不同进口雷诺数下双旋流杯下游回流区特征

于博文; 张弛; 杨谦; 许全宏; 林宇震

doi:10.13224/j.cnki.jasp.2016.04.008

不同进口雷诺数下双旋流杯下游回流区特征

doi: 10.13224/j.cnki.jasp.2016.04.008

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室, 北京 100191

详细信息

作者简介:
于博文(1990-),男,山东济宁人,硕士生,研究领域为燃气轮机燃烧及传热传质.E-mail:dtyubw90@163.com

中图分类号: V231.2
计量
- 文章访问数: 1227
- HTML浏览量: 237
- PDF量: 620
- 被引次数: 0
出版历程
- 收稿日期: 2014-07-24
- 刊出日期: 2016-04-28

Characteristics of the recirculation zone downstream a dual-swirl cup at varied inlet Reynolds numbers

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 为了分析旋流杯下游流场结构对航空燃气轮机燃烧室性能影响的作用,利用PIV(激光粒子测速仪)技术,在常温常压下对双旋流杯下游冷态流场进行测试,研究进口雷诺数对双旋流杯下游回流区的影响.试验结果表明:当进口雷诺数较低时,下游流场结构为收扩型;当进口雷诺数增大到25000后,流场结构变为扩张型;之后继续增加进口雷诺数,回流区流场结构不再改变,但回流区内的无量纲回流速度会随之增加.
- 航空燃气轮机 /
- 燃烧室 /
- 旋流杯 /
- 回流区 /
- 雷诺数
Abstract: To analyze the role of the flow structure downstream the swirl cup on the performance of aero gas turbine combustors, PIV (particle image velocimetry) was used to measure the non-reacting flow field downstream a dual-swirl cup under ambient pressure and temperature, and the effect of the inlet Reynolds number on the recirculation zone downstream a dual-swirl cup was studied. The experimental results indicate that the flow structure downstream is a converge-diverge type when the inlet Reynolds number is low. As the inlet Reynolds number increases to 25000, the flow structure turns to a diverge type.Then the flow structure of recirculation zone remains unchanged with increasing inlet Reynolds number, but the normalized velocities in the recirculation zone would increase accordingly.
- aero gas turbine /
- combustor /
- swirl cup /
- recirculation zone /
- Reynolds number

HTML

参考文献(18)

[1]	彭云晖,林宇震,许全宏,等.双旋流空气雾化喷嘴喷雾,流动和燃烧性能[J].航空学报,2008,29(1):1-14. PENG Yunhui,LIN Yuzhen,XU Quanhong,et al.Atomization,aerodynamics and combustion performance of swirl cup[J].Acta Aeronautica et Astronautica Sinica,2008,29(1):1-14.(in Chinese)
[2]	Weigand P,Meier W,Duan X R,et al.Investigations of swirl flames in a gas turbine model combustor:Ⅰ flow field,structures,temperature,and species distributions[J].Combustion and Flame,2006,144(1):205-224.
[3]	党新宪,赵坚行,徐榕,等.试验研究旋流数对燃烧室气动性能的影响[J].航空动力学报,2011,26(1):21-27. DANG Xinxian,ZHAO Jianxing,XU Rong,et al.Experimental investigation on effects of swirl number on aerodynamic characteristics of combustor[J].Journal of Aerospace Power,2011,26(1):21-27.(in Chinese)
[4]	Fureby C,Grinstein F F,Li G,et al.An experimental and computational study of a multi-swirl gas turbine combustor[J].Proceedings of the Combustion Institute,2007,31(2):3107-3114.
[5]	韩启祥,许铁军,黄健.双旋流器单头部模型燃烧室冷态流场试验[J].航空动力学报,2008,23(8):1370-1374. HAN Qixiang,XU Tiejun,HUANG Jian.Experimental study of flow field of a model combustor with two swirlers[J].Journal of Aerospace Power,2008,23(8):1370-1374.(in Chinese)
[6]	Mehta J M,Shin H W,Wisler D C.Mean velocity and turbulent flow field characteristics inside an advanced combustor swirl cup[R].AIAA 89-0215,1989.
[7]	Reddy A P,Sujith R I,Chakravarthy S R.Swirler flow field characteristics in a sudden expansion combustor geometry using PIV[R].AIAA-2005-217,2005.
[8]	林宇震,许全宏,刘高恩.燃气轮机燃烧室[M].北京:国防工业大学出版社,2008.
[9]	Cheng R K,Littlejohn D,Nazeer W A,et al.Laboratory studies of the flow field characteristics of low-swirl injectors for adaptation to fuel-flexible turbines[J].Journal of Engineering for Gas Turbines and Power,2008,130(2):277-285.
[10]	张弛,张荣伟,徐国强,等.直射式双旋流空气雾化喷嘴的雾化效果[J].航空动力学报,2006,21(5):805-809. ZHANG Chi,ZHANG Rongwei,XU Guoqiang,et al.Experimental investigation on atomization of an air-blast atomizer with plain-orifice nozzle and dual-swirl cup[J].Journal of Aerospace Power,2006,21(5):805-809.(in Chinese)
[11]	Melling A.Tracer particles and seeding for particle image velocimetry[J].Measurement Science and Technology,1997,8(12):1406-1416.
[12]	Fu Y,Cai J,Jeng S M,et al.Confinement effects on the swirling flow of a counter-rotating swirl cup[R].ASME Paper 2005 GT-68622,2005.
[13]	Wicksall D M,Agrawal A K,Schefer R W,et al.The interaction of flame and flow field in a lean premixed swirl-stabilized combustor operated on H₂/CH₄/air[J].Proceedings of the Combustion Institute,2005,30(2):2875-2883.
[14]	《航空发动机设计手册》总编委会.航空发动机设计手册第9册主燃烧室[M].北京:航空工业出版社,2000.
[15]	Johnson M R,Littlejohn D,Nazeer W A,et al.A comparison of the flowfields and emissions of high-swirl injectors and low-swirl injectors for lean premixed gas turbines[J].Proceedings of the Combustion Institute,2005,30(2):2867-2874.
[16]	Wernert P,Favier D.Considerations about the phase averaging method with application to ELDV and PIV measurements over pitching airfoils[J].Experiments in Fluids,1999,27(6):473-483.
[17]	陈懋章.粘性流体动力学基础[M].北京:高等教育出版社,2002.
[18]	Lefebvre A H,Ballal D R.Gas turbine combustion-alternative fuels and emissions[M].3rd ed.Boca Raton:CRC Press,2010.
