倾对某单排叶片进口流场的影响机理

许涵; 朱芳; 金东海; 桂幸民

doi:10.13224/j.cnki.jasp.2016.04.013

倾对某单排叶片进口流场的影响机理

doi: 10.13224/j.cnki.jasp.2016.04.013

1. 北京航空航天大学能源与动力工程学院, 北京 100191;
2. 上海电气电站技术研究与发展中心燃气轮机技术研究所, 上海 201612

基金项目:

国家自然科学基金(51006005,51236001)

详细信息

作者简介:
许涵(1992-),男,山东聊城人,博士生,主要从事叶轮机械气动热力学研究.

中图分类号: V232.4
计量
- 文章访问数: 1018
- HTML浏览量: 39
- PDF量: 547
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-10
- 刊出日期: 2016-04-28

Mechanism for the effect of lean on the inlet flow of a single blade row

1. School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
2. Gas Turbine Technology Institute, Shanghai Electric Power Generation Research and Development Center, Shanghai 201612, China

摘要

摘要: 采用降维的方法考察了倾对某单排叶片进口流场的影响,利用进口流场的变化解释了倾改善端壁流动的机理.通过推导周向平均的Navier-Stokes(N-S)方程得到了周向不均匀源项的表达形式.在均匀来流条件下,周向不均匀源项的径向和周向分量在叶片通道前已经存在,表征了进口流场周向不均匀性的强弱.通过对不同倾叶栅模型的三维数值计算和周向平均后处理发现,倾会改变叶片通道进口周向不均匀源项的大小和分布,引发进口气流的径向迁移,其中正倾使进口气流有从叶根到叶尖的迁移趋势,从而可以改善端壁的流动,负倾的作用与之相反.来流马赫数、叶片稠度和安装角等气动设计参数也会对倾叶片进口周向不均匀源项产生影响,过高的来流马赫数和过大的安装角均不利于体现倾对进口流场的作用效果.
- 倾 /
- 进口流场 /
- 周向不均匀 /
- 降维 /
- 数值模拟
Abstract: The effect of lean on the inlet flow of a single blade row was studied with the dimensionality reduction method, and the mechanism for lean improving endwall condition was explained by the inlet flow change. The circumferential fluctuation(CF) source items were obtained through the derivation of the circumferentially averaged Navier-Stokes(N-S)equations. The radial and circumferential components of the CF sources existed yet before the blade passage with a uniform incoming flow, representing the magnitude of the inlet CF. Different leaned cascade models were numerically calculated and circumferentially averaged. The results indicate that lean could change the magnitude and distribution of the CF source items before the blade passage, leading to the radial migration of the inlet flow. The positive lean diverts the inlet flow from hub to tip and improves the endwall condition, while the negative lean has a contrary effect.The inlet CF sources are also affected by the aerodynamic parameters such as the inlet Mach number, blade solidity and stagger angle. Neither an over-high inlet Mach number nor an over-wide stagger angle is good for the effect of blade lean on the inlet flow.
- lean /
- inlet flow /
- circumferential fluctuation /
- dimensionality reduction /
- numerical simulation

HTML

参考文献(18)

[1]	Harrison S.The influence of blade lean on turbine loses[J].Journal of Turbomachinery,1992,114(1):184-190.
[2]	Sasaki T,Breugelmans F.Comparison of sweep and dihedral effects on compressor cascade performance[J].Journal of Turbomachinery,1998,120(3):454-463.
[3]	Breugelmans F,Carels Y,Demuth M.Influence of dihedral on the secondary flow in a two-dimensional compressor cascade[J].Journal of Engineering for Gas Turbines and Power,1984,106(3):578-584.
[4]	Gallimore S,Bolger J,Cumpsty N,et al.The use of sweep and dihedral in multistage axial flow compressor blading:Part Ⅰ university research and methods development[J].Journal of Turbomachinery,2002,124(4):521-532.
[5]	Gallimore S,Bolger J,Cumpsty N,et al.The use of sweep and dihedral in multistage axial flow compressor blading:Part Ⅱ low and high speed designs and test verification[J].Journal of Turbomachinery,2002,124(4):533-541.
[6]	Debruge L.The aerodynamic significance of fillet geometry in turbocompressor blade rows[J].Journal of Engineering for Gas Turbines and Power,1980,102(4):984-993.
[7]	Vavra M.Aero-thermodynamics and flows in tubomachines[M].New York:Wiley & Sons Inc.,1960.
[8]	Smith L,Yeh H.Sweep and dihedral effects in axial-flow turbomachinery[J].Journal of Fluids Engineering,1963,85(3):401-414.
[9]	Smith L.The radial-equilibrium equation of turbomachinery[J].Journal of Engineering for Gas Turbines and Power,1966,88(1):1-12.
[10]	Gummer V,Wenger U,Kau H.Using sweep and dihedral to control three-dimensional flow in transonic stators of axial compressors[J].Journal of Turbomachinery,2001,123(1):40-48.
[11]	D'Ippolito G, Dossena V,Mora A.The influence of blade lean on straight and annular turbine cascade flow field[J].Journal of Turbomachinery,2011,133(1):011013.1-011013.9.
[12]	GUI Xingmin,ZHU Fang,WAN Ke,et al.Effects of inlet circumferential fluctuation on the sweep aerodynamic performance of axial fans/compressors[J].Journal of Thermal Science,2013,22(5):383-394.
[13]	朱芳.民用航空发动机高流通高效率风扇/增压级设计技术研究[D].北京:北京航空航天大学,2013. ZHU Fang.Study on design techniques of high through flow and high efficiency fan/booster of civil aeroengine[D].Beijing:Beijing University of Aeronautics and Astronautics,2013.(in Chinese)
[14]	Steinert W,Eisenberg B,Starken H.Design and testing of a controlled diffusion airfoil cascade for industrial axial flow compressor application[J].Journal of Turbomachinery,1991,113(4):583-590.
[15]	NUMECA Int.Numeca's flow integrated environment for turbomachinery and internal flows:user manual[M].Brussels,Belgium:NUMECA International,2000.
[16]	WAN Ke,JIN Hailiang,JIN Donghai,et al.Influence of non-axisymmetric terms on circumferentially averaged method in fan/compressor[J].Journal of Thermal Science,2013,22(1):13-22.
[17]	Simon J.Contribution to throughflow modelling for axial flow turbomachines[D].Liege,Belgium:University of Liege,2007.
[18]	金海良.周向平均方法在多级轴流风扇/压气机设计与分析中的应用[D].北京:北京航空航天大学,2011. JIN Hailiang.Application of circumferentional average method in multistage axial fan/compressor design and analysis[D].Beijing:Beijing University of Aeronautics and Astronautics,2011.(in Chinese)
