三头部燃烧室火焰筒壁面温度测试研究

熊庆荣; 朱国成; 钟明

doi:10.13224/j.cnki.jasp.2016.04.002

三头部燃烧室火焰筒壁面温度测试研究

doi: 10.13224/j.cnki.jasp.2016.04.002

中国航空工业集团公司中国燃气涡轮研究院, 四川江油 621703

详细信息

作者简介:
熊庆荣(1959-),男,贵州修文人,高级工程师,主要从事发动机测试技术研究.

中图分类号: V231.3
计量
- 文章访问数: 1189
- HTML浏览量: 90
- PDF量: 669
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-09
- 刊出日期: 2016-04-28

Experimental investigation of temperature measurement on the wall of flame tube for a triple combustor

China Gas Turbine Establishment, Aviation Industry Corporation of China, Jiangyou Sichuan 621703, China

摘要

摘要: 为对3种不同冷却结构形式的三头部燃烧室冷却效果做出评定,采用K型铠装热电偶和示温漆技术同时对燃烧室3种火焰筒的表面温度进行试验测试研究.试验结果表明:有限的热电偶只能测试局部的火焰筒温度,难以全面反映燃烧室火焰筒冷却效果;示温漆测试技术能有效的区分出燃烧室火焰筒壁面温度及显示温度场分布,示温漆等温线判读精度可达±10℃,为燃烧室3种火焰筒冷却结构效果的评定提供了数据支撑.
- 燃烧室 /
- 火焰筒 /
- 示温漆 /
- 壁温测量 /
- 等温线
Abstract: In order to study the best cooling style for a triple combustor of three different cooling styles, temperature-sensitive paints and thermocouple were used to study of wall temperature profiles of the flame tube. The result show that, it is difficult to distinguish cooling effect when using a few thermocouples to measure the wall temperature; the best cooling style of flame tube could be analyzed by temperature-sensitive paints, including wall temperature and temperature distribution; the temperature recognition accuracy based on isotherm temperature identification is ±10℃, the experiment result is an important reference to compare and assess the cooling effect of flame tube.
- combustor /
- flame tube /
- temperature-sensitive paints /
- wall temperature measurement /
- isotherm
