基于出口导流控制的超声速进气道性能研究

温玉芬; 严佳民; 陈皓; 马友林

doi:10.13224/j.cnki.jasp.2016.09.011

基于出口导流控制的超声速进气道性能研究

doi: 10.13224/j.cnki.jasp.2016.09.011

中国航天科技集团公司中国运载火箭技术研究院, 北京 100076

详细信息

作者简介:
温玉芬(1986-),女,广东高州人,工程师,硕士,主要从事内外流空气动力学研究.

中图分类号: V211.3
计量
- 文章访问数: 1730
- HTML浏览量: 105
- PDF量: 647
- 被引次数: 0
出版历程
- 收稿日期: 2014-12-20
- 刊出日期: 2016-09-28

Investigation on the performance of a supersonic inlet with diversing flow control on the exit

China Academy of Launch Vehicle Technology, China Aerospace Science and Technology Corporation, Beijing 100076, China

摘要

摘要: 针对进气道内型面存在较大弯段而导致的流动分离问题，提出了一种对进气道出口弯段进行导流控制的概念，设计了3种不同的导流格栅方案，采用数值仿真方法对不同导流格栅方案的超声速进气道流动进行了对比分析，获得了不同导流格栅对进气道流场结构和工作性能的影响特性.结果表明：利用格栅对进气道进行导流控制，可以改善进气道出口弯段的流场结构和压力分布，避免进气道出口发生流动分离.通过对格栅型面进行优化可以显著改善进气道的工作性能，采用类翼型导流格栅的进气道性能改善幅度最大，马赫数为3.5条件下，其稳定工作裕度和出口总压恢复系数分别提高10.3%和9.8%，冷流内阻降低5.3%.
- 超声速进气道 /
- 流动控制 /
- 导流格栅 /
- 总压恢复系数 /
- 稳定工作裕度
Abstract: Due to the flow separation induced by the severe curved shape of the inlet, a flow-control method based on the diversing flow grid was brought forward. Three different diversing flow grids were designed and a comparison of the supersonic inlet performance was conducted with a computational fluid dynamics method. Effects on the flow structure and working performance of the inlets with different diversing flow grids were attained. Results indicate that taking the grid as the flow control measure could avoid flow separation on the exit of the inlet by improving the flow structure and pressure distribution of the curved duct. It is proven that the performance of the inlet could be obviously improved by optimizing the diversing grid. Stability and total pressure recovery coefficient of the inlet with adoption of the airfoil shape grid could be raised by 10.3% and 9.8% at utmost while its interior resistance could be reduced by 5.3% at Mach number of 3.5.
- supersonic inlet /
- flow-control /
- diversing flow grid /
- total pressure recovery coefficient /
- stability

HTML

参考文献(18)

[1]	谢旅荣,郭荣伟.一种受总体限制的弹用S弯进气道的设计和试验验证[J].航空动力学报,2006,24(1):95-101. XIE Lürong,GUO Rongwei.Design and experimental study of an S-shaped inlet restricted by missile[J].Journal of Aerospace Power,2006,24(1):95-101.(in Chinese)
[2]	钟易成,陈晓,王伟.不同进气道状态对矩形大S弯扩压器流动特性的影响[J].推进技术,1996,17(6):43-48. ZHONG Yicheng,CHEN Xiao,WANG Wei.The influence of incoming flow conditions on flow characteristics in a large S-bend rectangular diffuser[J].Journal of Propulsion Technology,1996,17(6):43-48.(in Chinese)
[3]	翁小侪,郭荣伟.一种腹下S弯进气道低速大攻角下气动特性实验[J].航空动力学报,2008,23(9):1573-1578. WENG Xiaochai,GUO Rongwei.Investigation of pneumatic characteristics for a ventral S-shape inlet at high incidence and low speed[J].Journal of Aerospace Power,2008,23(9):1573-1578.(in Chinese)
[4]	郭荣伟,梁德旺,陈贻忠.进口导流叶片对S弯进气道出口旋流的抑制研[J].空气动力学报,1996,14(2):141-147. GUO Rongwei,LIANG Dewang,CHEN Yizhong.Investigation on swirl control in a diffusing S-shaped inlet with a horizontal guiding fence[J].Acta Aerodynamica Sinica,1996,14(2):141-147.(in Chinese)
[5]	梁德旺,郭荣伟,宁向荣,等.S弯扩压器内旋流的自动抑制[J].南京航空航天大学学报,1996,28(6):750-754. LIANG Dewang,GUO Rongwei,NING Xiangrong,et al.Auto-reduction of swirl in a S-shaped diffuser[J].Journal of Nanjing University of Aeronautics and Astronautics,1996,28(6):750-754.(in Chinese)
[6]	翁培奋.S弯进气道旋流的转动叶片模拟技术[J].空气动力学报,1997,15(4):519-523. WENG Peifen.Swirlin flow simulator in a S-shaped diffuser by a rotating blade[J].Acta Aerodynamica Sinica,1997,15(4):519-523.(in Chinese)
[7]	Reichert B A,Wendt B J.Improving diffusing S-duct performance by secondary flow control[R].AIAA 94-0365,1994.
[8]	Anderson B H,Keller D J.A robust design methodology for optimal microscale secondary flow control in compact inlet diffusers[R].NASA/TM-2001-211278,2002.
[9]	Anderson B H,Keller D J.Robust parameter design methodologies for optimal micro-scale secondary flow control in compact inlet diffusers[R].NASA/TM-2002-211477,2002.
[10]	Anderson B H,Keller D J.Optimal micro-scale secondary flow control for the management of high cycle fatigue and distortion compact inlet diffusers[R].NASA/TM-2002-211686,2002.
[11]	Anderson B H,Miller D N,Addeington G A,et al.Optimal micro-jet flow control for compact air vehicle inlets[R].NASA/TM-2004-212937,2004.
[12]	梁德旺,郭荣伟,赵明桂.格栅对进气道的气动性能和电磁散射特性的影响[J].航空学报,1998,19(5):567-569. LIANG Dewang,GUO Rongwei,ZHAO Minggui.Effect of honeycomb on aerodynamic performance and radar cross section of inlet[J].Acta Aeronautica et Astronautica Sinica,1998,19(5):567-569.(in Chinese)
[13]	Sullerey R K,Pradeep A M.Secondary flow control using vortex generator jets[J].Journal of Fluids Engineering,2004,126(4):650-657.
[14]	Pradeep A M,Sullerey R K.Secondary flow control in a circular S-duct diffuser using vortex generator jets[R].Portland,Oregon:2nd AIAA Flow Conference,2004.
[15]	翁培奋,郭荣伟.S弯进气道旋流缩涡实验研究[J].航空动力学报,1994,9(3):310-312. WENG Peifen,GUO Rongwei.Experimental investigation on swirl control in an S-shaped diffuser by vortex reduced device[J].Journal of Aerospace Power,1994,9(3):310-312.(in Chinese)
[16]	SUN Shu,GUO Rongwei.Serpentine inlet performance enhancement using vortex generator based flow control[J].Chinese Journal of Aeronautics,2006,19(1):10-17.
[17]	赵振山,董军,郭承鹏.基于数值涡流发生器双S型进气道被动流动控制装置参数优化[J].空气动力学报,2011,29(1):22-26. ZHAO Zhenshan,DONG Jun,GUO Chengpeng.Parameters optimization of passive flow control device for a dual S inlet by numerical vortex generator model[J].Acta Aerodynamica Sinica,2011,29(1):22-26.(in Chinese)
[18]	李斌斌,程克明,顾蕴松.斜出口合成射流激励器S进气道分离流动控制[J].实验流体力学,2012,26(2):34-37. LI Binbin,CHENG Keming,GU Yunsong.Separation flow control of beveled synthetic jet actuator in S-shaped inlet[J].Journal of Experiments in Fluid Mechanics,2012,26(2):34-37.(in Chinese)
