电离对高超声速稀薄流飞行器气动热影响

屈程; 王江峰

doi:10.13224/j.cnki.jasp.2016.09.014

电离对高超声速稀薄流飞行器气动热影响

doi: 10.13224/j.cnki.jasp.2016.09.014

屈程,
王江峰

南京航空航天大学航空宇航学院, 南京 210016

基金项目:

江苏高校优势学科建设工程资助项目

详细信息

作者简介:
屈程(1988-),男,江苏泰兴人,博士生,主要从事高超声速稀薄流DSMC气动热研究.

中图分类号: V19;V211
计量
- 文章访问数: 1421
- HTML浏览量: 408
- PDF量: 558
- 被引次数: 0
出版历程
- 收稿日期: 2015-09-21
- 刊出日期: 2016-09-28

Ionization effects on aerodynamic heat for vehicle in hypersonic rarefied flow

College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 将电离反应模型扩展到（direct simulation Monte Carlo，DSMC）方法中，研究了电离反应效应对高超声速稀薄流飞行器气动热的影响特性.针对稀薄流场中电子出现带来的实际困难，引入“捆绑法”思想处理电子在流场中的运动，并给出了电离反应模型及电离反应处理方法.在以RAM-C Ⅱ飞行器外形为例对增加了电离反应的DSMC代码进行验证的基础上，以“星尘号”探测器外形为研究对象，针对不同飞行高度下5组元混合气体模型（无电离）和11组元混合气体模型（含电离）的化学非平衡流动开展了数值模拟，细致分析和对比了电离反应效应对探测器气动热的影响规律.研究结果表明：采用的电离反应处理方案能够模拟带电离反应的高超声速化学非平衡稀薄流动.在飞行高度为60km时电离反应对探测器气动热的影响最为强烈，使探测器的驻点热流密度降低了5.12%，电离反应对探测器气动热的影响随气体稀薄程度增加而减弱.
- 气动热 /
- DSMC方法 /
- 电离反应 /
- 高超声速 /
- 稀薄流
Abstract: Effect of ionization reaction on aerodynamic heat characteristics for vehicle in hypersonic rarefied flow was studied by using direct simulation Monte Carlo (DSMC) method in which ionization reaction model was added. For the actual difficulties added by electron in rarefied flow, a bundling method was used to deal with electron motion. The ionization reaction model and the processing method of ionization reaction were presented. Firstly, taking the example of shape of RAM-C Ⅱ vehicle, DSMC code with addition of ionization reaction was validated. Then, a numerical experiment was made to investigate the effects of ionization reaction on aerodynamic heat characteristics of the Stardust blunt body at different altitudes by use of 5 species gas model(without ionization) and 11 species gas model(with ionization) in chemical non-equilibrium flow. The results show that the treatment scheme proposed can simulate ionization reaction for hypersonic rarefied flow. At 60km altitude, ionization reaction effect on the aerodynamic heat characteristics becomes the strongest, reducing heat flux at stagnation point by 5.12%,and the effect decreases with the increase of the rarefied content of gas.
- aerodynamic heat /
- DSMC method /
- ionization reaction /
- hypersonic /
- rarefied flow

HTML

参考文献(18)

[1]	沈青.稀薄气体动力学[M].北京:国防工业出版社,2003.
[2]	Bird G A.Molecular gas dynamics and the direct simulation of gas flow[M].Oxford,UK:Clarendon Press,1994.
[3]	Bird G A.Nonequilibrium radiation during re-entry at 10 km/s[R].AIAA 87-1543,1987.
[4]	Boyd I D,Gokcen T.Computation of axisymmetric and ionized hypersonic flows using particle and continuum method[J].AIAA Journal,1994,32(9):1828-1835.
[5]	Boyd I D.Computation of hypersonic flows using the direct simulation Monte Carlo method[J].Journal of Spacecraft and Rockets,2015,52(1):38-53.
[6]	Hoult D,Starkey R P,Lewis M J.DSMC of power-law leading edge ionization for hypersonic telemetry applications[R].AIAA-2003-6964,2003.
[7]	陈伟芳,郑忠华,任兵,等.合并式电离-复合反应的DSMC模拟[J].空气动力学学报,1998,16(3):348-351. CHEN Weifang,ZHENG Zhonghua,REN Bing,et al.DSMC simulation of associative lonization recombination reactions[J].Acta Aerodynamica Sinica,1998,16(3):348-351.(in Chinese)
[8]	樊菁.稀薄气体动力学:进展与应用[J].力学进展,2013,43(2):185-201. FAN Jing.Rarefied gas dynamics:advances and applications[J].Advances in Mechanics,2013,43(2):185-201.(in Chinese)
[9]	王学德.高超声速稀薄气流非结构网格DSMC及并行算法研究[D].南京:南京航空航天大学,2006. WANG Xuede.DSMC method on unstructured grids for hypersonic rarefied gas flow and its parallelization[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2006.(in Chinese)
[10]	屈程,王江峰.DSMC算法气体壁面相互作用模型[J].南京航空航天大学学报,2015,47(3):348-354. QU Cheng,WANG Jiangfeng.Gas-surface interaction models for DSMC method[J].Journal of Nanjing University of Aeronautics and Astronautics,2015,47(3):348-354.(in Chinese)
[11]	QU Cheng,WANG Jiangfeng.Hybrid grid DSMC method for chemical nonequilibrium with rarefied flow heating[J].Transactions of Nanjing University of Aeronautics and Astronautics,2015,32(4):409-414.
[12]	Gallis M A,Torczynski J R,Rader D J,et al.Convergence behavior of a new DSMC algorithm[J].Journal of Computational Physics,2009,228(12):4532-4548.
[13]	Boyd I D.Modeling of associative ionization reactions in hypersonic rarefied flows[J].Physics of Fluids,2007,19(9):3-14.
[14]	Farbar E D,Boyd I D.Similation of reactions involving charged particles in hypersonic rarefied flows[R].AIAA-2009-267,2009.
[15]	Boyd I D.Modelling of the near field plume of a hall thruster[J].Journal of Applied Physics,2004,95(9):4575-4584.
[16]	Bird G A.Direct simulation of typical AOTV entry flows[J].AIAA 86-1310,1986.
[17]	吴其芬,陈伟芳.高温稀薄气体热化学非平衡流动的DSMC方法[M].长沙:国防科学技术大学出版社,1999.
[18]	石于中,陈伟芳,任兵,等.稀薄流热化学非平衡效应的DSMC研究[J].空气动力学学报,1997,15(2):239-244. SHI Yuzhong,CHEN Weifang,REN Bing,et al.DSMC study for the effects of thermochemical nonequilibrium in rarefied flow[J].Acta Aerodynamica Sinica,1997,15(2):239-244.(in Chinese)
