不同温度下树脂基复合材料层合板力学性能试验

宋健; 温卫东

doi:10.13224/j.cnki.jasp.2016.04.030

不同温度下树脂基复合材料层合板力学性能试验

doi: 10.13224/j.cnki.jasp.2016.04.030

宋健^1,2,
温卫东^1,2

1. 南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室, 南京 210016;
2. 南京航空航天大学能源与动力学院机械结构力学及控制国家重点实验室, 南京 210016

基金项目:

江苏省研究生培养创新工程(KYLX_0237)

详细信息

作者简介:
宋健(1986-),男,吉林长春人,博士生,主要从事先进材料与结构设计技术方面的研究.

中图分类号: V258;TB332
计量
- 文章访问数: 1373
- HTML浏览量: 121
- PDF量: 554
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-13
- 刊出日期: 2016-04-28

Experiment on mechanical properties of resin matrix composites laminates under various temperatures

SONG Jian^1,2,
WEN Wei-dong^1,2

1. Jiangsu Province Key Laboratory of Aerospace Power System, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. State Key Laboratory of Mechanics and Control of Mechanical Structures, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 通过试验的方法研究了双马来酰亚胺树脂浇注体及碳纤维增强树脂基复合材料单向层合板在不同温度下的静态力学性能,并讨论了温度对材料力学行为的影响,最后对材料断口形貌进行了分析.试验结果表明:纯树脂浇注体拉伸、压缩性能受温度影响比较明显,且拉、压性能不同.对于拉伸性能,相对室温均值(20℃),160℃环境下模量均值及强度均值降幅分别为31.73%,44.71%,200℃时又分别下降了21.15%,20.37%;对于压缩性能,相对室温均值,160℃下模量及强度均值分别下降了26.67%,44.40%,而200℃时继续下降了6.66%,12.40%.层合板的纵向拉伸性能受温度影响较小,在200℃内,纵向模量与强度最大变幅分别为2.82%和2.53%,且材料断口从室温下的"毛刷"状变为了沿轴向劈断.材料的横向及面内剪切性能受温度影响较大,且应力-应变曲线存在明显非线性,但横向试件断口平整、面内剪切试件无明显紧缩现象,即均表现为脆性断裂特征.另外,相对室温均值,在160℃时,横向及面内切变模量分别下降约32.96%,41.25%,强度分别下降约15.83%,30.96%;在200℃时,横向及面内剪切性能继续下降,模量降幅为16.83%,22.52%,强度降幅12.24%,11.01%.
- 树脂基复合材料层合板 /
- 横向拉伸试验 /
- 面内剪切试验 /
- 高温性能 /
- 断口分析
Abstract: The mechanical properties of resin casting body and carbon fiber reinforced resin composite laminate were investigated under various temperatures experimentally. Influence of temperature on the stress-strain curve was discussed and then fracture surface analysis was also conducted. The experiment results showed that the tensile and compression properties of the resin casting body were obviously affected by temperature, and both of the properties were unequal. The average tensile modulus and strength fell by 31.73% and 44.71% compared with the value at room temperature (RT 20℃), and then dropped by 21.15% and 20.37%, respectively if continuing to heat up to 200℃. The average compressive modulus and strength at 160℃ decreased by 26.67% and 44.40% in comparison with those at RT, and the relative values continued to decline by 6.66% and 12.40%. For the composites, the longitudinal tensile property was hardly affected by temperature. The maximum amplitudes in the average stiffness and strength were only 2.82% and 2.53%. The longitudinal fractured surface morphology illustrated a "brushy" shape at RT, while a split configuration was observed at elevated temperature. The mechanical properties of transverse and in-plane shear were significantly affected by temperature and the stress-strain curve showed an obvious nonlinearity, however, a neat fractured surface subjecting to transverse loading and shear fractured surface had no significant necking appearance, which indicated brittle-natured fracture. The modulus of transverse and in-plane shear was reduced by 32.96%, 41.25% and the related strength declined by 15.83%, 30.96% at 160℃ compared with those at RT. When the temperature reached 200℃, the modulus continued to decline by 16.83%, 22.52%, and the corresponding strength dropped by 12.24% and 11.01%, respectively.
- unidirectional resin composite laminates /
- transverse tensile test /
- in-plane shear test /
- elevated temperature performance /
- fracture analysis

HTML

参考文献(22)

[1]	Kawai M,Yajima S,Hachinohe A,et al.Off-axis fatigue behavior of unidirectional carbon fiber-reinforced composites at room and high temperatures[J].Journal of Composite Materials,2001,35(7):545-576.
[2]	Ming H R,Yu C T,Huang K K H J.Fatigue response of APC-2 composite laminates at elevated temperatures[J]. Composites:Part B Engineering,2008,39(7/8):1142-1146.
[3]	Rupnowski P,Gentz M,Kumosa M.Mechanical response of a unidirectional graphite fiber/polyimide composite as a function of temperature[J].Composites Science and Technology,2006,66(7):1045-1055.
[4]	Ha S K,Springer G S.Nonlinear elastic properties of organic matrix composites at elevated temperatures[J].Journal of Engineering Materials and Technology,1988,110(2):124-127.
[5]	Ha S K,Springer G S.Nonlinear mechanical properties of a thermoset matrix composite at elevated temperatures[J].Journal of Composite Materials,1989,23(11):1130-1158.
[6]	Odegard G,Kumosa M.Determination of shear strength of unidirectional composite materials with the Iosipescu and 10° off-axis shear tests[J].Composites Science and Technology,2000,60(16):2917-2943.
[7]	Odegard G,Kumosa M.Elastic-plastic and failure properties of a unidirectional carbon/PMR-15 composite at room and elevated temperatures[J].Composites Science and Technology,2000,60(16):2979-2988.
[8]	Vieille B,Taleb L.About the influence of temperature and matrix ductility on the behavior of carbon woven-ply PPS or epoxy laminates:notched and unnotched laminates[J].Composites Science and Technology,2011,71(7):998-1007.
[9]	Selezneva M,Montesano J,Fawaz Z.Microscale experimental investigation of failure mechanisms in off-axis woven laminates at elevated temperatures[J].Composites:Part A Applied Science and Manufacturing,2011,42(11):1756-1763.
[10]	Montesano J,Fawaz Z,Poon C.A microscopic investigation of failure mechanisms in a triaxially braided polyimide composite at room and elevated temperatures[J].Materials & Design,2014,53(1):1026-1036.
[11]	冯青,李敏,顾轶卓,等.不同湿热条件下碳纤维/环氧复合材料湿热性能实验研究[J].复合材料学报,2010,27(6):16-20. FENG Qing,LI Min,GU Yizhuo,et al.Experimental research on hygrothermal properties of carbon fiber/epoxy resin composite under different hygrothermal conditions[J].Acta Materiae Compositae Sinica,2010,27(6):16-20.(in Chinese)
[12]	李晔,钟翔屿,崔郁,等.CF3052/5284RTM复合材料湿热性能[J].宇航材料工艺,2010(4):84-87. LI Ye,ZHONG Xiangyu,CUI Yu,et al.Hygrothermal properties of CF3052/5284RTM carbon fiber fabric composites[J].Aerospace Materials & Technology,2010(4):84-87.(in Chinese)
[13]	赵渠森.QY8911树脂系列及其工程应用[J].工程塑料应用,1995,23(1):1-8. ZHAO Qusen.QY8911 BMI series resin and its engineering application[J].Engineering Plastics Application,1995,23(1):1-8.(in Chinese)
[14]	赵渠森.先进复合材料手册[M].北京:机械工业出版社,2003.
[15]	赵渠森.双马来酰亚胺树脂和复合材料低成本[J].材料导报,2001,15(10):2-5. ZHAO Qusen.BMI resin system and affordable composite[J].Materials Review,2001,15(10):2-5.(in Chinese)
[16]	隋晓东,梁成利,刘文博,等.高温老化对碳纤维增强双马来酰亚胺树脂基复合材料力学性能的影响研究[J].纤维复合材料,2011,21(1):21-23. SUI Xiaodong,LIANG Chengli,LIU Wenbo,et al.Effect of thermal-aging on the mechanical properties of carbon fiber reinforced bis-malemide composite material[J].Fiber Composites,2011,21(1):21-23.(in Chinese)
[17]	张勇波,傅惠民,王治华.CCF300/QY8911单向纤维增强复合材料纵向压缩性能预测[J].航空动力学报,2013,28(6):1231-1235. ZHANG Yongbo,FU Huimin,WANG Zhihua.Compressive strength prediction of CCF300/QY8911 unidirectional fiber reinforced composites[J].Journal of Aerospace Power,2013,28(6):1231-1235.(in Chinese)
[18]	崔海坡,温卫东.T300/BMP316层合板冲击后压缩强度试验[J].航空动力学报,2008,23(11):2001-2006. CUI Haipo,WEN Weidong.Post-impact compressive strength experiment of T300/BMP316 composite laminates[J].Journal of Aerospace Power,2008,23(11):2001-2006.(in Chinese)
[19]	包建文,陈祥宝.发动机用耐高温聚酰亚胺树脂基复合材料的研究进展[J].航空材料学报,2012,32(6):1-13. BAO Jianwen,CHEN Xiangbao.Study on hygrothermal properties of 5284/T300 composites[J].Journal of Aeronautical Materials,2012,32(6):1-13.(in Chinese)
[20]	杨士勇,高生强,胡爱军,等.耐高温聚酰亚胺树脂及其复合材料的研究进展[J].宇航材料工艺,2000(1):1-6. YANG Shiyong,GAO Shengqiang,HU Aijun,et al.Progress in high temperature polyimide matrix resins and carbon fiber reinforced composites[J].Aerospace Materials & Technology,2000(1):1-6.(in Chinese)
[21]	国家质量技术监督局.GB/T 3354-1999定向纤维增强塑料拉伸性能试验方法[S].北京:中国标准出版社,1999. The State Bureau of Quality and Technical Supervision.GB/T 3354-1999 Test method for tensile properties of oriented fiber reinforced plastics[S].Beijing:Standards Press of China,1999.(in Chinese)
[22]	国家质量监督检验检疫总局.GB/T 2567-2008树脂浇注体性能试验方法[S].北京:中国标准出版社,2008. General Administration of Quality Supervision Inspection and Quarantine of the People's Republic of China.GB/T 2567-2008 Test methods for properties of resin casting boby[S].Beijing:Standards Press of China,2008.(in Chinese)
