局部喘振的发生机理

潘天宇; 孙太璐; 李志平; 李秋实

doi:10.13224/j.cnki.jasp.2016.04.014

局部喘振的发生机理

doi: 10.13224/j.cnki.jasp.2016.04.014

1. 北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室, 北京 100191;
2. 先进航空发动机协同创新中心, 北京 100191

基金项目:

国家自然科学基金(51176005)

详细信息

作者简介:
潘天宇(1989-),男,北京人,博士生,主要从事叶轮机械流动不稳定性研究.

中图分类号: V231.3
计量
- 文章访问数: 1084
- HTML浏览量: 56
- PDF量: 572
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-06
- 刊出日期: 2016-04-28

Occurrence mechanism of partial surge

1. National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China;
2. Collaborative Innovation Center for Advanced Aero-Engine, Beijing 100191, China

摘要

摘要: 为了深入研究高负荷压气机的失稳机制,明确失稳先兆局部喘振现象的发生机理,总结了某跨声压气机在均匀进气不同工作转速下失稳过程的实验结果,继而对其在进气畸变条件的失稳过程开展实验和数值研究.结果发现:在均匀进气条件下,局部喘振在低转速时并未发生,而发生于高转速情况下,推断局部喘振的发生与压气机叶根区域的相对高负荷有关.随后在高转速下降低叶根负荷,则局部喘振现象不再发生;而在低转速下升高叶根负荷,则局部喘振现象发生.所以得出结论,压气机叶根相对高负荷确实为局部喘振的发生条件.对于所研究的压气机,如果近失速点叶根扩散因子超过0.6,则会发生局部喘振现象.
- 局部喘振 /
- 负荷分布 /
- 跨声速压气机 /
- 失稳先兆 /
- 进气总压畸变
Abstract: To fully understand the instability mechanism of highly load compressors, the occurrence mechanism of instability inception partial surge was studied in detail. Based on the experimental data of instability evolution at different rotation speeds and uniform intake of a transonic compressor, the instability evolution under inlet distortion was studied by experimental and numerical methods. The results show that under uniform intake, partial surge can only be detected at high rotation speed while at low rotation speed partial surge can't be detected. So it can be supposed that high blade loading at hub is related to the occurrence of partial surge. The results under different inlet condition suggest that lower blade loading in the hub region could prevent the occurrence of partial surge at high rotation speed while partial surge would occur at the low rotation speed if the blade loading in the hub region is higher. High blade loading in the hub is proved as a necessary condition for the occurrence of partial surge. In this compressor, if the diffusion factor exceeds 0.6 at near stall point, partial surge may occur.
- partial surge /
- load distribution /
- transonic compressor /
- instability inception /
- inlet total pressure distortion

HTML

参考文献(21)

[1]	Emmons H W,Pearson C E,Grant H P.Compressor surge and stall propagation[J].Transactions of the ASME,1955,77(4):455-469.
[2]	Greitzer E M.Surge and rotating stall in axial flow compressors:Part Ⅰ theoretical compression system model[J].Journal of Engineering for Gas Turbines and Power,1976,98(2):190-198.
[3]	Greitzer E M.Surge and rotating stall in axial flow compressors:Part Ⅱ experimental results and comparison with theory[J].Journal of Engineering for Gas Turbines and Power,1976,98(2):199-211.
[4]	Greitzer E M.Some aerodynamic problems of aircraft engines:fifty years after the 2007 IGTI scholar lecture[J].Journal of Turbomachinery,2009,131(3):031101.1-031101.13.
[5]	Moore F K.A theory of rotating stall of multistage axial compressors:Part Ⅰ small disturbances[J].Journal of Engineering for Gas Turbines and Power,1984,106(2):313-320.
[6]	Moore F K.A theory of rotating stall of multistage axial compressors:Part Ⅱ finite disturbances[J].Journal of Engineering for Gas Turbines and Power,1984,106(2):321-326.
[7]	Longley J P.A review of nonsteady flow models for compressor stability[J].Journal of Turbomachinery,1994,116(2):202-215.
[8]	Camp T R,Day I J.A study of spike and modal stall phenomena in a low-speed axial compressor[J].Journal of Turbomachinery,1998,120(3):393-401.
[9]	Gong Y,Greitzer E M,Tan C S,et al.A computational model for short-wavelength stall inception and development in multistage compressors[J].Journal of Turbomachinery,1999,121(4):726-734.
[10]	Young A,Day I,Pullan,G.Stall warning by blade pressure signature analysis[J].Journal of Turbomachinery,2013,135(1):011033.1-011033.10.
[11]	Khalid S A,Khalsa A S,Waitz I A,et al.Endwall blockage in axial compressors[J].Journal of Turbomachinery,1999,121(3):499-509.
[12]	Suder K L,Celestina M L.Experimental and computational investigation of the tip clearance flow in a transonic axial compressor rotor[J].Journal of Turbomachinery,1996,118(2):218-229.
[13]	Simpson A K,Longley J P.An experimental study of the inception of rotating stall in a single-stage low-speed axial compressor[R].ASME Paper GT2007-27181,2007.
[14]	Vo H D.Role of tip clearance flow on axial compressor stability[D].Cambridge,US:Massachusetts Institute of Technology,2002.
[15]	Weichert S,Day I.Detailed measurements of spike formation in an axial compressor[J].Journal of Turbomachinery,2014,136(5):2555-2565.
[16]	Pullan G,Young A,Day I,et al.Origins and structure of spike-type rotating stall[R].ASME Paper GT2014-68707,2014.
[17]	Dodds J,Vahdati M.Rotating stall observations in a high speed compressor:Part Ⅰ experimental study[J].Journal of Turbomachinery,2015,137(5):051002.1-051002.9.
[18]	Li Q,Pan T,Li Z,et al.Experimental study of compressor instability inception in a transonic axial flow compressor[R].ASME Paper GT2014-25190,2014.
[19]	潘天宇,宋西镇,李志平,等.跨声速压气机不同转速下失稳形式的实验研究[J].推进技术,2015,36(8):1127-1134. PAN Tianyu,SONG Xizhen,LI Zhiping,et al.Effects of transonic tandem stator airfoil on stall inception in a transonic axial flow compressor[J].Journal of Propulsion Technology,2015,36(8):1127-1134.(in Chinese)
[20]	潘天宇,贺雷,王正鹤,等.局部喘振频率特性及估算方法研究[J].航空动力学报,2015,30(11):2666-2672. PAN Tianyu,HE Lei,WANG Zhenghe,et al.Study on the frequency of partial surge and estimating method[J].Journal of Aerospace Power.Accepted,2015,30(11):2666-2672.(in Chinese)
[21]	Davis G.Non-uniform flow through wire screens[D].Cambridge,UK:University of Cambridge,1957.
