俯仰姿态保持模式下飞机结冰边界保护方法

王小龙; 徐浩军; 薛源; 朱和铨; 裴彬彬

doi:10.13224/j.cnki.jasp.2016.09.006

俯仰姿态保持模式下飞机结冰边界保护方法

doi: 10.13224/j.cnki.jasp.2016.09.006

空军工程大学航空航天工程学院, 西安 710038

基金项目:

国家自然科学基金（61374145）；国家重点基础研究计划（2015CB755800）

详细信息

作者简介:
王小龙(1992-),男,山东聊城人,博士生,主要从事飞行力学、控制与飞行安全方向的研究.

中图分类号: V212
计量
- 文章访问数: 1378
- HTML浏览量: 230
- PDF量: 639
- 被引次数: 0
出版历程
- 收稿日期: 2015-01-02
- 刊出日期: 2016-09-28

Envelope protection method for pitch attitude holding mode under flight icing conditions

Aeronautics and Astronautics Engineering College, Air Force Engineering University, Xi'an 710038, China

摘要

摘要: 在研究飞机结冰机翼和平尾失速机理的基础上，以飞机迎角作为关键参数，飞机俯仰指令作为指令参数，提出一种基于飞机自驾仪的结冰后边界保护方法.通过引入铰链力矩检测模块，提前告警飞机失速，为边界保护提供了裕度.建立飞机纵向动力学方程，针对俯仰姿态保持（PAH）模式下机翼失速进行了仿真计算.结果表明：结冰条件下，通过铰链力矩的检测，飞机能在失速迎角为2°之前，进入边界保护模式，增加飞行安全的裕度.通过控制指令的限制，自动驾驶模式下飞机迎角能保持在失速迎角之内.
- 飞机结冰 /
- 边界保护 /
- 纵向自驾仪 /
- 失速迎角 /
- 平尾失速
Abstract: An envelope protection method with autopilot systems was proposed based on the research of wing stall and tailplane stall under icing conditions. The angle of attack was identified as a critical parameter, and the pitch angle was identified as a command parameter. The detection of hinge moment coefficient could early warn aircraft stall and increase the margin of envelope protection. The flight longitudinal dynamics equation in pitch attitude holding (PAH) mode was built. Results show that, the envelope protection system works at the 2 degrees before the stall angle of attack through the detection of hinge moment under icing conditions, increasing the flight safety margin. With the control command limitation, the angle of attack of the automatic flight under icing conditions could be limited to the stall angle of attack.
- flight icing /
- envelope protection /
- longitudinal autopilot /
- stall angle of attack /
- tailplane stall

HTML

参考文献(21)

[1]	Safety Advisor.Aircraft icing[EB/OL].[2013-05-01].http://www.aopa.org/-/media/Files/AOPA/Home/Pilot%20Resources/ASI/Safety%20Advisors/sall.pdf.
[2]	Falkena W,Borst C,Mulder J A.Investigation of practical flight envelope protection systems for small aircraft[R].AIAA-2010-7701,2010.
[3]	Bragg M B,Hutchison T,Merret J.Effect of ice accretion on aircraft flight dynamics[R].AIAA-2000-0360,2000.
[4]	Ratvasky T P.NASA FAA tailplane icing program overview[R].AIAA 99-0370,1999.
[5]	Ansell P J,Bragg M B,Kerho M F.Envelope protection system using flag hinge moment measurements[R].AIAA-2010-4225,2010.
[6]	Ansell P J,Kerho M F.Envelope protection for contaminant-induced adverse aerodynamics on a wing using flap hinge moment measurements[R].AIAA-2013-2654,2013.
[7]	Gurbacki H M,Bragg M B.Sensing aircraft icing effects by flap hinge moment measurements[R].AIAA 99-3149,1999.
[8]	Hossain K N,Sharma V,Bragg M B.Envelope protection and control adaption in icing encounters[R].AIAA-2003-0025,2003.
[9]	Sharma V,Voulgaris P G.Aircraft autopilot analysis and envelope protection for operation under icing conditions[J].Journal of Guidance,Control,and Dynamics,2004,27(3):454-465.
[10]	张智勇.结冰飞行动力学特性与包线保护控制律研究[D].南京:南京航空航天大学,2006. ZHANG Zhiyong.Research on iced aircraft flight dynamics characteristics and envelope protection control law[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2006.(in Chinese)
[11]	杜亮,洪冠新.结冰对飞机飞行包线影响分析及控制[J].飞行力学,2008,26(2):9-12. DU Liang,HONG Guanxin.Analysis and control of icing effects on aircraft flight envelope[J].Flight Dynamics,2008,26(2):9-12.(in Chinese)
[12]	应思斌,艾剑良.飞机结冰包线保护对开环飞行性能影响与仿真[J].系统仿真学报,2010,22(10):2273-2301. YING Sibin,AI Jianliang.Simulation of aircraft flight envelope protect in icing encounters effects on open loop dynamic[J].Journal of System Simulation,2010,22(10):2273-2301.(in Chinese)
[13]	周莉,徐浩军.飞机在结冰条件下的最优边界保护方法[J].上海交通大学学报,2013,47(8):1217-1221. ZHOU Li,XU Haojun.Optimal boundary protection method for aircraft under icing conditions[J].Journal of Shanghai Jiao Tong University,2013,47(8):1217-1221.(in Chinese)
[14]	苏媛,徐忠达,吴祯龙.飞机积冰后若干飞行力学问题综述[J].航空动力学报,2014,29(8):1878-1893. SU Yuan,XU Zhongda,WU Zhenlong.Overview of several ice accretion effects on aircraft flight dynamic[J].Journal of Aerospace Power,2014,29(8):1878-1893.(in Chinese)
[15]	Melody J W,Basar T.Parameter identification for inflight detection and characterization of aircraft icing[J].Control Engineering Practice,2000,8(9):985-1001.
[16]	Lampton A,Valasek J.Prediction of icing effects on the dynamic response of light airplanes[J].Journal of Guidance,Control,and Dynamics,2007,30(3):722-732.
[17]	Lampton A,Valasek J.Prediction of icing effects on the coupled response of light airplanes[J].Journal of Guidance,Control,and Dynamics,2008,31(3):656-673.
[18]	徐忠达,苏媛,曹义华.平尾积冰对飞机纵向气动参数的影响[J].航空学报,2013,34(7):1563-1571. XU Zhongda,SU Yuan,CAO Yihua.Effects of tailplane icing on aircraft longitudinal aerodynamic parameters[J].Acta Aeronaitica et Astronautica Sinica,2013,34(7):1563-1571.(in Chinese)
[19]	钟长生.结冰对平尾性能的影响及平尾失速分析[J].中国民航飞行学院学报,2004,15(6):6-9. ZHONG Changsheng.Effects of ice accretion on tailplane and analysis of tailplane stall[J].Journal of Civil Aviation Flight University of China,2004,15(6):6-9.(in Chinese)
[20]	Kim H S,Bragg M B.Effects of leading-edge ice accretion geometry on airfoil performance[R].AIAA 99-3150,1999.
[21]	Robert N C.Flightstability and automatic control[M].New York:McGraw Hill Higher Education,1997.
