拉杆组合转子的刚度修正及动力学建模

卢明剑; 孙岩桦; 周健; 赵世全; 耿海鹏; 王为民

doi:10.13224/j.cnki.jasp.2016.09.020

拉杆组合转子的刚度修正及动力学建模

doi: 10.13224/j.cnki.jasp.2016.09.020

1. 西安交通大学机械工程学院机械结构强度与振动国家重点实验室, 西安 710049;
2. 中国东方电气集团有限公司东方汽轮机有限公司, 四川德阳 618000

基金项目:

国家重点基础研究发展计划（2013CB035705）；国家自然科学基金（51275386）

详细信息

作者简介:
卢明剑(1987-),男,江苏宿迁人,博士生,主要从事轴承-转子动力学研究.

中图分类号: V231.91;TH113.1
计量
- 文章访问数: 1107
- HTML浏览量: 77
- PDF量: 619
- 被引次数: 0
出版历程
- 收稿日期: 2014-12-16
- 刊出日期: 2016-09-28

Stiffness modification and dynamic modeling of a rod fastening rotor

1. State Key Laboratory of Strength and Vibration for Mechanical Structure, School of Mechanical Engineering, Xi'an Jiaotong University, Xi'an 710049, China;
2. Dongfang Turbine Company Limited, Dongfang Electric Corporation, Deyang Sichuan 618000, China

摘要

摘要: 为研究拉杆组合转子的动力学特性并比较其与整体式转子的差异，基于集总参数法，提出了一种拉杆组合转子动力学建模的方法.该方法通过对整体式转子梁模型抗弯刚度的修正，可以考虑接触、预紧力和拉杆等因素的影响.首先分别分析了这3个因素对等效梁静态抗弯刚度的影响，给出了相应的修正系数.研究结果表明：接触界面和拉杆对轴段抗弯刚度的影响很大，而轴向预紧力的影响较小.然后，针对一模化实验拉杆组合转子，计算了各轴段的修正系数并建立了动力学模型.其临界转速计算值和实验结果吻合，误差仅0.8%，表明了方法的正确性.研究可为其他组合式结构的动力学分析和设计提供参考和借鉴.
- 拉杆组合转子 /
- 动力学模型 /
- 预紧 /
- 抗弯刚度 /
- 临界转速
Abstract: In order to analyze the rotor dynamics of a rod fastening rotor and compare its differences with the integral rotor, a model based on lumped parameter method was proposed. By modification of the stiffness of the beam element, the effects of contacts between the disks, pre-stresses in the disks produced by the axial preload and the rods can be considered. Firstly, the effects of the three factors on the stiffness of the beam in static were analyzed, and the modified coefficients were obtained. The results show that, contacts and rods compared with the pre-stresses in the discs had relatively large effects on the dynamics of the rod fastening rotor. Then the modification coefficients for each beam element of an experimental rod fastening rotor were calculated and the dynamic model of the rotor was established. The critical speeds were calculated and agreed well with the experimental results. The error was just 0.8%, validating the method proposed. The results are very useful in dynamics analysis and design of other combined structures.
- rod fastening rotor /
- dynamic model /
- preload /
- bending stiffness /
- critical speed

HTML

参考文献(17)

[1]	GAO Jin,YUAN Qi,LI Pu,et al.Effects of bending moments and pre-tightening forces on the flexural stiffness of contact interfaces in rod-fastened rotors[C]//Proceedings of ASME Turbo Expo.Denmark:ASME,2012:511-519.
[2]	LIU Heng,CHEN Li,WANG Weimin,et al.Nonlinear dynamic analysis of a flexible rod fastening rotor bearing system[C]//Proceedings of ASME Turbo Expo. Glasgow,UK:ASME,2010:389-398.
[3]	Manfred J,John S.35-year old splined-disc rotor design large gas turbine[R].ASME Paper 96-GT-523,1996.
[4]	饶柱石.拉杆组合式特种转子力学特性及其接触刚度的研究[D].哈尔滨:哈尔滨工业大学,1992. RAO Zhushi.A study of dynamic characteristic and contact stiffness of the rod fastening composite special rotor[D].Harbin:Harbin Institute of Technology,1992.(in Chinese)
[5]	LU Mingjian,GENG Haipeng,XU Guohui,et al,Analysis and experimental study of dynamic characteristics of rod fastened rotor-bearing system under preload saturation[R].ASME Paper GT2013-95397,2013.
[6]	YUAN Qi,GAO Rui,FENG Zhengping,et al.Analysis of dynamic characteristics of gas turbine considering contact effects and pre-tightening force[C]//Proceedings of ASME Turbo Expo. Berlin,Germany:ASME,2008:938-988.
[7]	ZHANG Yanchun,DU Zhaogang.Determination of contact stiffness of rod-fastened rotors based on modal test and finite element analysis[J].Journal of Engineering for Gas Turbines and Power,2010,132(9):094501.1-094501.4.
[8]	HE Peng,LIU Zhansheng,WANG Guiwang,et al.Rotor dynamic analysis of tie-bolt fastened rotor based on elastic-plastic contact[C]//Proceedings of ASME Turbo Expo.British,Columbia,Canad:ASME,2011:365-373.
[9]	MENG Cheng,SU Ming,WANG Shaobo.An investigation on dynamic characteristics of a gas turbine rotor using an improved transfer matrix method[J].Journal of Engineering for Gas Turbines and Power,2013,135(2):122505.1-122505.12.
[10]	李辉光,刘恒,虞烈.考虑接触刚度的燃气轮机拉杆转子动力特性研究[J].振动与噪声,2012,31(7):4-8. LI Huiguang,LIU Heng,YU Lie.Dynamic characteristics of rod fastening rotor for gas turbine considering contact stiffness[J].Journal of Vibration and Shock,2012,31(7):4-8.(in Chinese)
[11]	李辉光,刘恒,虞烈.周向均布拉杆转子预紧力的确定[J].航空动力学报,2011,26(12):2791-2797. LI Huiguang,LIU Heng,YU Lie.Determination of preload force of circumferential distributed rod fastening rotor[J].Journal of Aerospace Power,2011,26(12):2791-2797.(in Chinese)
[12]	YUAN Shuxia,ZHANG Youyun,ZHU Yongsheng,et al.Study on the equivalent stiffness of the heavy-duty gas turbines composite rotor with curvic couplings and spline tie-bolts[C]//Proceedings of ASME 2011 Power Conference.Colorado,USA:ASME,2011:567-576.
[13]	Guillaume M,Thouraya N,Regis D,et al.Efficient model development for an assembled rotor of an induction motor using a condensed modal functional[J].Journal of Computational and Nonlinear Dynamics,2011,6(2):293-297.
[14]	钱征文,程礼,陈威,等.盘式拉杆转子双稳态振动特性[J].航空动力学报,2011,26(7):1563-1568. QIAN Zhengwen,CHENG Li,CHEN Wei,et al.Analysis on bistable response of a disk rod fastening rotor[J].Journal of Aerospace Power,2011,26(7):1563-1568.(in Chinese)
[15]	卢明剑,耿海鹏,徐国徽,等.预紧饱和下盘式周向拉杆转子-轴承系统动力学特性分析及实验研究[J].振动工程学报,2014,27(1):111-117. LU Mingjian,GENG Haipeng,XU Guohui,et al.Analysis and experiment study on dynamic characters of rod-fastening rotor-bearing system under saturated pretension[J].Journal of Vibration Engineering,2014,27(1):111-117.(in Chinese)
[16]	李浦,袁奇,高进,等.轮盘端面齿连接的周向拉杆转子刚度研究[J].航空动力学报,2013,28(7):1618-1623. LI Pu,YUAN Qi,GAO Jin,et al.Investigation on stiffness of circumferential distributed tie-rod rotor with curvic couplings of trochal disk[J].Journal of Aerospace Power,2013,28(7):1618-1623.(in Chinese)
[17]	John M.Rotordynamics of turbomachinery[M].New Jersey:John Wiley & Sons Inc.,1988.
