跨声速风扇转子间隙流动结构分析

杨晰琼; 刘波; 曹志远; 茅晓晨; 夏树丹

doi:10.13224/j.cnki.jasp.2016.09.027

跨声速风扇转子间隙流动结构分析

doi: 10.13224/j.cnki.jasp.2016.09.027

西北工业大学动力与能源学院, 西安 710072

基金项目:

国家自然科学基金（51236006）；先进发动机协同创新中心资助

详细信息

作者简介:
杨晰琼(1990-),女,河南南阳人,硕士生,主要从事叶轮机械气动设计及试验研究.

中图分类号: V231.3
计量
- 文章访问数: 1079
- HTML浏览量: 74
- PDF量: 486
- 被引次数: 0
出版历程
- 收稿日期: 2015-01-08
- 刊出日期: 2016-09-28

Analysis on tip flow structure in transonic fan rotor

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 为探索跨声速转子间隙流动结构，归纳间隙泄漏涡（TLV）和激波相互作用机理，以跨声速转子为研究对象，数值模拟不同间隙下流动特性.此外，着重探究TLV与激波的相互作用，斜激波受到间隙泄漏流的干扰，被削弱打断向上游凹曲；建立三维模型，加深对跨声速叶尖区域流动的全面认识.研究表明：随间隙增大，相同流量下，效率越小，压比也越小；TLV强度更大，偏离吸力面程度增大，沿周向和展向影响范围都越大.压力差提供泄漏流迁移动力，间隙提供泄漏流形成通道.选取h/c=1.0%间隙，随着间隙高度的增大，泄漏流周向运动趋势更明显且二次泄漏现象更剧烈；沿泄漏流方向无量纲流向涡量有少量减少，无量纲螺旋度较高，集中涡特性明显.
- 跨声速 /
- 间隙泄漏涡 /
- 流动结构 /
- 激波 /
- 相互作用
Abstract: In order to analyze the tip flow structure and explore the intersection of shock and tip clearance vortex, a transonic fan rotor was studied using three dimensional numerical calculation and comparative analysis of flow field with various clearances. Further study of the intersection of tip leakage vortex and shock were obtained by establishing the 3-D flow model of the process, thus enhancing the comprehensive understanding of tip leakage flow. The research indicated that the performance was improved with the decrease of the clearance, including efficiency and pressure ratio. Moreover, with the increase of tip gap, the intensity of tip leakage vortex(TLV)was enhanced and the scope of high-entropy area was expanded along the circumferential direction and spanwise direction. The pressure difference between pressure surface and suction surface provided the impetus for the migration of the leakage flow, and lateral gap offered the migration channel. Under h/c=1.0%, the circumferential movement tended to be more notable and the secondary leakage turned more dramatic with the increase of tip height. Propagating of TLV led to the rapid reduction of the normalized streamwise vorticity, while the constant value of the normalized helicity showed that the concentrated vortex feature was maintained. What's more, the shock was distorted by the tip leakage vortex near suction, weakening the shock wave and pushing the shock upward.
- transonic /
- tip leakage vortex (TLV) /
- flow structure /
- shock /
- intersection

HTML

参考文献(19)

[1]	Camp T R,Day I J.A study of spike and modal stall phenomena in a low speed axial compressor[J].Journal of Turbomachinery,1998,120(3):393-401.
[2]	Wheeler A P S,Korakianitis T,Banneheke S.Tip-leakage losses in subsonic and transonic blade rows[J].Journal of Turbomachinery,2013,135(1):751-759.
[3]	ZHANG Zhibo,YU Xianjun,LIU Baojie.Characteristics of the tip leakage vortex in a low-speed axial compressor with different rotor tip gaps[R].ASME Paper GT-2012-69148,2012.
[4]	DU Juan,LIN Feng,CHEN Jingyi,et al.Flow structures in the tip region for a transonic compressor rotor[J].Journal of Turbomachinery,2013,135(3):2561-2572.
[5]	Ahti J,Teemu T S,Aki G,et al.Experimental study of the effect of the tip clearance of the diffuser flow and stage performance of a centrifugal compressor[R].ASME Paper GT-2012-68445,2012.
[6]	ZHANG Desheng,SHI Weidong,WU Suqing.Numerical and experimental investigation of the tip leakage vortex trajectory in an axial flow pump[R].ASME Paper GT-2013-16058,2013.
[7]	WU Yanhui,CHU Wuli,LU Xingen,et al.Behavior of tip-leakage flow in an axial flow compressor rotor[R].ASME Paper GT2006-90399,2006.
[8]	Furukawa M,Saiki K,Nagayoshi K,et al.Effects of stream surface inclination on tip leakage flow fields in compressor rotor[J].Journal of Turbomachinery,1998,120(4):683-694.
[9]	Wheeler A P S,Atkins N R,He L.Turbine blade tip heat transfer in low speed and high speed flows[J].Journal of Tturbomachinery,2011,133(4):041025.1-041025.9.
[10]	陈绍文,孙士珺,韩东,等.间隙大小对高负荷压气机叶栅流动特性的影响[J].工程热物理学报,2014,35(1):34-37. CHEN Shaowen,SUN Shijun,HAN Dong,et al.Experimental study of the effect of different gap height on the highly-loaded compressor cascade flow characteristics[J].Journal of Engineering Thermophysics,2014,35(1):34-37.(in Chinese)
[11]	杜娟.跨音压气机/风扇转子叶顶泄漏流动的非定常机制研究[D].北京:中国科学院,2010. DU Juan.Investigation on the unsteady mechanism of tip leakage flow in transonic compressor/fan rotors[D].Beijing:Chinese Academy of Sciences,2010.(in Chinese)
[12]	Hah C,Rabe D C,Wadia A R.Role of tip leakage vortices and passage shock in stall inception in a swept transonic compressor rotor[R].ASME Paper GT-2004-53867,2004.
[13]	ZHANG Qiang,HE Li.Over-tip choking and its implications on turbine blade tip aerodynamaic performance[J].Journal of Propulsion and Power,2012,27(5):1008-1014.
[14]	Hoffman W H,Ballman J.Some aspect s of tip vortex behavior in a transonic turbo compressor[R].ISABE Paper 2003-GT-1223,2003.
[15]	张晨凯,胡骏,王志强,等.轴流压气机转子叶尖间隙流动结构的数值研究[J].航空学报,2014,35(5):1236-1245. ZHANG Chenkai,HU Jun,WANG Zhiqiang,et al.Numerical study on tip clearance flow structure of an axial flow compressor rotor[J].Acta Aeronautica et Astronautica Sinica,2014,35(5):1236-1245.(in Chinese)
[16]	姜斌,王松涛,孙玺淼,等.跨音风扇顶部激波、泄漏流作用的数值研究[J].工程热物理学报,2008,28(10):1653-1656. JIANG Bin,WANG Songtao,SUN Ximiao,et al.Numerical simulation study on the effect of tip clearance on performance of a transonic axial fan[J].Journal of Engineering Thermophysics,2008,28(10):1653-1656.(in Chinese)
[17]	Messenger H E,Kennedy E E.Two-stage fan:I aerodynamic and mechanical design[R].NASA CR-120888,1972.
[18]	Kerrebrock J L,Epstein A H,Merchant A A,et al.Design and test of an aspirated counter-rotating fan[R].ASME Paper GT-2006-90582,2006.
[19]	Rugger R S,Benser W A.Performance of a highly loaded two-stage axial flow[R].NASA TMX-3076,1974.
