旋流杯套筒混合段长度对点火特性的影响

康尧; 林宇震; 蒋尧; 王晓峰

doi:10.13224/j.cnki.jasp.2016.09.007

旋流杯套筒混合段长度对点火特性的影响

doi: 10.13224/j.cnki.jasp.2016.09.007

1. 中国航空工业集团公司中国航空动力机械研究所, 湖南株洲 412002;
2. 北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室, 北京 100191

详细信息

作者简介:
康尧(1987-),男,湖北鹤峰人,助理工程师,硕士,主要从事航空发动机燃烧方面研究.

中图分类号: V231.2
计量
- 文章访问数: 1656
- HTML浏览量: 178
- PDF量: 1629
- 被引次数: 0
出版历程
- 收稿日期: 2014-12-16
- 刊出日期: 2016-09-28

Effects of sleeve mixing length of swirl cup on the ignition characteristics

1. China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 412002;
2. National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 为研究旋流杯套筒过长的混合段长度对燃烧室点火特性的影响，设计了两种不同的套筒混合段长度试验件，在常温常压条件下，采用单头部模型燃烧室进行了起动点火性能试验，同时采用马尔文进行了燃油雾化颗粒度测量，并结合Fluent软件的数值模拟对结果进行分析.研究结果表明：套筒混合段长度对燃烧室头部流场和油雾分布有很大影响，过长的套筒混合段长度将造成液雾与套筒壁碰撞，限制旋转射流和液滴的径向运动，造成喷雾锥角减小了32%，贫油起动点火油气比增加了20%左右.
- 航空发动机 /
- 燃烧室 /
- 旋流杯 /
- 套筒混合段长度 /
- 点火性能
Abstract: A research was performed done to study the effect on the ignition performance by the too long mixing length of sleeve. Two variations of sleeve mixing length were made to test the ignition performance using a single module test combustor under normal temperature and atmospheric pressure. Melvin was used to test the spray particle size, and the software Fluent was used to analyze the experimental results. The research results show:the hardware geometry of sleeve mixing length has a great influence on the flow fields, and spray distributions of the dome. The spray drops will impact on the wall of sleeve when the mixing length of sleeve is long enough, and the radial movement of swirl jets and spray drops will be confined, leading to the decrease of spray cone angle by 32% and the increase of fuel air ratio(FAR) of lean ignition about 20%.
- aero-engine /
- combustor /
- swirl cup /
- sleeve mixing length /
- ignition performance

HTML

参考文献(25)

[1]	彭泽琰,刘刚.航空燃气轮机原理[M].北京:国防工业出版社,2000.
[2]	Peters J E,Mellor A M. An ignition model for quiescent fuel sprays[J].Combustion and Flame,1980,38(80):65-74.
[3]	Ballal D R,Lefebvre A H.A general model of spark ignition for gaseous and liquid fuel-air mixture[C]//18th Symposium (International) on Combustion.Waterloo:Combustion Institute,1981:1737-1746.
[4]	Lefebvre A H.Gas turbine combustion[M].Phiadelphia,PA,USA:Taylor & Francis Press,1999.
[5]	Mellor A M.Design of modern turbine combustors[M].London:Academic Press,1990.
[6]	Read R W.Experimental investigations into high-altitude relight of a gas turbine[D].Cambridge:University of Cambridge,2008.
[7]	Mosbach T,Sadanandan R,Meier W,et al.Experimental analysis of altitude relight under realistic conditions using laser and high-speed video techniques[R].ASME Paper 2010-GT-22625,2010.
[8]	Linassier G,Viguier C,Verdier H,et al.,Experimental investigations of the ignition performances on a multi-sector combustor under high altitude conditions[R].AIAA-2012-0934,2012.
[9]	Marchione T,Ahmed S F,Mastorakos E.Ignition of turbulent swirling n-heptane spray flames using single and multiple sparks[J].Combustion and Flame,2009,156(1):166-180.
[10]	Ahmed S F,Mastorakos E.Spark ignition of lifted turbulent jet flames[J].Combustion and Flame,2006,146(1/2):215-231.
[11]	Letty C,Mastorakos E,Masri A R,et al.Structure of igniting ethanol and n-heptane spray flames with and without swirl[J].Experimental Thermal and Fluid Science,2012,43:47-54.
[12]	Mastorakos E.Ignition of turbulent non-premixed flames[J].Progress in Energy and Combustion Science,2009,35(1):57-97.
[13]	程波,徐华胜,史家荣.某环形燃烧室地面起动点火试验研究[C]//中国航空学会第十四届燃烧与传热传质学术交流会论文集.沈阳:中国航空学会,2007:201-206.
[14]	史家荣.短环燃烧室点火和燃烧稳定性能研究[C]//中国航空学会青年科技论坛文集.银川:中国航空学会,2005:268-273.
[15]	薛鑫,林宇震,张弛,等.火焰筒压力损失对点火特性的影响[J].航空动力学报,2012,27(10):2229-2235. XUE Xin,LIN Yuzhen,ZHANG Chi,et al.Effects of liner pressure loss on combustor ignition performances[J].Journal of Aerospace Power,2012,27(10):2229-2235.(in Chinese)
[16]	张弛,王建臣,覃清钦,等.微型燃气轮机乙醇燃烧室点火与熄火试验[J].航空动力学报,2009, 24(9):1930-1936. ZHANG Chi,WANG Jianchen,QIN Qingqin,et al.Experimental research on ignition and lean blowout for micro gas turbine ethanol combustor[J].Journal of Aerospace Power,2009,24(9):1930-1936.(in Chinese)
[17]	方昌德.世界航空发动机手册[M].北京:航空工业出版,1996.
[18]	WANG Xiaofeng,LIN Yuzhen,HU Haosheng,et al.Effect of swirl cup's venturi shape on spray structure and ignition process[R].ASME Paper 2014-GT-25216,2014.
[19]	Kobayashi M,Ogata H,Oda T,et al.Improvement on ignition performance for a lean staged low NOx combustor[R].ASME Paper 2011-GT-46187,2011.
[20]	KANG Yao,LIN Yuzhen,SONG Shuangwen,et al. Effects of sleeve divergence angle of dual-stage swirl cup on the ignition performance[R].ASME Paper 2014-GT-25782,2014.
[21]	于锦峰,郭志辉,张君锋,等.套筒长度对火焰筒流场和雾化特性的影响[J].航空动力学报,2009,24(11):2506-2513. YU Jinfeng,GUO Zhihui,ZHANG Junfeng,et al.Experimental study the effect of flare sleeve length on the flowfield and spray characterization of a combustor swirl cup[J].Journal of Aerospace Power,2009,24(11):2506-2513.(in Chinese)
[22]	夏立峰,刁瑶朋,郭志辉.套筒结构参数对头部流场和喷雾场的影响[C]//中国航空学会第十四届燃烧与传热传质学术交流会论文集.沈阳:中国航空学会,2007:472-478.
[23]	康尧,林宇震,霍伟业,等.双级旋流杯结构变化对点火特性的影响研究[J].推进技术,2014,35(5):675-680. KANG Yao,LIN Yuzhen,HUO Weiye,et al.Effects of hardware geometry of dual-stage swirl cup on ignition performance[J].Journal of Propulsion Technology,2014,35(5):675-680.(in Chinese)
[24]	罗国良,宋双文,胡好生,等.旋流杯空气雾化喷嘴套筒出口形状对小型燃烧室点火性能的影响[J].航空动力学报,2011,26(8):1708-1712. LUO Guoliang,SONG Shuangwen,HU Haosheng,et al.Influences of the swirl cup flares design on the small combustor ignition performances[J].Journal of Aerospace Power,2011,26(8):1708-1712.(in Chinese)
[25]	林宇震,林培华,许全宏,等.复合式收扩套筒空气雾化喷嘴燃烧室点火研究[J].航空动力学报,2007,22(3):342-346. LIN Yuzhen,LIN Peihua,XU Quanhong,et al.Research on ignition performance of a hybrid airblast atomizer combustor with convergent-divergent[J].Journal of Aerospace Power,2007,22(3):342-346.(in Chinese)
