固体火箭发动机喷管阻尼特性的数值仿真

孙兵兵; 李军伟; 苏万兴; 王宁飞

doi:10.13224/j.cnki.jasp.2016.09.031

固体火箭发动机喷管阻尼特性的数值仿真

doi: 10.13224/j.cnki.jasp.2016.09.031

1. 北京理工大学宇航学院, 北京 100081;
2. 中国航天科技集团公司中国运载火箭技术研究院研究与发展中心, 北京 100076

详细信息

作者简介:
孙兵兵(1988-),男,河南许昌人,博士生,研究方向为固体火箭发动机不稳定燃烧.t19891089@126.com

中图分类号: V435.12
计量
- 文章访问数: 1297
- HTML浏览量: 410
- PDF量: 521
- 被引次数: 0
出版历程
- 收稿日期: 2014-12-13
- 刊出日期: 2016-09-28

Numerical simulation of nozzle damping characteristics in solid rocket motor

1. School of Aerospace Engineering, Beijing Institute of Technology, Beijing 100081, China;
2. Research and Development Center, China Academy of Launch Vehicle Technology, China Aerospace Science and Technology Corporation, Beijing 100076, China

摘要

摘要: 为了探究影响固体火箭发动机喷管阻尼特性的关键因素，基于典型柱状装药固体火箭发动机二维简化模型，利用脉冲衰减法，开展喷管阻尼特性数值仿真计算，研究了喉通比和燃烧室长度对喷管阻尼常数的影响规律，结果发现数值模拟结果与经验公式理论预估结果有较好的一致性，证实了该数值方法的有效性；在此基础上，进一步探讨了无法由经验公式直接获知的诸如喷管收敛半角以及收敛型面对喷管阻尼常数的影响规律，结果表明：收敛半角对喷管阻尼常数有很大的影响，在设计范围内，较小的收敛角有益于提高喷管阻尼特性；收敛段型面对喷管阻尼也有一定的影响，凸型型面阻尼特性优于锥型型面，锥形型面优于凹形型面.
- 固体火箭发动机 /
- 不稳定燃烧 /
- 喷管阻尼常数 /
- 脉冲衰减法 /
- 不稳定燃烧
Abstract: For the purpose of investigating the key factors affecting the nozzle damping characteristics of solid rocket motor, numerical simulation of nozzle damping characteristics were carried out to study the influence of the nozzle throat area-to-grain port area ratio and the chamber length, based on the simplified two-dimensional model of the typical columnar grain of solid rocket motor and with use of pulse attenuation method.It was found that the numerical simulation results and empirical formulas theoretical estimate values were in good agreement, confirm the validity of the numerical methods; the study further explored what the empirical formula cannot deal with well, such as the change rules of nozzle convergent half-angle and nozzle convergent surface. The results show that the nozzle convergent half angle plays a vital role in nozzle damping constant. Small convergent half angle is beneficial to the nozzle damping; the convex nozzle provides more damping than the conical nozzle, which in turn provides more damping than the concave nozzle.
- solid rocket motor /
- combustion instability /
- nozzle damping constant /
- pulse decay method /
- instable combustion

HTML

参考文献(21)

[1]	Blomshield F S.Historical perspective of combustion instability in motors:case studies[J].AIAA 2001-3875,2001.
[2]	Blomshield F S.Lessons learned in solid rocket combustion instabity[R].AIAA 2007-5803,2007.
[3]	孙维申.固体火箭发动机不稳定燃烧[M].北京:北京工业学院出版社,1987.
[4]	Crocco L,Sirignano W A.Behavior of supercritical nozzles under three-dimensional oscillatory conditions[R].Advisory Group for Aerospace Research and Development AD672435,AGARDograph 117,1967.
[5]	Zinn B T.Longitudinal mode acoustic losses in short nozzles[J].Journal of Sound and Vibration,1972,22(1):93-105.
[6]	Zinn B T.Nozzle damping in solid rocket instabilities[J].AIAA Journal,1973,11(11):1492-1497.
[7]	Crocco L.Verification of nozzle admittance theory by direct measurement of the admittance parameter[J].ARS Journal,1961,31(6):771-775.
[8]	Buffum F G,Jr,Dehority G L,Price E W,et al.Acoustic attenuation experiments on subscale,cold-flow rocket motors[J].AIAA Journal,1967,5(2):272-280.
[9]	Janardan B A,Zinn B T.Rocket nozzle damping characteristics measured using different experimental techniques[J].AIAA Journal,1977,15(3):442-444.
[10]	许春英,甘舜仙.喷管声导纳的理论计算和实验研究[J].兵工学报,1995,16(2):44-46. XU Chunying,GAN Shunxian.Calculation and experimental study of nozzle acoustic admittance[J].Acta Armamentarll,1995,16(2):44-46.(in Chinese)
[11]	Bell W A,Daniel B R,Zinn B T.Experimental and theoretical determination of the admittances of a family of nozzles subjected to axial instabilities[J].Journal of Sound and Vibration,1973,30(2):179-190.
[12]	Bell W A.Damping of axial instability by solid propellant rocket exhaust nozzle[D].Atlanta,USA:Georgia Institute of Technology,1973.
[13]	Morgenweck D,Pieringer J,Sattelmayer T.Numerical determination of nozzle admittances in rocket engines[M]//Dillmann A.Numerical and experimental fluid mechanics Ⅶ.Berlin Heidelberg:Springer-Verlage,2010:579-586.
[14]	Su W X,Wang N F,Li J W,et al.Numerical research on the nozzle damping effect by a wave attenuation method[J].Defence Technology,2013,9(3):162-166.
[15]	Javed A,Chakraborty D.Damping coefficient prediction of solid rocket motor nozzle using computational fluid dynamics[J].Journal of Propulsion and Power,2013,30(1):19-23.
[16]	Brown R S,Dunlap R,Young S W,et al.Vortex shedding as a source of acoustic energy in segmented solid rockets[J].Journal of Spacecraft and Rockets,1981,18(4):312-319.
[17]	Vuillot F.Vortex-shedding phenomena in solid rocket motors[J].Journal of Propulsion and Power,1995,11(4):626-639.
[18]	苏万兴,李世鹏,张峤,等.某固体火箭发动机工作末期不稳定燃烧[J].航空动力学报,2013,28(10):2376-2383. SU Wanxing,LI Shipeng,ZHANG Qiao,et al.Numerical study on combustion instability at the end of burning in solid rocket motor[J].Journal of Aerospace Power,2013,28(10):2376-2383.(in Chinese)
[19]	王宁飞,张峤,李军伟,等.固体火箭发动机不稳定燃烧研究进展[J].航空动力学报,2011,26(6):1405-1414. WANG Ningfei,ZHANG Qiao,LI Junwei,et al.Progress of investigation on combustion instability of solid rocket motors[J].Journal of Aerospace Power,2011,26(6):1405-1414.(in Chinese)
[20]	HU Daning,HE Guoqiang,LIU Peijin,et al.Study on instable combustion of solid rocket motor with finocyl grain[J].Journal of China Ordnance,2011,7(1):24-28.
[21]	赵伯华,康顺章.抑制中频不稳定性的固体火箭发动机设计[J].北京工业学院学报,1982(2):76-86. ZhAO Baihua,KANG Shunzhang.Design of solid propellant rocket engine aiming at a damping of the mid-frequency instability[J].Journal of Beijing Institute of Technology,1982(2):76-86.(in Chinese)
