基于无序点云的叶片截面特征参数提取

刘书桂; 毛晨丽; 张海涛

doi:10.13224/j.cnki.jasp.2016.09.023

基于无序点云的叶片截面特征参数提取

doi: 10.13224/j.cnki.jasp.2016.09.023

天津大学精密测试技术与仪器国家重点实验室, 天津 300072

基金项目:

中航创新基金（2009B41030）；天津市应用基础与前沿技术研究计划（13JCZDJC34500）

详细信息

作者简介:
刘书桂(1954-),男,湖南华容人,教授、博士生导师,博士,主要从事智能坐标测量技术、自动测量与控制技术研究.

中图分类号: V232.4;TP391.7
计量
- 文章访问数: 1181
- HTML浏览量: 119
- PDF量: 541
- 被引次数: 0
出版历程
- 收稿日期: 2015-01-19
- 刊出日期: 2016-09-28

Cross-sectional feature parameters extraction of blade based onunorganized point cloud

State Key Laboratory of Precision Measuring Technology and Instruments, Tianjin University, Tianjin 300072, China

摘要

摘要: 针对提取航空发动机叶片截面特征参数的实用性要求，研究了基于无序点云数据的叶片截面特征参数提取方法.综合距离法和二分法的优点，采用基于矩形腐蚀法的距离-二分法对点云数据排序，基于最小包容区域直线和最小二乘圆拟合，提出了将整条叶片截面点云数据分割成前缘、后缘、叶盆和叶背4部分的自动分区方法，对特征参数提取方法做了研究并用VC++进行算法实现，使用UG/OpenGrip生成UG中叶片截面上的点云数据进行实验运算，计算精度达到10^-4mm，表明在实际测量和参数提取中算法误差可以忽略.
- 叶片截面 /
- 特征参数 /
- 无序点云 /
- 数据排序 /
- 数据分区
Abstract: According to the practical requirements for extracting the cross-sectional feature parameters of aircraft engine blade, algorithms based on unorganized point cloud were studied. For the point cloud sorting, the distance-dichotomy based on rectangular corrosion was presented in consideration of the advantages of distance method and dichotomy. The approach based on minimum contain regional linear fitting and least square circle approximation was proposed for partitioning automatically the cross-sectional data of blade into four parts of leading edge, trailing edge, pressure face and suction face.The algorithms of feature parameters extraction were studied as well, and realized with VC++ and simulated using the unorganized point data generated by UG/OpenGrip. The experiments show that the precision of the calculation can reach 10^-4 mm, indicating that algorithm calculation error can be ignored in the practical measurement and parameter extraction.
- cross-section of blade /
- feature parameters /
- unorganized point cloud /
- data sorting /
- data partitioning

HTML

参考文献(18)

[1]	郭真望,张力宁.一种复杂截面线数据的排序与轮廓分离方法[J].今日科苑,2007(8):94. GUO Zhenwang,ZHANG Lining.A kind of complex cross section line data sorting and contour separation method[J].Modern Science,2007(8):94.(in Chinese)
[2]	谭晓丹.整体叶盘测量特征点提取与数据处理研[D].长春:吉林大学,2014. TAN Xiaodan.Research on sampling distribution and data processing for blisk measurement[D].Changchun:Jilin University,2014.(in Chinese)
[3]	彭志光,李文龙.基于改进凸包算法的叶片型面特征参数提取[J]. 装备制造技术,2012(1):37-43,46. PENG Zhiguang,LI Wenlong.The blade surface feature parameter extraction based on the improved convex hull algorithm[J].Equipment Manufactring Technology,2012(1):37-43,46.(in Chinese)
[4]	张新宝,张坤.平面内直线度误差最小区域法的完备性研究[J]. 机械工程学报,2012,48(24):14-18. ZHANG Xinbao,ZHANG Kun.Research on the completeness of minimum zone method of straightness error in plane[J].Journal of Mechanical Engineering,2012,48(24):14-18.(in Chinese)
[5]	ZHU Lingjian,LI Lin,LIU Junhua.A method for measuring the guideway straightness error based on polarized interference principle[J].International Journal of Machine Tools and Manufacture,2009,49(3/4):285-290.
[6]	YI Ziqiang,LI Shengyi.High accuracy error separation technique for on-machine measuring straightness[J].Precision Engineering,2006,30(2):192-200.
[7]	彭志光.基于改进凸包算法的叶片型面检测[D].武汉:华中科技大学,2012. PENG Zhiguang.The blade surface inspection based on the improved convex hull algorithm[D].Wuhan:Huazhong University of Science and Technology,2012.(in Chinese)
[8]	陈志强.基于测量数据的叶片截面特征参数提取技术研究[D].西安:西北工业大学,2007. CHEN Zhiqiang.Research of cross-sectional feature parameter extraction of blade based on measurement data[D].Xi'an:Northwestern Polytechnieal University,2007.(in Chinese)
[9]	陈志强,张定华,金炎芳,等.基于测量数据的叶片截面特征参数提取[J]. 科学技术与工程,2007,7(9):1972-1975. CHEN Zhiqiang,ZHANG Dinghua,JIN Yanfang,et al.Cross-sectional feature parameter extraction of blade based on measurement data[J].Science Technology and Engineering,2007,7(9):1972-1975.(in Chinese)
[10]	Gander W, Golub G H,Strebel R.Least-squares fitting of circles and ellipses[J].BIT Numerical Mathematics,1994,34(4):558-578.
[11]	Fitzgibbon A,Pilu M,Fisher R B.Direct least square fitting of ellipses[J].Pattern Analysis and Machine Intelligence,1999,21(5):476-480.
[12]	Tiller P A.The NURBS book[M].2nd ed.New York:Springer Verlag,1997.
[13]	JIANG Dan,WANG Lancheng. An algorithm of NURBS surface fitting for reverse engineering[J].The International Journal of Advanced Manufacturing Technology,2006,31(1):92-97.
[14]	贾春阳,杨岳,陈峰. 等弧长原则的NURBS曲线离散算法[J]. 计算机工程与应用,2014,50(3):165-167,189. JIA Chunyang,YANG Yue,CHEN Feng.NURBS curve discrete algorithm based on equal arc-length principle[J]. Computer Engineering and Applications,2014,50(3):165-167,189.(in Chinese)
[15]	Tiller P.Biarc approximation of NURBS curves[J].Computer Aided Design,2002,34(11):807-814.
[16]	邓达.曲线的(广义)圆弧样条逼近[D].长沙:中南大学,2007. DENG Da.The approximation of curves by generalized arc spline[D].Changsha:Central South University,2007.(in Chinese)
[17]	何援军.计算机图形学[M].北京:机械工业出版2006.
[18]	孙钢峰.叶片中弧线和最大叶型厚度的计算[J].汽轮机技术,1988(2):36-47,14. SUN Gangfeng.The calculation of mean camber line and maxthickness of blade[J].Turbine Technology,1988(2):36-47,14.(in Chinese)
