基于涡流发生器的风洞侧壁附面层控制

刘光远; 王瑞波; 邓吉龙; 陈宏涛

doi:10.13224/j.cnki.jasp.2016.09.012

基于涡流发生器的风洞侧壁附面层控制

doi: 10.13224/j.cnki.jasp.2016.09.012

中国空气动力研究与发展中心高速空气动力研究所, 四川绵阳 621000

详细信息

作者简介:
刘光远(1983-),男,山东曹县人,工程师,硕士,主要从事跨声速试验空气动力学研究.

中图分类号: V211.7
计量
- 文章访问数: 1388
- HTML浏览量: 206
- PDF量: 686
- 被引次数: 0
出版历程
- 收稿日期: 2015-02-05
- 刊出日期: 2016-09-28

Wind tunnel side wall boundary layer control based on vortex generator

High Speed Aerodynamics Institute, China Aerodynamics Research and Development Center, Mianyang Sichuan 621000, China

摘要

摘要: 为降低风洞侧壁附面层对半模型数据的影响，在前期数值模拟的基础上，研制了一种适用于2.4m跨声速风洞半模型试验段侧壁的梯形涡流发生器，并进行了试验验证.结果表明：加装涡流发生器效果明显，亚声速范围内能够使附面层厚度降低20%~30%，对主气流均匀性影响可忽略；加装后半模型零升阻力系数降低，升力线斜率增大，压力中心向机身移动，体现了明显的附面层减薄效果，证明所研制的涡流发生器可应用于亚声速半模型试验中.
- 风洞 /
- 涡流发生器 /
- 附面层厚度 /
- 半模型试验 /
- 流动控制
Abstract: Combined with former numerical simulating results, vortex generators applicable for 2.4m transonic wind tunnel half-model test section were designed and validated to reduce side wall boundary layer effect. Results show that 20%-30% boundary layer thickness is reduced using trapezia-shaped flat vortex generators in subsonic conditions, and the influence on flow field uniformity is neglectable. The decrease of zero-lift drag and increase of lift-slope are found after vortex generators installation, meanwhile pressure center moves toward fuselage. Both trends are distinct evidence of thinner boundary layers. The developed vortex generators can be applied to half-model tests for subsonic conditions.
- wind tunnel /
- vortex generator /
- boundary layer thickness /
- half-model test /
- flow control

HTML

参考文献(18)

[1]	Mack M D,McMasters J H.High Reynolds number testing in support of transport airplane development[R].AIAA 92-3982,1992.
[2]	Lynch F T.Experimental necessities for subsonic transport configuration development[R].AIAA 92-0158,1992.
[3]	Martin C N W,Bernd H.Half model testing at ETW[R].European Transonic Windtunnel Technical Memorandum,ETW/TM/2000028,2004.
[4]	Viehweger G,Ewald B.Half model testingin the cologne cryogenic tunnel[R].AIAA 94-2511,1994.
[5]	Gatlin G M,Parker P A,Owens L R,Jr.Advancement of semispan testing at the national transonic facility[J].Journal of Aircraft,2002,39(2):339-353.
[6]	赵硕虎.FL-2风洞半模型试验技术研究[J].气动研究与实验,1997,14(3):10-19. ZHAO Shuohu.Study of half model testing techniques in FL-2 wind tunnel[J].Aerodynamic Researchand Experiment,1997,14(3):10-19.(in Chinese)
[7]	Jurgen Q,Martin C N,Wright S R.Investigation of a modern transonic transport aircraft configuration over a large range of Reynolds numbers[J].AIAA-2002-0422,2002.
[8]	Gross N,Quest J.The ETW wall interference assessment for full and half models[J].AIAA-2004-0769,2004.
[9]	焦予秦,乔志德.有侧壁干扰的机翼半模型风洞实验的N-S方程数值模拟[J].航空学报,2001,22(2):140-143. JIAO Yuqin,QIAO Zhide.Navier-Stockes calculation of wind tunnel testing of semispan wing with side-wall interference[J].Acta Aeronautica et Astronautica Sinica,2001,22(2):140-143.(in Chinese)
[10]	William W E,Chokani N.Computational analysis of semi-span model test techniques[R].AIAA 95-2290,1995.
[11]	Peter E.Numerical validation of a half model high lift configuration in a wind tunnel[R].AIAA-2007-0262,2007.
[12]	Milholen W E.Design methodology for semispan model mounting geometries[R].AIAA 98-0758,1998.
[13]	Milholen W E,Chokani N,McGhee R J.Development of semispan model test techniques[J].Journal of Aircraft,1996,33(6):1115-1122.
[14]	Gatlin G M,Parker P A,Owens L R,Jr.Development of a semi-span test capability at the national transonic facility[R].AIAA-2001-0759.2001.
[15]	王建明,刘炜,祝魁,等.旋涡发生器对叶片根部马蹄涡的影响[J].航空动力学报,2012,27(7):1479-1483. WANG Jianming,LIU Wei,ZHU Kui,et al.Effects of vortex generator application on the wing-body juncture horseshoe vortex[J].Journal of Aerospace Power,2012,27(7):1479-1483.(in Chinese)
[15]	钟易成,陈晓.涡与涡以及涡与附面层之间相互作用的试验研究[J].航空动力学报,1999,14(1):27-30. ZHONG Yicheng,CHEN Xiao.An experimental investigation on interactions among vortices and vortex with boundary layer[J].Journal of AerospacePower,1999,14(1):27-30.(in Chinese)
[17]	倪雅琴.涡流发生器研制及其对边界层的影响研究[J].空气动力学学报,1995,13(1):110-116. NI Yaqin.Development of the vortex-generator and study on the effect of vortex-generator on boundary layer[J].Acta Aerodynamica Sinica,1995,13(1):110-116.(in Chinese)
[18]	LIU Guangyuan,WANG Ruibo,ZHANG Changrong,et al.Numerical investigation on boundary layer flow control with vortex generators[J].Applied Mechanics and Materials, 2013,432:351-357.
