基于ADE-ELM的涡轴发动机建模方法

焦洋; 李秋红; 朱正琛; 廖光煌

doi:10.13224/j.cnki.jasp.2016.04.025

基于ADE-ELM的涡轴发动机建模方法

doi: 10.13224/j.cnki.jasp.2016.04.025

南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室, 南京 210016

详细信息

作者简介:
焦洋(1991-),男,河北昌黎人,硕士生,从事航空发动机建模与仿真研究.

中图分类号: V233.7
计量
- 文章访问数: 1022
- HTML浏览量: 121
- PDF量: 530
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-27
- 刊出日期: 2016-04-28

Turbo-shaft engine modeling method based on ADE-ELM

Jiangsu Province Key Laboratory of Aerospace Power System, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 提出了基于自适应微分进化-极端学习机(ADE-ELM)求解平衡方程的高精度涡轴发动机实时部件级模型建立方法.基于牛顿-拉夫逊(N-R)迭代模型,以迭代计算前模型平衡方程残差为输入,迭代收敛后平衡方程猜值修正量为输出,训练极端学习机,并采用自适应微分进化(ADE)算法优化极端学习机(ELM)参数,提高猜值修正量映射精度.ADE算法中采用sigmoid型自适应缩放因子,提高了微分进化算法的寻优能力.在涡轴发动机不同飞行状态下的测试结果表明,以N-R迭代算法模型为基准,基于ADE-ELM的发动机模型,最大建模误差约为一次通过算法的1/3,运算耗时约为一次通过算法的1/3,验证了算法的有效性.
- 涡轴发动机 /
- 建模 /
- 平衡方程 /
- 极端学习机 /
- 微分进化算法
Abstract: A modeling method based on adaptive differential evolution-extreme learning machine (ADE-ELM) was proposed to solve the balance equations for turbo-shaft engine models. The model achieved high accuracy and real time properties. The extreme learning machine (ELM) was trained by the data got from the Newton-Raphson (N-R) iteration model. The inputs were the residuals of balance equations before iteration, and the outputs were the adjustments of guess values after iteration. The parameters of the ELM were optimized by adaptive differential evolution (ADE) algorithm to enhance the mapping accuracy of the guess values adjustments. The sigmoid type adaptive scaling factor was adopted by ADE algorithm to improve its optimization ability. Taking the N-R iteration model as a criterion, the simulation results of ADE-ELM model under different flying states show that, the maximum modeling error is about 1/3 that of the single iteration per time step, and the time consumption is about 1/3 that of the single iteration per time step. The modeling method is valid.
- turbo-shaft engines /
- modeling /
- balance equations /
- extreme learning machine /
- differential evolution algorithm

HTML

参考文献(17)

[1]	姚文荣.涡轴发动机/旋翼综合建模控制及优化研究[D].南京:南京航空航天大学,2008. YAO Wenrong.Research on integrated modeling,control and optimization of turboshaft engine/rotor[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2008.(in Chinese)
[2]	赵永平,孙健国.最小二乘支持向量回归机在发动机推力估计中的应用[J].航空动力学报,2009,24(6):1420-1425. ZHAO Yongping,SUN Jianguo.Aeroengine thrust estimation using least squares support vector regression machine[J].Journal of Aerospace Power,2009,24(6):1420-1425.(in Chinese)
[3]	文陆军.用实测数据建立发动机的神经网络模型[D].南京:南京航空航天大学,2005. WEN Lujun.Aeroengine modeling with neural network by using practice measure data[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2005.(in Chinese)
[4]	胡宇,杨月诚,张世英,等.基于改进拟合法的涡扇发动机状态变量模型建立方法[J].推进技术,2013,34(2):405-410. HU Yu,YANG Yuecheng,ZHANG Shiying,et al.Establishment of turbofan engine state variable model based on improved fitting method[J].Journal of Propulsion Technology,2013,34(2):405-410.(in Chinese)
[5]	姜彩虹,孙志岩,王曦.航空发动机预测健康管理系统设计的关键技术[J].航空动力学报,2009,24(11):2589-2594. JIANG Caihong,SUN Zhiyan,WANG Xi.Critical technologies for aero-engine prognostics and health management systems development[J].Journal of Aerospace Power,2009,24(11):2589-2594.(in Chinese)
[6]	DeCastro J A,Litt J S,Frederick D K.A modular aero-propulsion system simulation of a large commercial aircraft engine[R].NASA/TM-2008-215303,2008.
[7]	May R D,Csank J,Lavelle T M,et al.A high-fidelity simulation of a generic commercial aircraft engine and controller[R].NASA/TM-2010-216810,2010.
[8]	Huang G B,Ding X,Zhou H.Optimization method based extreme learning machine for classification[J].Neurocomputing,2010,74(1/2/3):155-163.
[9]	Suresh S,Saraswathi S,Sundararajan N.Performance enhancement of extreme learning machine for multi-category sparse data classification problems[J].Engineering Applications of Artificial Intelligence,2010,23(7):1149-1157.
[10]	Liu N,Wang H.Ensemble based extreme learning machine[J].IEEE:Signal Processing Letters,2010,17(8):754-757.
[11]	Storn R,Price K.Differential evolution:a simple and efficient adaptive scheme for global optimization over continuous spaces[M].Berkeley,CA:International Computer Science Institute,1995.
[12]	杨启文,蔡亮,薛云灿.差分进化算法综述[J].模式识别与人工智能,2008,21(4):506-513. YANG Qiwen,CAI Liang,XUE Yuncan.A survey of differential evolution algorithms[J].Pattern Recognition and Artificial Intelligence,2008,21(4):506-513.(in Chinese)
[13]	Brest J,Greiner S,Boskovic B,et al.Self-adapting control parameters in differential evolution:a comparative study on numerical benchmark problems[J].IEEE Transactions on Evolutionary Computation,2006,10(6):646-657.
[14]	Brest J,Boskovic B,Greiner S.Performance comparison of self-adaptive and adaptive differential evolution algorithms soft computing:a fusion of foundations[J].Methodologies and Applications,2007,11(7):617-629.
[15]	Noman N,Iba H.Accelerating differential evolution using an adaptive localsearch[J].IEEE Transactions on Evolutionary Computation,2008,12(1):107-125.
[16]	张海波,王健康,陈国强.单旋翼直升机/涡轴发动机通用综合模型的构建方法:中国,102520620[P].2012-06-27.
[17]	张海波,姚文荣,陈国强.涡轴发动机/直升机综合控制仿真平台设计[J].推进技术,2011,32(3):383-390. ZHANG Haibo,YAO Wenrong,CHEN Guoqiang.Design of a numeric simulation platform for integrated turbo-shaft engine/helicopter control system[J].Journal of Propulsion Technology,2011,32(3):383-390.(in Chinese)
