电荷作用对均质-非均质凝结流动的影响

崔可; 刘华坪; 宋彦萍; 陈焕龙; 陈浮

doi:10.13224/j.cnki.jasp.2016.04.004

电荷作用对均质-非均质凝结流动的影响

doi: 10.13224/j.cnki.jasp.2016.04.004

哈尔滨工业大学能源科学与工程学院, 哈尔滨 150001

基金项目:

国家自然科学基金(51306042,51121004)

详细信息

作者简介:
崔可(1987-),男,湖南湘潭人,博士生,主要从事叶轮机械内湿蒸气两相流动方面的研究.

中图分类号: V231.1
计量
- 文章访问数: 1090
- HTML浏览量: 59
- PDF量: 627
- 被引次数: 0
出版历程
- 收稿日期: 2015-07-06
- 刊出日期: 2016-04-28

Charge-effect on the homo-heterogeneous condensing flow

School of Energy Science and Engineering, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 基于Fletcher成核理论及均质-非均质凝结双流体模型,讨论了电荷作用对凝结流动的影响,结果表明:有无电荷影响时,成核率计算公式精度均较高,流场参数的计算结果与实验结果吻合良好,相对误差不超过5%,表明所建的均质-非均质凝结双流体模型具有较高精度.不带电时,加入颗粒半径为5nm颗粒前后流场过冷度差别较小,加入颗粒半径分别为8nm和10nm颗粒后过冷度峰值虽分别降低2K和7K,但均导致自发凝结向下游迁移.当颗粒带电荷量为Q=1e,加入颗粒半径为5nm颗粒情况下对减小成核自由能障、增加非均质成核率的作用最为明显,这一作用在颗粒半径为8nm时较弱,颗粒半径为10nm情况下最弱.当带电量增加至Q=3e时,加入颗粒半径分别为5nm和8nm颗粒情况下峰值过冷度与均质凝结相比分别下降10K和6K,且较明显地抑制了自发凝结发生.
- 电荷作用 /
- 非均质凝结 /
- 成核 /
- 过冷度 /
- 湿蒸汽
Abstract: Based on the Fletcher's nucleation theory and the two-fluid model for homo-heterogeneous condensation, the effect of charge-effect on the condensing flow was discussed. The results show that the formula of the nucleation rate calculation with or without charge-effect both have high resolution. The calculated results are in good agreement with the experimented results and the relative error is not than 5%, indicating that the two-fluid model for homo-heterogeneous condensation has high precision. When the particle is not charged, the difference of supercooling in the flow field before and after the input of particles with 5nm radius is small. Although the input of 8nm and 10nm radius particles reduces the peak value of the supercooling as 2K and 7K respectively, it also causes the downstream migration of spontaneous condensation. When the particles are charged with a unit of electrical charge, i.e. Q=1e, the input of 5nm radius particles shows most obvious effect on decreasing the nucleation energy barrier and improving the heterogeneous nucleation rate. This effect becomes weaker and even weakest with the input of 8nm and 10nm radius particles respectively. As the charge rise up to three units of electrical charge, the input of 5nm and 8nm radius particles reduce the peak value of supercooling as 10K and 6K compared with homogeneous condensation respectively, which also obviously inhibit the occurrence of homogeneous condensation.
- charge-effect /
- heterogeneous condensation /
- nucleation /
- supercooling /
- wet steam

HTML

参考文献(25)

[1]	陈红梅,李亮,丰镇平,等.透平级中自发凝结及叶栅中非均质凝结流动的初步研究[J].工程热物理学报,2005,26(增刊1):65-68. CHEN Hongmei,LI Liang,FENG Zhenping,et al.Preliminary studies on wei steam flow with homogenous condensation in a turbine stage and heterogeneous in cascade[J].Journal of Engineering Thermophysics,2005,26(suppl.1):65-68.(in Chinese)
[2]	李亮,丰镇平,李国君.平面叶栅中湿蒸汽两相凝结流动数值模拟[J].工程热物理学报,2002,23(3):309-311. LI Liang,FENG Zhenping,LI Guojun.Numerical simulation of wet steam flow with spontaneous condensation in turbine cascade[J].Journal of Engineering Thermophysics,2002,23(3):309-311.(in Chinese)
[3]	牛凤仙,蔡小舒,宋廷勇,等.300 MW汽轮机内异质均质凝结的实验研究[J].中国电机工程学报,2009,29(29):1-6. NIU Fengxian,CAI Xiaoshu,SONG Tingyong,et al.Experimental study of heterogeneous and homogeneous condensation in a 300MW turbine[J].Proceedings of the CSEE,2009,29(29):1-6.(in Chinese)
[4]	Moore M J,Sieverding C H.Two-phase steam flow in turbines and separator[M].New York:Hemisphere Publishing Corporation,1972:174-202.
[5]	Hanzal V.Experimental determination of size and number of herterogeneous condensation nuclei in steam[D].Prague,Czech Republic:Czech Technical University,2005.
[6]	李亮,丰镇平,陈红梅,等.凝结理论在汽轮机设计中应用的探讨[J].热力透平,2005,34(1):36-40. LI Liang,FENG Zhenping,CHEN Hongmei,et al.Study on application of condensation theory to design of steam turbine[J].Thermal Turbine,2005,34(1):36-40.(in Chinese)
[7]	郭平生,刘海力.电离子作为凝结核时电量对液滴生长的影响[J].科学通报,2010,55(34):3340-3345. GUO Pingsheng,LIU Haili.Effect of charge on growth of droplets with ionic condensation nuclei[J].Chinese Science Bulletin,2010,55(34):3340-3345.(in Chinese)
[8]	任宇航,许祝安.水表面张力的磁化效应[J].浙江大学学报:自然科学版,1997,31(2):142-146. REN Yuhang,XU Zhu'an.The magnetic effect on the surface tension of water[J].Journal of Zhejiang University:Natural Science,1997,31(2):142-146.(in Chinese)
[9]	Hesler S,Maurer R.Electrostatic charge measurement on the turbine-condenser connection of salf river project's Navajo generating station unit 3[R].Electric Power Research Institute Project Report RP-3849-01,1998.
[10]	Rieger N F,Dooley R B.Electrostatic charge and its influence on the condensation of steam in a turbine[R].Palo,US:Electric Power Research Institute Report 1001332,2001.
[11]	Tarelin A O,Skliarov V P.Investigation of electrophysical effects in the turbine exhaust upon flow and power output[R].Palo,US:Electric Power Research Institute Report TR113091,1999.
[12]	Hesler S,Herzog J.Preliminary results for charge test in turbine exhaust conesville unit[R].Palo,US:Electric Power Research Institute Report WO8309-06,2000.
[13]	Buckley J R.A study of heterogeneous nucleation and electrostatic charge in steam flows[D].Birmingham,UK:The University of Birmingham,2003.
[14]	Guha A,Young J B.Time-marching prediction of unsteady condensation phenomena due to supercritical heat addition[R].London:Proceeding of Turbomachinery:Latest Development in a Changing Scene,1991.
[15]	Gerber A G,Mousave A.Representing poly-dispersed droplet behavior in nucleating steam flow[J].Journal of Fluids Engineering,2007,129(11):1404-1414.
[16]	Starzmann J,Schatz M,Casey M V,et al.Modelling and validation of wet steam flow in a low pressure steam turbine[R].ASME Paper GT2011-45672,2011.
[17]	Flectcher N H.The physics of rain cloud[M].Cambridge,UK:Cambridge University Press,1969.
[18]	周明翰.水蒸气在带高电量SiO2纳米微粒上之非均匀核凝现象[D].台南:国立成功大学,2009. CHOU Minghan.Heterogeneous nucleation of water vapor on highly charged nanoparticles of SiO₂[D].Tainan:National Cheng Kung University,2009.(in Chinese)
[19]	凡凤仙,杨林军,袁竹林,等.水汽在燃煤PM2.5表面异质核化特性数值预测[J].化工学报,2007,58(10):2561-2566. FAN Fengxian,YANG Linjun,YUAN Zhulin,et al.Numerical prediction of water vapor nucleation behavior on PM2.5 from coal combustion[J].Journal of Chemical Industry and Engineering,2007,58(10):2561-2566.(in Chinese)
[20]	Chen C C,Chen H C.Effects of charge and size on condensation of supersaturated water vapor on nanoparticles of SiO₂[J].Journal of Chemical Physics,2007,126(3):526-540.
[21]	Hill P G.Condensation of water vapor during supersonic expansion in nozzles[J].Journal of Fluid Mechanics,1966,25(3):593-620.
[22]	崔可,付云峰,陈焕龙,等.考虑相间滑移影响的湿蒸汽自发凝结流动数值研究[J].中国科学:技术科学,2014,44(4):417-424. CUI Ke,FU Yunfeng,CHEN Huanlong,et al.Numerical investigation of wet steam spontaneous condensing flow with considering the velocity slip[J].Scientia Sinica Techologica,2014,44(4):417-424.(in Chinese)
[23]	CUI Ke,CHEN Huanlong,SONG Yanping,et al.Research on wet steam spontaneous condensing flows considering phase transition and slip[J].Journal of Thermal Science,2013,22(4):320-326.
[24]	Moses C A,Stein G D.On the growth of steam droplets formed in a Laval nozzle using both static pressure and light scattering measurements[J].Journal of Fluids Engineering,1977,77(3):311-322.
[25]	Nasibulin A G,de la Mora J F,Kauppinen E I.Ion-induced nucleation of dibutyl phthalate vapors on spherical and non-spherical singly and multiply charged polyethylene glycol ions[J].Journal of Physical Chemistry A,2008,112(6):1133-1138.
