超磁致伸缩电静液作动器磁场分析与优化

杨旭磊; 朱玉川; 费尚书; 纪良; 郭亚子

doi:10.13224/j.cnki.jasp.2016.09.021

超磁致伸缩电静液作动器磁场分析与优化

doi: 10.13224/j.cnki.jasp.2016.09.021

南京航空航天大学机电学院, 南京 210016

基金项目:

国家自然科学基金（51175243）；江苏省自然科学基金（BK20131359）；航空科学基金（20130652011）

详细信息

作者简介:
杨旭磊(1989-),男,山东莱阳人,硕士生,主要从事智能材料电液控制技术方面的研究.

中图分类号: V231;TH137
计量
- 文章访问数: 1130
- HTML浏览量: 117
- PDF量: 554
- 被引次数: 0
出版历程
- 收稿日期: 2014-12-11
- 刊出日期: 2016-09-28

Magnetic field analysis and optimization of giant magnetostrictive electro-hydrostatic actuator

College of Mechanical and Electrical Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 提出一种超磁致伸缩电静液作动器（GMEHA）结构，采用永磁体与控制线圈组合提供驱动磁场.首先建立了该组合磁路数学模型，并给出了超磁致伸缩棒内磁感应强度计算解析式；其次，对以上结构进行了有限元分析（FEA），得出了磁路主要结构参数与磁场分布均匀性之间映射规律；最后进行了作动器磁场试验研究并与有限元分析结果进行了对比，验证了理论与有限元模型的可预测性，给出了该电静液作动器结构设计方法.结果表明：该电静液作动器的最佳驱动频率为250Hz，最大无负载体积流量为0.85L/min，最大阻断力达到了120N.
- 电静液作动器(EHA) /
- 超磁致伸缩棒 /
- 磁场 /
- 有限元方法 /
- 均匀度
Abstract: A structure of giant magnetostrictive electro-hydrostatic actuator (GMEHA) was designed. The control coil was combined with permanent magnet to provide driving magnetic field. Mathematical model of the magnetic circuit was established, and the analytical calculation of magnetic flux density inside giant magnetostrictive rod was performed. Secondly, finite element analysis (FEA) for the above structurewas conducted, and the mapping principle between the main parameters of the structure and the magnetic field uniformity was got. Finally,the study of actuator magnetic field experiment was conducted, the result of the study was compared with the result of FEA, verifying the predictability of theory and finite element model, then the structure design method of this electro-hydrostatic actuator was presented. Results show that the maximum no-load output volume flow is 0.85 L/min around 250 Hz of the best driving frequency, while the maximum blocked force was close to 120N.
- electro-hydrostatic actuator (EHA) /
- giant magnetostrictive rod /
- magnetic field /
- finite element method /
- uniformity

HTML

参考文献(18)

[1]	Chaudhuri A,Wereley N.Compact hybrid electrohydraulic actuators using smart materials:a review[J].Journal of Intelligent Material Systems and Structures,2012,23(6):597-634.
[2]	Chauhuri A,Yoo J,Wereley N M.Dynamic modeling of a magnetostrictive hydraulic pump[C]//Proceedings of 2006 ASME International Mechanical Engineering Congress And Exposition.Chicago:ASME,2006:331-338.
[3]	Lhermet N,Claeyssen F,Fabbro H.Electro-fluidic components based on smart materials for aircraft electrohydraulic actuators[C]//Proceedings of the 9th International Conference on New Actuators.Bremen,Germany:[s.n.],2004:718-721.
[4]	Alfayad S,Ouezdou F,Gheng G.High performance integrated electro-hydraulic actuator for robotics:Part Ⅰ principle,prototype design first experiments[J].Sensors and Actuators A:Physical,2011,169(1):115-123.
[5]	Larson J.Design of amagnetostrictive-hydraulic actuator considering nonlinear system dynamics and fluid-structure coupling[D].Ohio:The Ohio State University,2014.
[6]	Janker P,Claeyssen F,Grohmann B,et al.New actuators for aircraft and space applications[C]//Proceedings of the 11th International Conference on New Actuator.Bremen,Germany:[s.n.],2008:346-354.
[7]	陈龙,朱玉川,杨旭磊,等.超磁致伸缩泵驱动磁路建模及数值分析[J].中国机械工程,2014,25(6):718-722. CHEN Long,ZHU Yuchuan,YANG Xulei,et al.Drivingmagnetic path modeling and numerical analysis in giant magnetostrictive pump[J].China Mechanical Engineering,2014,25(6):718-722.(in Chinese)
[8]	王传礼.基于GMM转换器喷嘴挡板阀伺服阀的研究[D].杭州:浙江大学,2005. WANG Chuanli.Research on the nozzle flapper servo valve driven by GMM actuator[D].Hangzhou:Zhejiang University,2005.(in Chinese)
[9]	贾振元,郭东明.超磁致伸缩材料微位移执行器原理与应用[M].北京:科学出版社,2008.
[10]	Tan H,Hurst W,Leo D.Performance modeling of a piezohydraulic actuation system with active valves[J].Smart Materials and Structures,2005,14(1):91-110.
[11]	Larson J P,Dapino M J.High frequency valve development for smart material electro-hydraulic actuators[C]//Proceedings of Conference on Industrial and Commercial Applications of Smart Structures Technologies.[S.l.]:Society of Photo-optical Instrumentation Engineers,2011:843-845.
[12]	Chaudhuri A.Self-contained hybrid electro-hydraulic actuators using magnetostrictive and electrostrictive material[D].Baltimore,Maryland:University of Maryland,2008.
[13]	XUAN Zhefeng,JIN Tailie,Sanha N,et al.Performance of piezo-stacks for a piezoelectric hybrid actuator by experiments[J].Journal of Intelligent Material Systems and Structures,2014,25(18):2212-2220.
[14]	李跃松.超磁致伸缩射流伺服阀的理论与实验研究[D].南京:南京航空航天大学,2014. LI Yuesong.Theoretical and experimental research on jet servovalve driven by giant magnetostrictive actuator[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2014.(in Chinese)
[15]	程清风,朱玉川,王晓露,等.超磁致伸缩伺服阀电-机转换器磁场分析与优化[J].机械科学与技术,2012,31(7):1066-1070. CHENG Qingfeng,ZHU Yuchuan,WANG Xiaolu,et al.Optimizing magnetic field ofgiant magnetostrictive microdisplacement for jet servo valve[J].Mechanical Science and Technology,2012,31(7):1066-1070.(in Chinese)
[16]	李跃松,朱玉川,吴洪涛,等.射流伺服阀用超磁致伸缩执行器磁场建模与分析[J].兵工学报,2010,31(12):1587-1592. LI Yuesong,ZHU Yuchuan,WU Hongtao et al.The magnetic field molding and analysis of giant magnetos-trictive actor for jet servo valve[J].Acta Armamentarii,2010,31(2):1587-1592.(in Chinese)
[17]	Kendall D,Piercy A.The frequency dependence of eddy current losses in terfenold[J].Journal of Applied Physics,1993,73(10):6174-6176.
[18]	Nan X,Sullivan C R.Simplified high-accuracy calculation of eddy-current loss in round-wire windings[C]//Proceedings of Power Electronics Specialists Conference.Aachen,Germany:IEEE,2004:873-879.
