基于表面粗糙度的超高负荷低压涡轮叶片附面层控制

孙爽; 雷志军; 卢新根; 李伟; 付宇; 董立辉

doi:10.13224/j.cnki.jasp.2016.04.010

基于表面粗糙度的超高负荷低压涡轮叶片附面层控制

doi: 10.13224/j.cnki.jasp.2016.04.010

1. 中国民航大学航空工程学院, 天津 300300;
2. 中国科学院工程热物理研究所燃气轮机实验室, 北京 100190

基金项目:

中央高校基本科研业务费专项资金(3122015C006,ZXH2012H004)

中国民航大学科研启动资金(2014QD22X,2014QD21X,2015QD02S)

国家自然科学基金(51306176)

详细信息

作者简介:
孙爽(1983-),男,天津人,讲师,博士,主要从事航空发动机气动热力学研究.

中图分类号: V213
计量
- 文章访问数: 1604
- HTML浏览量: 116
- PDF量: 745
- 被引次数: 0
出版历程
- 收稿日期: 2015-10-20
- 刊出日期: 2016-04-28

Boundary layer control of ultra-high-lift low pressure turbine blade with surface roughness

1. Department of Aviation Engineering, Civil Aviation University of China, Tianjin 300300, China;
2. Gas Turbine Laboratory, Institute of Engineering Thermophyiscs, Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 实验研究了表面粗糙度对PACKD-A低压涡轮叶型损失及附面层特性的影响.实验分别在定常来流与非定常条件下进行,非定常条件下的上游尾迹通过运动的圆棒来模拟.粗糙叶片通过在光洁叶片表面切槽,埋入砂纸制作成型.叶型损失与吸力面载荷使用气动探针与壁面静压孔结合压差传感器来测量,附面层流场使用热线探针来测量.结果表明:覆盖5.2%吸力面弦长(起始于44.3%吸力面弦长,终止于49.5%吸力面弦长),粗糙高度为8.82μm的控制方案在非定常条件下效果最佳,该方案可在整个考察雷诺数范围内(3×10⁴~12×10⁴)降低叶型损失;覆盖19.5%吸力面弦长(起始于30%吸力面弦长,终止于49.5%吸力面弦长),粗糙高度为20.91μm的控制方案在定常条件下效果最佳,该方案可在低雷诺数范围内(小于8×10⁴)降低叶型损失、扩大叶型正常工作雷诺数范围,但在高雷诺数下(大于8×10⁴),却带来了一定的额外损失.
- 分离 /
- 表面粗糙度 /
- 上游尾迹 /
- 自然转捩 /
- 尾迹诱导转捩
Abstract: The effects of surface roughness on the aerodynamic performance and boundary layer condition of low pressure turbine blade PACKD-A were investigated experimentally under steady state and unsteady state. The upstream wakes were simulated by the rotating bars, thus, an unsteady environment state was formed. To produce the roughness blades, the sandpaper was stuck into the slot, which was incised on the smooth blade. The profile loss and the loading of the suction side were measured by aerodynamic probes and static pressure holes associated with the pressure transducer. And the details of the boundary layer were measured with a single hotwire probe. Result shows that the roughness strips covering 5.2% suction surface length (starting at 44.3% suction surface length, stopping at 49.5% suction surface length) and with 8.82μm roughness height have a better performance than others in the unsteady state. The profile loss is reduced with this roughness strip with the whole tested Reynolds number(3×10⁴~12×10⁴). In addition, the roughness strips covering 19.5% suction surface length (starting at 30% suction surface length, stopping at 49.5% suction surface length) and with 20.91μm roughness height reduce the profile loss and extended the operating margin of the turbine blade with low Reynolds number(less than 8×10⁴) under steady state. However, some additional profile loss is produced with this type of roughness with high Reynolds number(more than 8×10⁴).
- separation /
- surface roughness /
- upstream wakes /
- nature transition /
- wake-induced transition

HTML

参考文献(31)

[1]	Hodson H P,Howell R J.The role of transition in high-lift low-pressure turbines for aero-engines[J].Progress in Aerospace Sciences,2005,41(6):419-454.
[2]	Praisner T J,Grover E A,Knezevici D C,et al.Toward the expansion of low-pressure-turbine airfoil design space[J].Journal of Turbomachinery,2013,135(6):061007.1-061007.8.
[3]	Bons J P,Pluim J,Gompertz K,et al.The application of flow control to an aft-loaded low pressure turbine cascade with unsteady wakes[J].Journal of Turbomachinery,2011,134(3):031009.1-031009.11.
[4]	Curtis E M,Hodson H P,Banieghbal M R,et al. Development of blade profiles for low-pressure turbine applications[J].Journal of Turbomachinery,1997,119(3):531-538.
[5]	Hourmouziadis J.Aerodynamic design of low pressure turbines[R]. Advisory Group for Aerospace Research and Development,AGARD No.167,1989.
[6]	Zhang X F,Vera M,Hodson H P,et al.Separation and transition control on an aft-loaded ultra-high-lift LP turbine blade at low Reynolds numbers:low-speed investigation[J].Journal of Turbomachinery,2005,128(3):517-527.
[7]	Volino R J.Separation control on low-pressure turbine airfoils using synthetic vortex generator jets[J].Journal of Turbomachinery,2003,125(4):765-777.
[8]	Mack M,Niehui R.Boundary layer control on a low pressure turbine blade by means of pulsed blowing[R].ASME Paper GT2012-69029,2012.
[9]	Huang J,Corke T C,Thomas F O.Plasma actuators for separation control of low pressure turbine blades[J].AIAA Journal,2006,44(1):51-57.
[10]	Lake J P,King P I,Rivir R B.Reduction of separation losses on a turbine blade with low Reynolds number[R].AIAA 99-0242,1999.
[11]	Lake J P,King P I, Rivir R B.Low Reynolds number loss reduction on turbine blades with dimples and V-grooves[R].AIAA-2000-0738,2000.
[12]	Vera M,Zhang X F,Hodson H,et al.Separation and transition control on an aft-loaded ultra-high-lift LP turbine blade at low Reynolds numbers:high-speed validation[J].Journal of Turbomachinery,2006,129(2):340-347.
[13]	Martinstetter M,Niehuis R.Passive boundary layer control on a highly loaded low pressure turbine cascade[R].ASME Paper GT2010-22739,2010.
[14]	Boynton J L,Tabibzadeh R,Hudson S T.Investigation of rotor blade roughness effects on turbine performance[J].Journal of Turbomachinery,1993,115(3):614-620.
[15]	Abuaf N,Bunker R S,Lee C P.Effects of surface roughness on heat transfer and aerodynamic performance of turbine airfoils[J].Journal of Turbomachinery,1998,120(3):522-529.
[16]	Zhang Q,Goodro M,Ligrani P M,et al.Influence of surface roughness on the aerodynamic losses of a turbine vane[J]. Journal of Fluids Engineering,2005,128(3):568-578.
[17]	Bons J P. A review of surface roughness effects in gas turbine[J].Journal of Turbomachinery,2010,132(2):021004.1-021004.16.
[18]	Ramesh O N,Hodson H P,Harvey N W.Separation control in ultra high lift airfoils by unsteadiness and surface roughness[R].Bangalore,India:15th International Symposium on Airbreathing Engines,2001.
[19]	Lorenz M,Schulz A,Bauer H J.Experimental study of surface roughness effects on a turbine airfoil in a linear cascade:Part Ⅱ aerodynamic losses[J].Journal of Turbomachinery,2011,134(4):041007.1-041007.10.
[20]	Montomoli F,Hodson H,Haselbach F.Effect of roughness and unsteadiness on the performance of a new low pressure turbine blade at low Reynolds numbers[J].Journal of Turbomachinery,2010,132(3):031018.1-031018.9.
[21]	Montis M,Niehuis R,Fiala A.Aerodynamic measurements on a low pressure turbine cascade with different levels of distributed roughness[R].ASME Paper GT2011-45015,2011.
[22]	王英锋,胡骏,罗标能,等.上游叶片尾迹对转子叶片非定常表面压力频谱特性影响的研究[J].航空动力学报,2006,21(4):693-699. WANG Yingfeng,HU Jun,LUO Biaoneng,et al.Effects of the up-stream blade wakes on the spectrum of rotor blade unsteady surface pressure[J].Journal of Aerospace Power,2006,21(4):693-699.(in Chinese)
[23]	WANG Zhiqiang,HU Jun,WANG Yingfeng,et al.Effects of up-stream rotor on the aerodynamic force on down-stream stator blades.[J].Transactions of Nanjing University of Aeronautics and Astronautics,2006,27(2):94-101.
[24]	罗华玲,乔渭阳.低压涡轮叶型边界层相互作用的数值模拟[J].推进技术,2009,30(1):95-100. LUO Hualing,QIAO Weiyang.Numerical simulation for interaction between wake and boundary layer on a low-pressure turbine profile[J].Journal of Propulsion Technology,2009,30(1):95-100.(in Chinese)
[25]	乔渭阳,赵磊,罗华玲,等.低雷诺数涡轮叶片边界层转捩及分离特性测量[J].推进技术,2012,33(6):859-865. QIAO Weiyang,ZHAO Lei,LUO Hualing,et al.Measurement of the transition and separation for turbine blade boundary layer with low-Reynolds number[J].Journal of Propulsion Technology,2012,33(6):859-865.(in Chinese)
[26]	张士明,杨策,胡良军,等.离心压气机内部非定常流场的数值模拟[J].工程热物理学报,2007,28(6):942-944. ZHANG Shiming,YANG Ce,HU Liangjun,et al.Numerical simulation of unsteady flow in centrifugal compressor[J].Journal of Engineering Thermophysics,2007,28(6):942-944.(in Chinese)
[27]	刘尹红,杨策,赵奔,等.轴径流组合压气机中动叶尾迹与势流叠加特性的数值研究[J].航空动力学报,2013,28(5):1037-1046. LIU Yinhong,YANG Ce,ZHAO Ben,et al.Numerical investigation on superimposed effect of wake/potential interaction in axial-radial combined compressor[J].Journal of Aerospace Power,2013,28(5):1037-1046.(in Chinese)
[28]	Volino R J,Separated flow transition under simulated low-pressure turbine airfoil conditions:Part 2 turbulence spectra[J].Journal of Turbomachinery,2002,124(4):645-655.
[29]	Mahallati A,Sjolander S A.Aerodynamics of a low-pressure turbine airfoil at low Reynolds numbers:Part Ⅱ blade-wake interaction[J].Journal of Turbomachinery,2012,135(1):011011.1-011011.10.
[30]	Schlichting H,Gersten K.Boundary layer theory[M].8th Edition.Berlin:Springer-Verlag Berlin Heidelberg,2000.
[31]	Howell R J.Wake-separation bubble interactions in low Reynolds number turbomachinery[D].Cambridge:Cambridge University,1999.
