温度对飞机燃油射流泵工作特性影响

邵垒; 刘卫华; 潘俊; 刘文怡; 冯诗愚

doi:10.13224/j.cnki.jasp.2016.09.004

温度对飞机燃油射流泵工作特性影响

doi: 10.13224/j.cnki.jasp.2016.09.004

1. 南京航空航天大学航空宇航学院, 南京 210016;
2. 中国航空工业集团公司金城南京机电液压工程研究中心航空机电系统综合航空科技重点实验室, 南京 211106

基金项目:

国家自然科学基金（50906066）；航空科学基金（20122852038，20132852040）；江苏高校优势学科建设工程资助项目

详细信息

作者简介:
邵垒(1989-),男,重庆奉节人,博士生,主要研究方向为飞行器燃油系统和人机环境工程.

通讯作者:
冯诗愚(1974-),男,浙江绍兴人,副教授,博士,主要研究方向为飞行器燃油系统和人机环境工程.E-mail:shiyuf@nuaa.edu.cn

中图分类号: V228
计量
- 文章访问数: 1194
- HTML浏览量: 148
- PDF量: 636
- 被引次数: 0
出版历程
- 收稿日期: 2014-12-11
- 刊出日期: 2016-09-28

Effect on working characteristic of fuel injection pump in aircrafts of temperature

1. College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. Aviation Key Laboratory of Science and Technology on Aero Electromechanical System Integration, Nanjing Engineering Institute of Aircraft Systems, Jincheng, Aviation Industry Corporation of China, Nanjing 211106, China

摘要

摘要: 建立了射流泵数学模型，采用数值计算方法对其工作特性进行了模拟，搭建了实验台，采用RP-3燃油，通过实验数据验证了模型的正确性.在此基础上，分别选择了RP-3和JET-A两种燃油，计算了从-40℃~40℃温度下，不同操作压力对射流泵流量比的影响.结果表明：燃油温度高于0℃时，温度对射流泵工作特性影响并不明显，随着温度的降低，射流泵性能与标准温度下（20℃）偏差越来越大，且压比越高此偏差越明显.当温度高于0℃时，采用RP-3和JET-A燃油性能相差不大，RP-3燃油性能略优于JET-A燃油，但是在低温下，RP-3燃油性能远高于JET-A燃油.因此当燃油温度较低且压比较高时，必须充分考虑温度对射流泵特性的影响.
- 射流泵 /
- RP-3燃油 /
- 流场计算 /
- JET-A燃油 /
- 工作特性
Abstract: A mathematical model of the injection pump was set up and its working characteristic was simulated using numerical computation method, the experiment apparatus was constructed and RP-3 fuel was adopted as the working fluid to verify the validity of this model. The flow ratio under various operating pressures was calculated from -40 degree to 40 degree by employing RP-3 fuel and JET-A fuel as working fluids, respectively. Result shows that if the fuel's temperature is above 0 degree, the effect of the fuel temperature on the working characteristic of injection pumps can be ignored. However, with the decrease of the temperature, the deviation of the performance with that at standard temperature(20 degree) increases definitely, especially the pressure ratio is high. When the temperature is above 0 degree, the performance of injection pump using RP-3 fuel is slightly better than that using JET-A fuel, but if the temperature is extremely low, the performance using RP-3 fuel is much better than that using JET-A fuel. It can be concluded that when the temperature is low and the pressure ratio is high, the effect caused by the temperature on the performance of injection pump should be considered carefully.
- injection pump /
- RP-3 fuel /
- flow field computation /
- JET-A fuel /
- working characteristic

HTML

参考文献(18)

[1]	Nanda R,Gupta S,Shukla A K N.Experimental setup for performance characterization of a jetpump with varying angles of placement and depth[J].Journal of Petroleum Exploration and Production Technolgy,2011,1(2):107-110.
[2]	Yamazaki Y,Nakayama T,Narabayashi T,et al.Effect of surface roughness on jet pump performance[J].The Japan Society of Mechanical Engineers International Journal,2009,49(4):928-932.
[3]	Kandulal J,Kumar M V.Experimental analysis on multi hole nozzle jet pump[J].International Journal of Modern Engineering Research (IJMER),2013,3(1):193-198.
[4]	Shah A,Chughtai I R,Inayat M H.Experimental and numerical investigation of the effect of mixing section length on direct-contact condensation in steam jet pump[J].International Journal of Heat and Mass Transfer,2014,72(2):430-439.
[5]	Shah A,Chughtai I R,Inayat M H.Experimental and numerical analysis of steam jet pump[J].International Journal of Multiphase Flow,2011,37(10):1305-1314.
[6]	ZHU Yinhai,JIANG Peixue.Experimental and analytical studies on the shock wave length in convergent and convergent-divergent nozzle ejectors[J].Energy Conversion and Management,2014,88:907-914.
[7]	Filin N V,Simkhovich S L,Sultanov I F.Mathematical modeling of a cryogenic jet pump with flows of different temperatures[J].Chemical and Petroleum Engineering,1990,26(1):18-22.
[8]	Beithou N,Aybar H S.A mathematical model for steam-driven jet pump[J].International Journal of Multiphase Flow,2000,26(10):1609-1619.
[9]	Gazzar M E,Meakhail T,Mikhail S.Numerical study of flow inside an annular jet pump[J].Journal of Thermophysics and Heat Transfer,2006,20(4):930-932.
[10]	Winoto S H,Li H,Shah D A.Efficiency of jet pumps[J].Journal of Hydraulic Engineering,2000,126(2):150-157.
[11]	Mallela R,Chatterjee D.Numerical investigation of the effect of geometry on the performance of a jet pump[J].Proceedings of the Institution of Mechanical Engineers:Part C Journal of Mechanical Engineering,2011,225(7):1614-1625.
[12]	Fan J,Eves J,Thompson H M,et al.Computational fluid dynamic analysis and design optimization of jet pumps[J].Computers and Fluids,2011,46(1):212-217.
[13]	Ji M K,Utomo T,Lee Y H,et al.CFD investigation on the flow structure inside thermo vapor compressor[J].Energy,2010,35(6):2694-2702.
[14]	龙新平,程茜,韩宁,等.射流泵最佳喉嘴距的数值模拟[J].核动力工程,2008,29(1):35-38. LONG Xinping,CHENG Qian,HAN Ning,et al.Numerical simulation of optimal nozzle-to-throat clearance of jet pump[J].Nuclear Power Engineering,2008,29(1):35-38.(in Chinese)
[15]	龙新平,朱劲木,梁爱国,等.射流泵喉管最优长度的数值计算[J].水利学报,2013(10):14-18. LONG Xinping,ZHU Jinmu,LIANG Aiguo,et al.Numerical calculation of optimal length of throat pipe in jet pump[J].Journal of Hydraulic Engineering,2013(10):14-18.(in Chinese)
[16]	周凌九,袁玲丽.射流泵液固两相流特性三维大涡模拟[J].排灌机械工程学报,2012,30(5):522-526. ZHOU Lingjiu,YUAN Lingli.Performance of liquid-solid two-phase flow in jet pump by LES[J].Journal of Drainage and Irrigation Machinery Engineering,2012,30(5):522-526.(in Chinese)
[17]	刘济瀛.中国喷气燃料[M].北京:中国石化出版社,1991.
[18]	Coordinating Research Council.Handbook of aviation fuel properties[R].Coordinating Research Council,CRC Report No.530,2004.
