带斜孔肋大宽高比矩形通道的强化传热特性

朱强华; 崔苗; 高效伟

doi:10.13224/j.cnki.jasp.2016.04.003

带斜孔肋大宽高比矩形通道的强化传热特性

doi: 10.13224/j.cnki.jasp.2016.04.003

大连理工大学航空航天学院工业装备结构分析国家重点实验室, 辽宁大连 116024

基金项目:

国家自然科学基金(51206014)

中央高校基本科研业务费专项资助(DUT2014040)

详细信息

作者简介:
朱强华(1980-),男,江西南昌人,讲师,博士,研究方向为叶轮机气动热力学.

中图分类号: V231.1
计量
- 文章访问数: 1168
- HTML浏览量: 143
- PDF量: 576
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-25
- 刊出日期: 2016-04-28

Enhanced heat transfer characteristics in a large aspect ratio rectangular channel with inclined perforated rib

State Key Laboratory of Structural Analysis for Industrial Equipment, School of Aeronautics and Astronautics, Dalian University of Technology, Dalian Liaoning 116024, China

摘要

摘要: 为了获得带斜孔肋大宽高比矩形通道的强化传热特性,并寻求最佳的孔排倾斜角度,调节孔排倾斜角度和通道雷诺数,使其分别在0°~30°和3×10⁴~9×10⁴范围内变化,通过数值计算系统分析了通道摩擦因数和带肋壁努塞尔数等参数的变化规律.研究发现:相比于常规肋片,新型斜孔肋有效改善了肋片后方紧邻肋片的局部区域的壁面换热,并降低通道的摩擦因数,但传热增强因子有所减小;随着孔排倾斜角度的增大,通道的相对摩擦因子单调升高,传热增强因子则呈现出先升高后降低的变化过程,因此存在着最优孔排倾斜角度为15°,此时斜孔肋的强化传热综合指标达到最大值;随着通道雷诺数的增大,斜孔肋通道的摩擦因数小幅减小,换热则逐渐增强.
- 实体肋 /
- 斜孔肋 /
- 强化传热 /
- 冷却效率 /
- 矩形通道
Abstract: The enhanced heat transfer characteristics of inclined perforated rib in a large aspect ratio rectangular passage were studied through numerical simulations. The holes inclination angle and entrance flow Reynolds number were adjusted in the range of 0°-30° and 3×10⁴-9×10⁴ respectively. The variation laws of channel friction factor and its rib-wall Nusselt number with these parameters were system analyzed. The calculation results reveal that the inclined perforated rib has a lower friction factor and an improved local heat transfer immediately downstream from the perforated rib due to the impingement of jet-like flows as compared with the solid rib. With the increasing of holes inclination angle, the relative friction factor is elevated monotonously, and the averaged Nusselt number ratio take on up-down tendency, therefore an optimal holes inclination angle is 15°, when the thermal performance factor reached its maximum. The friction factor slightly decreases and the averaged Nusselt number gradually increases with the increasing of Reynolds number for the inclined perforated rib.
- solid rib /
- inclined perforated rib /
- enhanced heat transfer /
- cooling efficiency /
- rectangular channel

HTML

参考文献(19)

[1]	Han J C,Dutta S,Ekkad S.Gas turbine heat transfer and cooling technology[M].2nd ed.London:CRC Press,2012.
[2]	曹玉璋.航空发动机传热学[M].北京:北京航空航天大学出版社,2005.
[3]	Taslim M E,Bakhtari K,Liu H.Experimental and numerical investigation of impingement on a rib-roughened leading-edge wall[J].Journal of Turbomachinery,2003,125(4):682-691.
[4]	Yan W M,Liu H C,Soong C Y,et al.Experimental study of impinging heat transfer along rib-roughened walls by using transient liquid crystal technique[J]. International Journal of Heat and Mass Transfer,2005,48(12):2420-2428.
[5]	Yan W M,Mei S C.Measurement of detailed heat transfer along rib-roughened surface under arrays of impinging elliptic jets[J].International Journal Heat and Mass Transfer,2006,49(1/2):159-170.
[6]	Xing Y F,Weigand B.Experimental investigation on staggered impingement heat transfer on a rib roughened plate with different crossflow schemes[R].ASME Paper 2010-GT-22043,2010.
[7]	Sebastian S,Xing Y F,Bernhard W.An experimental and numerical study of heat transfer from arrays of impinging jets with surface ribs[J].Journal of Heat Transfer,2012,134(8):082201.1-082201.11.
[8]	Caliskan S,Baskaya S.Experimental investigation of impinging jet array heat transfer from a surface with V-shaped and convergent-divergent ribs[J].International Journal of Thermal Sciences,2012,59(9):234-246.
[9]	Hwang J J,Liou T M.Heat transfer augmentation in a rectangular channel with slit rib-turbulators on two opposite walls[J].Journal of Turbomachinery,1997,119(3):617-623.
[10]	Liou T M,Kao C W,Chen S H.Flowfield investigation of the effect of rib open area ratio in a rectangular duct[J].Journal of Fluids Engineering,1998,120(3):504-512.
[11]	Panigrahi P K,Schröder A,Kompenhans J.PIV investi-gation of flow behind surface mounted permeable ribs[J].Experiments in Fluids,2006,40(2):277-300.
[12]	Shaalan M R,Ahmad S A,Abdul-Lateef A E.Flow and heat transfer performance of a rectangular channel with solid and perforated ribs[R].AIAA-2006-3591,2006.
[13]	Panigrahi P K,Schroeder A,Kompenhans J.Turbulent structures and budgets behind permeable ribs[J]. Experi-mental Thermal and Fluid Science,2008,32(4):1011-1033.
[14]	Shin S,Kwak J S.Effect of hole shape on the heat transfer in a rectangular duct with perforated blockage walls[J].Journal of Mechanical Science and Technology,2008,22(10):1945-1951.
[15]	Huang K D,Tzeng S C,Jeng T M,et al.Experimental study of fluid flow and heat transfer characteristics in the square channel with a perforation baffle[J].International Communications in Heat and Mass Transfer,2008,35(9):1106-1112.
[16]	Sundén B.Convective heat transfer and fluid flow physics in some ribbed ducts using liquid crystal thermography and PIV measuring techniques[J].Heat and Mass Transfer,2011,47(8):899-910.
[17]	Nuntadusit C,Wae-Hayee M,Bunyajitradulya A,et al.Thermal visualization on surface with transverse perforated ribs[J].International Communications in Heat and Mass Transfer,2012,39(5):634-639.
[18]	朱强华,崔苗,高效伟.肋开孔高度对大宽高比矩形通道流动传热的影响[J].推进技术,2014,35(12):1630-1638. ZHU Qianghua,CUI Miao,GAO Xiaowei.Effects of holes height on flow and heat transfer in a ribbed rectangular channel with large aspect ratio[J].Journal of Propulsion Technology,2014,35(12):1630-1638.(in Chinese)
[19]	陶文铨.数值传热学[M].2版.西安:西安交通大学出版社,2001.
