军圣,等.基于LMD的包络谱特征值在滚动轴承故障诊断中的应用[J].航空动力学报,2012,27(5):1153-1158. YANG Yu,WANG Huanhuan,CHENG Junsheng,et al.Application of envelope spectrum characteristics based on LMD to roller bearing fault diagnosis[J].Journal of Aerospace Power,2012,27(5):1153-1158.(in Chinese)
[16]	张中民,卢文祥,杨叔子,等.滚动轴承故障振动模型及其应用研究[J].华中理工大学学报,1997,25(3):50-53. ZHANG Zhongmin,LU Wenxiang,YANG Shuzi,et al.A model for the vibration produced by local faults in roller bearing and its application[J].Journal of Huazhong University of Science and Technology,1997,25(3):50-53.(in Chinese)
[17]	张亢,程军圣,杨宇.基于自适应波形匹配延拓的局部均值分解端点效应处理方法[J].中国机械工程,2010,21(4):457-462. ZHANG Kang,CHENG Junsheng,YANG Yu.Processing method for end effects of local mean decomposition based on self-adaptive waveform matching extending[J].China Mechanical Engineering,2010,21(4):457-462.(in Chinese)
[18]	张亢,程军圣,杨宇.局部均值分解方法中乘积函数判据问题研究[J].振动与冲击,2011,30(9):84-88. ZHANG Kang,CHENG Junsheng,YANG Yu.Research on the product function criterion in local mean decomposition method[J].Journal of Vibration and Shock,2011,30(9):84-88.(in Chinese)
