极限条件下的大角度扩散段优化设计数值模拟

丛成华; 任泽斌; 杨高强; 王宁

doi:10.13224/j.cnki.jasp.2016.04.018

极限条件下的大角度扩散段优化设计数值模拟

doi: 10.13224/j.cnki.jasp.2016.04.018

1. 中国空气动力研究与发展中心空气动力学国家重点实验室, 四川绵阳 621000;
2. 中国空气动力研究与发展中心设备设计及测试技术研究所, 四川绵阳 621000

基金项目:

空气动力学国家重点实验室基金(SKLA2013A0208)

详细信息

作者简介:
丛成华(1979-),男,山东泰安人,副研究员,硕士,主要从事计算流体力学、风洞气动设计及流动控制方面的研究.

中图分类号: V211.3
计量
- 文章访问数: 1137
- HTML浏览量: 111
- PDF量: 546
- 被引次数: 0
出版历程
- 收稿日期: 2014-07-24
- 刊出日期: 2016-04-28

Numerical simulation for optimal design of wide angle diffuser in limited condition

1. State Key Laboratory of Aerodynamics, China Aerodynamics Research and Development Center, Mianyang Sichuan 621000, China;
2. Facility Design and Instrumentation Institute, China Aerodynamics Research and Development Center, Mianyang Sichuan 621000, China

摘要

摘要: 为提升某低速风洞大角度扩散段静压恢复性能,降低总压损失至分流隔板的水平,采用计算流体动力学(CFD)方法对该扩散段不同设计方案进行了模拟.采用阻尼网能有效抑制分离,阻尼网布置位置和开孔率对大角度扩散段内的流动状态和总压损失有很大影响.使用直线壁面扩散时,由于扩散角过大,第1层阻尼网对抑制大角度扩散段入口分离效果很弱,总压损失无法达到预期设定指标.采用三次曲线壁面扩散时,总压损失明显降低,小于预期指标,但存在小范围的分离.分级扩散能有效降低总压损失,按照最大静压恢复设计的分级扩散段,避免了入口的气流分离,能大幅度降低总压损失.对分级扩散的进一步研究表明,按照最大静压恢复设计的第1级扩散段扩散角已达到上限,为抑制第3级扩散段的分离,缩短第2级扩散段,减小第3级扩散段扩散角的方法是合理的.通过对不同方案流态的比较得出了最佳的参数匹配,总压损失指标达到了设计要求.因此采用数值模拟能够获得最佳的大角度扩散段设计结果.
- 低速风洞 /
- 大角度扩散段 /
- 阻尼网 /
- 总压损失 /
- 流动控制 /
- 优化设计
Abstract: In order to improve the static pressure recovery of specific low speed wind tunnel wide angle diffuser(WAD) and reduce the total pressure loss to the level of the splitter plates, different configurations of WAD were studied using computational fluid dynamics (CFD). The screens could restrain flow separation. The position and opening area ratio of the screens had an important effect on the flow regimes and total pressure loss. The total pressure loss using linear wall WAD was greater than the expected value. Due to the oversize diffuser angle, the first screen played a little role on separation control of WAD inlet. By use of cubic curve wall, the total pressure loss evidently decreased and was less than the expected value. But a little separation in WAD existed. Simple segment linear walls had profound function on the drop of total pressure loss. Based on the method of maximum static pressure recovery, WAD using three segment linear walls was designed. The separation of inlet disappeared. And the total pressure loss was reduced to a great extent. Further investigation on the diffuser of three segment linear walls indicated that the angle of the first level diffuser was upper limit to the edge of separation based on the method of maximum static pressure recovery. To restrain separation of the third level diffuser, the method was reasonable to shorten the second level diffuser length and reduce the third level diffuser angle. Combination of satisfactory parameters, which could significantly produce less total pressure loss to the expected level, was obtained based on flow regime analysis of different configurations. It is concluded that the optimal design of WAD can be obtained based on numerical simulation.
- low speed wind tunnel /
- wide angle diffuser /
- screen /
- total pressure loss /
- flow control /
- optimal design

HTML

参考文献(18)

[1]	Duell E.Recent advances in large scale aeroacoustic wind tunnels[R].AIAA-2002-2503,2002.
[2]	Schubauer G B,Spangenberg W G.Effect of screens in wide-angle diffusers[R].NACA-949,1947.
[3]	Noui-Mehidi M N.Velocity distribution downstream of an asymmetric wide-angle diffuser[J].Experimental Thermal and Fluid Science,2005,29(6):649-657.
[4]	Hancock P E.Plane multiple screens in non-uniform flow,with particular application to wind tunnel settling chamber[J].European Journal Mechanics:B Fluids,1998,17(3):357-369.
[5]	Kulkarni V.Simulation of honeycomb-screen combinations for turbulence management in a subsonic wind tunnel[J].Journal of Wind Engineering and Industrial Aerodynamics,2011,99(1):37-45.
[6]	Mehta R D.The aerodynamic design of blower tunnels with wide-angle diffusers[J].Progress in Aerospace Science,1977,18:59-120.
[7]	Sahin B.The pressure drop and flow characteristics of wide-angle screened diffusers of large area ratio[J].Journal of Wind Engineering and Industrial Aerodynamics,1995,58(1/2):33-50.
[8]	Moore C A.Some effects of vanes and of turbulence in two-dimensional wide-angle subsonic diffusers[R].NACA-TN-4080,1958.
[9]	Cochran D L.Use of short flat vanes for producing efficient wide-angle two-dimensional subsonic diffusers[R].NACA-TN-4309,1958.
[10]	Chiccine B G.Experimental investigation of expanded duct sections and screens for reducing flow distortions at subsonic flows[R].NASA-TM-1959E,1959.
[11]	Yaste D M.NWTC back-leg model tests[R].AIAA 97-0093,1997.
[12]	Grumet A A.Navier-Stokes analysis of NWTC back leg diffuser[R].AIAA 97-0094,1997.
[13]	Bouis X,Prieur J.ETW aerodynamic design:a case study[R].Hull,Canada:Advisory Group for Aerospace Research and Development AGARD CP-585,1997.
[14]	丛成华,陈振华,彭强.跨超声速风洞大开角段设计技术研究[J].空气动力学学报,2011,29(1):85-90. CONG Chenghua,CHEN Zhenhua,PENG Qiang.Study report of design technology of transonic wind tunnel's wide angle diffuser[J].Acta Aerodynamica Sinica,2011,29(1):85-90.(in Chinese)
[15]	丛成华,廖达雄,陈吉明.连续式风洞大开角扩散段流动控制数值模拟[J].工程力学,2013,30(3):424-430. CONG Chenghua,LIAO Daxiong,CHEN Jiming.Numerical simulation of flow control of wide-angle diffuser in closed-circuit continuous transonic wind tunnel[J].Engineering Mechanics,2013,30(3):424-430.(in Chinese)
[16]	Johan G S,Olle T.Numerical and experimental study of separated flow in a plane asymmetric diffuser[J].International Journal of Heat and Fluid Flow,2004,25(3):451-460.
[17]	Sinha P K,Mullick A N.Flow investigation through an annular diffuser in subsonic flow regime[J].Journal of the Institution of Engineers,2009,90(11):24-29.
[18]	Wolf T.On the possibilities for improvement and modernization of subsonic wind tunnels[R].AIAA 90-1423,1990.
