支撑刚度对行星传动系统动态均载特性的影响

朱增宝; 江志祥; 尹敏

doi:10.13224/j.cnki.jasp.2016.04.027

支撑刚度对行星传动系统动态均载特性的影响

doi: 10.13224/j.cnki.jasp.2016.04.027

安徽理工大学机械工程学院, 安徽淮南 232001

基金项目:

安徽理工大学博士基金项目(ZY048)

国家自然科学基金(7150080050)

安徽省教育厅自然科学研究重点项目(KJ2013A093,KJ2013A083)

详细信息

作者简介:
朱增宝(1967-),男,安徽淮南人,教授,博士,主要从事机械设计与机械传动研究.

中图分类号: V228;TH132
计量
- 文章访问数: 956
- HTML浏览量: 105
- PDF量: 451
- 被引次数: 0
出版历程
- 收稿日期: 2014-07-31
- 刊出日期: 2016-04-28

Impact of support stiffness on dynamic load sharing characteristics of planetary train system

College of Mechanical Engineering, Anhui University of Science and Technology, Huainan Anhui 232001, China

摘要

摘要: 考虑了行星架微位移、时变啮合刚度、旋转阻尼和构件自重,建立了行星传动系统动力学微分方程.利用多领域工程系统建模、分析与优化语言Modelica进行求解,分析了各主要构件支撑刚度对行星传动系统均载特性的影响.研究结果表明:刚性支撑条件下,较小的系统误差都将引起行星轮间载荷分配严重不均匀.一个或者多个构件的支撑刚度小于10⁷N/m时系统能获得较好的均载效果.在构件支撑刚度敏感区间,随着该构件支撑刚度的增大,系统均载性能将迅速恶化.多个构件支撑刚度减小时,系统的均载效果比单个构件支撑刚度减小要好.改变其中某个行星轮的支撑刚度会使载荷在行星轮间重新分配,降低某个行星轮的支撑刚度,其分配的载荷减小.
- 行星传动 /
- 支撑刚度 /
- 动力学 /
- 均载特性 /
- Modelica语言
Abstract: The dynamic differential equation of the planetary train system was set up considering planetary carrier micro displacement, time-varying meshing stiffness, revolution damping and components gravity. The Modelica language for modeling, analyzing and optimizing the engineering system of various fields was used to solve the problem, and the impact of support stiffness of the main components on dynamic load sharing characteristics of this train was analyzed. The research results show that under the condition of rigid support, the load between the planet gears is seriously uneven at a smaller system error. When the support stiffness of one or more components is less than 10⁷N/m, a good load sharing effect of this train could be achieved. The load sharing characteristic of this train is deteriorated rapidly with the increase of this component support stiffness within the support stiffness sensitive range of corresponding component. The load sharing effect for reducing the supporting stiffness of multiple components is better than that of single ones. The load is redistributed between planetary gears while the support stiffness of a planetary gear is changed. When the support stiffness of a planetary gear is cut down, its own load is reduced.
- planetary train /
- support stiffness /
- dynamics /
- load sharing characteristic /
- Modelica language

HTML

参考文献(18)

[1]	Kahraman A.Load sharing characteristics of plantary transmission[J].Mechanisms and Machine Theory,1994,29(8):1151-1165.
[2]	Bodas A,Kahraman A.Influence of carrier and gear manufacturing errors on the static load sharing behavior of planetary gear sets[J].Japan Society of Mechanical Engineers International Journal:Series C Mechanical Systems,Machine Elements and Manufacturing,2004,47(3):908-915.
[3]	Ma P,Botman M.Load sharing in a planetary gear stage in the presence of gear errors and misalignment[J].Journal of Mechanicals,1985,107(1):4-10.
[4]	Kish J G.Sikorsky aircraft advanced rotorcraft transmission (ART) program-final report[R].NASA CR-191079,1993.
[5]	Timothy T L.A method to analyze and optimize the load sharing of split-path transmissions[R].NASA TM 107201,1996.
[6]	Ligata H,Kahraman A,Singh A.An experimental study of the influence of manufacturing errors on the plantary gear stresses and load sharing[J].Journal of Mechanical Design,2008,130(4):041701.1-041701.9.
[7]	Singh A,Kahraman A,Ligata H.Internal gear strains and load sharing in planetary transmissions:model and experiments[J].Journal of Mechanical Design,2008,130(7):072602.1-072602.10.
[8]	方宗德,沈允文,黄镇东.2K-H行星减速器的动态特性[J].西北工业大学学报,1990,8(4):361-371. FANG Zongde,SHEN Yunwen,HUANG Zhendong.Analysis of dynamic behaviour of 2K-H planetary gearing[J].Journal of Northwestern Polytechnical University,1990,8(4):361-371.(in Chinese)
[9]	张宏,张少名,马月英.多杆联动均载机构均载效果的理论分析[J].西安理工大学学报,1991,7(4):208-212. ZHANG Hong,ZHANG Shaoming,MA Yueying.The analysis of performance of load equilibrium for multi-link load banlancing mechanism[J].Journal of Xi'an University of Technology,1991,7(4):208-212.(in Chinese)
[10]	袁茹,王三民,沈允文.行星齿轮传动的功率分流动态均衡优化设计[J].航空动力学报,2000,15(4):410-418. YUAN Ru,WANG Sanmin,SHEN Yunwen.Dynamic optimum design of power shared out equally among the planetary gears[J].Journal of Aerospace Power,2000,15(4):410-418.(in Chinese)
[11]	陆俊华,朱如鹏,靳广虎.行星传动动态均载特性分析[J].机械工程学报,2009,45(5):85-90. LU Junhua,ZHU Rupeng,JIN Guanghu.Analysis of dynamic load sharing behavior in planetary gearing[J].Journal of Mechanical Engineering,2009,45(5):85-90.(in Chinese)
[12]	李斌.行星齿轮传动系统均载分析方法的研究[D].南京:南京航空航天大学,2005. LI Bin.Research on analytical method of load sharing characteristics of planetary gear transmission[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2005.(in Chinese)
[13]	FENG Shuguang,HE Jifeng,ZHANG Lichen.Modeling vehicle dynamics based on modelica[J].International Journal of Multimedia and Ubiquitous Engineering,2013,8(3):307-318.
[14]	蒋鸣.机械自动变速器(AMT)的多领域统一建模与仿真关键技术研究[D].武汉:华中科技大学,2011. JIANG Ming.Multi-domain modeling and simulation of automatic manual transmission(AMT)[D].Wuhan:Huazhong University of Science and Technology,2011.(in Chinese)
[15]	Maatar M,Velex P.An analytical expression for time-varying contact length in perfect cylindrical gears:some possible applications in gear dynamics[J].Journal of Mechanical Design,1996,118(12):586-589.
[16]	Parker R G,Lin J.Mesh phasing relationships in planetary and epicyclic gears[J].Journal of Mechanical Design,2004,126(3):365-370.
[17]	Kelly.机械振动[M].贾启芬,刘习军,译.北京:科学出版社,2002.
[18]	饶振纲.行星传动机构设计[M].北京:国防工业出版社,1994.
