整体涡对跨声速单转子性能和稳定性影响

屠宝锋; 胡骏; 张凯

doi:10.13224/j.cnki.jasp.2016.09.024

整体涡对跨声速单转子性能和稳定性影响

doi: 10.13224/j.cnki.jasp.2016.09.024

屠宝锋^1,2,
胡骏^1,2,
张凯¹

1. 南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室, 南京 210016;
2. 先进航空发动机协同创新中心, 北京 100191

基金项目:

航空基金（2015ZB52018）；中央高校基本科研业务费专项资金（NS2014021）

详细信息

作者简介:
屠宝锋(1981-),男,浙江嵊州人,讲师,博士,主要从事叶轮机械气动稳定性及非定常流研究.

中图分类号: V231
计量
- 文章访问数: 1136
- HTML浏览量: 208
- PDF量: 521
- 被引次数: 0
出版历程
- 收稿日期: 2014-12-04
- 刊出日期: 2016-09-28

Effect of bulk swirl on performance and stability of transonic single rotor

1. Jiangsu Province Key Laboratory of Aerospace Power System, College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. Collaborative Innovation Center for Advanced Aero-Engine, Beijing 100191, China

摘要

摘要: 为研究整体涡影响轴流压气机性能和稳定性的机理，设计了一种叶片式旋流发生器，并对旋流发生器和跨声速单转子进行了联合数值模拟研究.计算结果表明：反向整体涡导致堵塞点流量、进口攻角和总压比增加，效率和稳定工作范围降低；同向整体涡导致堵塞点流量、进口攻角、总压比和稳定工作范围减小，效率增加；反向整体涡导致50%叶高以上吸力面附面层分离以及叶尖泄漏流堵塞加剧是压气机失稳的主要原因.
- 压气机 /
- 跨声速 /
- 整体涡 /
- 旋转发生器 /
- 稳定性
Abstract: In order to investigate the effect of bulk swirl on performance and stability of axial compressor, blade swirl generator was designed and numerically simulated with a transonic single rotor. The results showed that counter-rotating bulk swirl caused significant drop in coefficient and stall margin and increase in choke mass flow, angle of attack and total pressure ratio. Co-rotating bulk swirl led to decrease of choke mass flow, attack angle, total pressure ratio and stable operating range, and increase of coefficient. Co-rotating bulk swirl caused suction surface boundary layer separation beyond 50% blade span, and more serious tip leakage blocking, contributing a lot to unstable compressor.
- compressor /
- transonic /
- bulk swirl /
- swirl generator /
- stability

HTML

参考文献(18)

[1]	Schmid N R,Leinhos D C,Fottner L.Steady performance measurements of a turbofan engine with inlet distortions containing co-and counter-rotating swirl from an intake diffuser for hypersonic flight[R].ASME Paper,2000-GT-0011,2000.
[2]	Fottner L,Genssler H P,Meyer W.Development of intake swirl generators for turbo jet engine testing[R].Advisory Group for Aerospace Research and Development,AGARD-CP-400,1987.
[3]	张晓飞,姜健,符小刚.S弯进气道旋流畸变数值模拟及特性分析[J].燃气涡轮试验与研究,2012,25(3):21-26. ZHANG Xiaofei,JIANG Jian,FU Xiaogang.Numerical simulation and characteristic analysis of swirl distortion in S-duct inlet[J].Gas Turbine Experiment and Research.2012,25(3):21-26.(in Chinese)
[4]	Rabe A C.Effectiveness of serpentine inlet duct flow control scheme at design and off-design simulated flight conditions[D].Blacksburg:Virginia Polytechnic Institute and State University,2003.
[5]	XIE Wengzhong,GUO Rongwei.A ventral diverterless high offset S-shaped inlet at transonic speeds[J].Chinese Journal of Aeronautics,2008,21(3):207-214.
[6]	Sullivan J P,Murthy S N B,Davis R,et al.S-shaped duct flows[R].Office of Naval Research Contract,N-78-C-0710,1982.
[7]	Cousins W T.History philosophy physics and future directions of aircraft propulsion system/inlet integration[R].ASME Paper,2004-GT-54210,2004.
[8]	Sheoran Y,Bouldin B.A versatile design of a controlled swirl distortion generator for testing gas turbine engines[R].ASME Paper,GT2008-50657,2008.
[9]	Sheoran Y,Bouldin B,Krishnan P M.Advancements in the design of an adaptable swirl distortion generator for testing gas turbine engines[R].ASME Paper,GT2009-59146,2009.
[10]	Sheoran Y,Bouldin B,Krishnan P M.Compressor performance and operability in swirl distortion[J].Journal of Turbomachinery,2012,134(4):2453-2464.
[11]	Castaneda J,Mehdi A,Cugno D,et al.A preliminary numerical CFD analysis of transonic compressor rotors when subjected to inlet swirl distortion[R].ASME Paper,GT2011-46560,2011.
[12]	彭成一,林峰,张堃元.旋流模拟器研究[J].航空动力学报,1986,1(2):22-26. PENG Chengyi,LIN Feng,ZHANG Kunyuan.Design of swirl simulators[J].Journal of Aerospace Power,1986,1(2):22-26.(in Chinese)
[13]	彭成一,马家驹,尹军飞.新机试飞中的进气道旋流测量[J].推进技术,1994,15(4):8-13. PENG Chengyi,MA Jiaju,YIN Junfei.Measurement of inlet swirl in flight[J].Journal of Propulsion Technology,1994,15(4):8-13.(in Chinese)
[14]	姜健,屈霁云,史建邦.进气道旋流发生器的设计与数值模拟[J].燃气涡轮试验与研究,2008,21(1):43-46. JIANG Jian,QU Jiyun,SHI Jianbang.Design and numerical calculation of vane type swirl generator[J]. Gas Turbine Experiment and Research,2008,21(1):43-46.(in Chinese)
[15]	邓小宝,姜健,屈霁云,等.进气道旋流模拟及测量的风动试验研究[J].燃气涡轮试验与研究,2009,22(4):51-56. DENG Xiaobao,JIANG Jian,QU Jiyun.Research on simulation and measurement of inlet swirl by wind tunnel test[J].Gas Turbine Experiment and Research,2009,22(4):51-56.(in Chinese)
[16]	叶飞,张堃元,姜健,等.进气道旋流模拟及测量的实验研究[J].推进技术,2009,30(3):297-301. YE Fei,ZHANG Kunyuan,JIANG jian,et al.Experimental investigation on simulation and measurement for intake swirl[J].Journal of Propulsion Technology,2009,30(3):297-301.(in Chinese)
[17]	李大伟,马东立.背负式S形进气道流场控制技术[J].北京航空航天大学学报,2008,34(12):1456-1459. LI Dawei,MA Dongli.Improving dorsal S shaped inlet performance by vortex flow control[J].Journal of Beijing University of Aeronautics and Astronautics,2008,34(12):1456-1459.(in Chinese)
[18]	刘雷,陈焕龙,宋彦平,等.半埋入式S弯进气道主动流动控制研究[J].推进技术,2014,35(9):1167-1172. LIU Lei,CHEN Huanlong,SONG Yanping,et al.Numerical simulation of effects of active flow control on the performance of a half flush-mounted S-shaped inlet[J].Journal of Propulsion Technology,2014,35(9):1167-1172.(in Chinese)
